Item #1005414989
Model #DFI-7004-WH-G
USE AND CARE GUIDE
MOTION SOLAR SECURITY LIGHT
Questions, problems, missing parts?
Before returning to the store, call Defiant Customer Service
8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-866-308-3976
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Defiant through the purchase of this motion solar security
light. We strive to continually create quality products designed to enhance your home. Visit us online to see our full
line of products available for your home improvement needs. Thank you for choosing Defiant!
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Defiant DFI-7004-WH-G
Summary of Contents for Defiant DFI-7004-WH-G
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Defiant through the purchase of this motion solar security light. We strive to continually create quality products designed to enhance your home. Visit us online to see our full...
-
Page 2: Table Of Contents
Table of Contents Solar Panel ..........3 Table of Contents ........2 Specifications ........4 Safety Information ........2 Tools Required ........4 Warranty ...........2 Hardware Included .........5 3-Year Limited Warranty ......2 Package Contents ........5 Pre-Installation .........3 Installation ..........6 Planning Installation ......3 Operation...........8 Initial Battery Charge ......3 Care and Cleaning ........9 Mounting Location ........3 Troubleshooting ........10... -
Page 3: Pre-Installation
Pre-Installation PLANNING INSTALLATION Before installing the light fixture, ensure that all parts are present. Compare parts with the Hardware Included and Package Contents sections. If any part is missing or damaged, do not attempt to assemble, install, or operate this light fixture. -
Page 4: Specifications
Pre-Installation (continued) SPECIFICATIONS Up to 40 ft. (12 m) (Varies with surrounding temperature) Range Up to 180° Sensing angle Solar Power: 2100 LM Lumens 5000K (bright white) LED color temperature 3600 mAh, 7.4V Li-Ion Rechargeable Battery (pre-installed, non- Power requirements replaceable) Off, Test, Auto Operating modes... -
Page 5: Hardware Included
Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware shown to actual size. Part Description Quantity Mounting screw Mounting screw Wall anchor PACKAGE CONTENTS Part Description Quantity Lamp heads Light fixture Motion sensor Mounting plate Solar panel HOMEDEPOT.COM Please contact 1-866-308-3976 for further assistance. -
Page 6: Installation
Installation Determining the mounting location NOTE: The light fixture should be mounted approximately 8 ft. (2.4 m) above the ground. If the light fixture is mounted higher than recommended, aiming the sensor down will reduce the coverage area. Wall Mount NOTE: Ensure the fixture and the solar panel are located THIS SIDE... - Page 7 Installation (continued) □ If mounting to wall board or brick, drill two Mounting the solar panel 7/32 in. holes into the mounting surface. Insert the wall anchors (CC) and attach the base using the two mounting screws (AA). IMPORTANT: Caulk around the base and on top of the screw heads after installation.
-
Page 8: Operation
Operation Adjusting the lamp heads □ If needed, gently grasp the lamp heads (A) and tilt them up or down or side to side to adjust the light coverage area. THIS SIDE Rotating the sensor controls downward CAUTION: To avoid water damage, the motion sensor controls must be facing the ground when installation is complete. -
Page 9: Care And Cleaning
Operation (continued) Adjusting the SENS switch NOTE: The higher the “SENS” setting (sensitivity), the greater the possibility of false triggering. To reduce false triggering, slide the “SENS” switch toward the “L” (low) setting. □ To increase the detection zone, slide the OFF TEST AUTO “SENS”... -
Page 10: Troubleshooting
Troubleshooting Problem Possible Cause Solution □ □ The light will not come on. The motion sensor control switch Slide the control switch to the AUTO is set to the OFF position. position. □ □ The rechargeable battery is dead. Slide the control switch to the OFF position and allow the battery to charge with 3 to 7 days of full sun- shine before testing. - Page 11 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 12 Questions, problems, missing parts? Before returning to the store, call Defiant Customer Service 8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-866-308-3976 HOMEDEPOT.COM Retain this manual for future use. 210529-01A...
- Page 13 HOMEDEPOT.COM GRACIAS Agradecemos la confianza que han depositado en Defiant al comprar esta luz solar de seguridad con detector de movimiento. Procuramos crear continuamente productos de calidad diseñados para mejorar su hogar. Visítenos en internet para ver nuestra línea completa de productos disponibles que necesita para el mejoramiento de su hogar.
-
Page 14: Contenido
Contenido Panel Solar ...........15 Contenido ..........14 Especificaciones ........16 Información de seguridad ......14 Herramientas Requeridas ....16 Garantía...........14 Ferretería Incluida ........17 3 años de garantía limitada ....14 Contenido del Paquete ......17 Antes de la instalación ......15 Instalación ..........18 Planificación de la Instalación .....15 Operación ..........20 Carga Inicial de la Batería ....15 Cuidado y limpieza .........21... -
Page 15: Antes De La Instalación
Antes de la instalación PLANIFICACIÓN DE LA INSTALACIÓN Antes de instalar el aparato de luz, esté seguro que estén todas las piezas. Compare las piezas con la Ferretería incluida y las secciones de Contenidos del paquete. Si cualquier pieza falta o está dañada, no intente ensamblar, instalar ni operar este aparato de luz. -
Page 16: Especificaciones
Antes de la instalación (continuación) ESPECIFICACIONES Hasta 40 pies (12 m) (Varía con la temperatura circundante) Alcance Hasta 180° Ángulo de detección Energía solar: 2100 LM Lúmenes 5000K (blanco brillante) LED de temperatura de color Pila de ión-litio de 3600 mAh, 7,4 Voltios (preinstalada, no Requisitos de la energía eléctrica reemplazable) Apagado, prueba, automático... -
Page 17: Ferretería Incluida
Antes de la instalación (continuación) FERRETERÍA INCLUIDA NOTA: La ferretería se muestra en su tamaño real Pieza Descripción Cantidad Tornillo de montaje Tornillo de montaje Ancla de pared CONTENIDO DEL PAQUETE Pieza Descripción Cantidad Cabezas de la lámpara Artefacto de luz Detector de movimiento Placa de montaje Panel solar... -
Page 18: Instalación
Instalación Determinación del sitio de montaje NOTA: Esta lámpara debe ser instalada aproximadamente a 8 pies (2,4 m) por encima del suelo. Si se la instala a una altura más alta de la recomendada, se reducirá la zona de cobertura si apunta el detector hacia abajo. Montaje en NOTA: Asegúrese que el aparato y el panel solar se pared... - Page 19 Instalación (continuación) □ Si se monta sobre tabla de fibra prensada Montaje del panel solar o sobre ladrillo, taladre dos orificios de 7/32 pulgadas en la superficie de montaje. Inserte anclas de pared (CC) y sujete la IMPORTANTE: Calafatee alrededor de la base y en la parte base con dos tornillos de montaje (AA).
-
Page 20: Operación
Operación Ajuste de los cabezales de la lámpara □ Si es necesario, sujete suavemente los cabezales de la lámpara (A) e inclínelos hacia arriba o hacia abajo o de lado a lado para ajustar el área de cobertura de la luz. THIS SIDE Giro hacia abajo de los... -
Page 21: Cuidado Y Limpieza
Operación (continuación) Ajuste del interruptor SENS NOTA: Mientras mayor sea la calibración del “SENS” (sensibilidad), mayor será la posibilidad de falsas alarmas. Para reducir las falsas alarmas, deslice el interruptor “SENS” hacia el ajuste “L” (baja). □ Para aumentar la zona de detección, deslice el OFF TEST AUTO interruptor “SENS”... -
Page 22: Análisis De Averías
Análisis de averías Problema Causa Probable Solución □ □ La luz no se enciende. El interruptor de control del Deslice el interruptor de control a la detector de movimiento está en posición AUTO. la posición OFF. □ □ La batería recargable está Deslice el interruptor de control a la agotada. - Page 23 Este aparato cumple con la Parte 15 de las Reglas de la FCC. La operación está sujeta a las dos siguientes condiciones: (1) este aparato no puede causar interferencias perjudiciales y (2) este aparato debe aceptar cualquier interferencia recibida, incluyendo una interferencia que pueda causar un funcionamiento indeseado.
- Page 24 ¿Tiene preguntas, problemas o piezas faltantes? Antes de devolverlo a la tienda, llame a Servicio al Cliente de Defiant de 08 a.m.-7 p.m., EST, Lunes - Viernes, 09 a.m.-6 p.m., EST, sábado. 1-866-308-3976 HOMEDEPOT.COM Guarde este manual para uso futuro.
Need help?
Do you have a question about the DFI-7004-WH-G and is the answer not in the manual?
Questions and answers
How do you change the battery for a new one
The manual does not provide instructions on how to change the battery for the Defiant DFI-7004-WH-G. It states that no service parts are available for this product. Therefore, changing the battery is not supported.
This answer is automatically generated
Does the solar require direct sunlight to operate ?
Yes, the Defiant DFI-7004-WH-G solar light requires direct sunlight to operate effectively. Solar collection is only effective in direct sunlight, and every hour the light is on requires a minimum of 16 hours of sunlight charging. Additionally, the solar panel should be positioned with minimal obstructions and aimed toward the south for optimal performance.
This answer is automatically generated
My light does not come on. Instead, a red light is on. What is wrong?
