Defiant DFI-7004-WH-G Quick Start Manual

The solar panel requires full, direct sunlight to charge the battery. Clouds, rain, snow, and other weather conditions may not allow
the solar panel to completely recharge the battery. Other obstructions such as buildings or trees may block the sun as well.
When installing the solar panel, make sure it is aimed toward the sun with a minimum amount of obstructions. If possible,
mount the panel facing toward the southern sky.
Refer to the included full instruction manual "Use and Care Guide" for installation, safety, and additional information.
Operation
1
Adjusting the lamp heads
The lamp heads may be adjusted left or right and up and
down.
3
Determining the motion sensor detection zone
NOTE: When the motion sensor switch is set to the "TEST"
position, the light will operate during the day or night. The light
will stay on for 5 seconds after all motion is stopped.
□ Slide the switch to the "TEST" position.
□ Slide the "SENS" switch to the "L" (low) position.
□ Perform a "walk test": walk in an arc across the front
of the motion sensor.
□ Watch the light. The light will come on and the red
LED will flash indicating motion has been detected.
□ Stop, wait for the light to turn off, and then begin
walking again.
4
Adjusting the sensitivity
□ "L" – Low range
□ "M" – Medium range
□ "H" – High range
OFF TEST AUTO
L M H
SENS
HOMEDEPOT.com
Quick Start Guide
MOTION SOLAR SECURITY LIGHT
THIS SIDE UP
OFF TEST AUTO
L M H
SENS
2
Connecting the solar panel to the light fixture
□ Adjust solar panel toward the sun for maximum sun
exposure.
□ Plug solar panel connector into light fixture connector.
THIS SIDE
□ Continue this process until the detection zone has
been established.
□ If needed, gently grasp the motion sensor and move
it from side to side or up and down to adjust the
detection zone.
5
Adjusting the light timer
□ OFF – turns light off.
□ TEST – light operates day or night for 5 seconds after
all motion has stopped. Used for setup.
□ AUTO – motion activated. Light can be set to stay on
between 5 seconds and 1 minute after all motion has
OFF TEST AUTO
stopped.
L M
Please contact 1-866-308-3976 for further assistance.
Item # 1005414989
Model # DFI-7004-WH-G
