Defiant DFI-0452-WH Quick Start Manual

Model: DFI-0452-WH Motion Security Light
Quick Start Guide
IMPORTANT - THIS LIGHT REQUIRES DIRECT EXPOSURE TO THE SUN TO CHARGE
The Defiant DFI-0452-WH Motion Security Light uses solar power to charge its on-board lithium-ion battery.
Upon installation, the light should be allowed to charge for at least 6 hours in direct sunlight before first use.
(Optional: leave the light OFF for at least 2 days, to charge without interruption, before turning ON for continuous operation.)
What's in the Box
Motion Security Light
Rechargeable Lithium-Ion Battery
included and installed.
Solar Panel
About the Rechargeable Battery
Specifications and Usage
The Motion Security Light includes a 2000mAh 3.7V rechargeable Lithium-Ion
battery. It is already installed in the unit, and may have a small charge for testing.
During the day, the battery is charged by solar energy; it take about 6 hours in clear,
direct sunlight for the battery to charge to full capacity.
In the evening, when the light switches over to motion-sensing, the battery discharges
whenever the light is triggered. It will discharge for a total of about 2 hours before
being depleted. Once the battery is depleted, the light will stop working until it is
charged again the next day.
Battery is installed,
and may have a starting charge. The battery is exclusively for use in the Defiant DFI-0452-WH, and replacement batteries
are available. Contact Home Depot Customer Service at 1-866-308-3976 for details.
Home Depot Customer Service
1-866-308-3976
or visit HomeDepot.com
Mounting Bracket Use and Care Guide
(May be attached to the back of
the Motion Security Light.)
Set of Screws
and Wall Anchors
Solar Panel Cradle
for Mounting Bracket and Cradle
Placement of the Light
for Optimal Operation
Mount at least 7.5 feet above the ground
You can install the light almost anywhere in an outdoor
setting, so long as it can be connected to the Solar Panel.
WALL
The light works best
mounted 7.5 feet
above the ground.
Leave 3 inches of clearance for the Mounting Bracket
Minimum
3-inch Clearance
Adjust the PIR Motion Sensor Head
Adjust the Motion Sensor Head based on
the distance you prefer to detect motion.
Adjust SENS accordingly.
Sensor Head Angle: 15º
Coverage Distance: 13 - 50ft.
Mount on Wall or Eave
WALL
Mount
Do Not Mount
INVERTED
When installing the Mounting Bracket, make sure it
has at least 3 inches of clearance from the top of the
bracket, to the bottom of any edge, overhang or rain-
gutter that may impede installation.
Motion Sensor is Motion Sensor tilted Motion Sensor tilted
Straight Ahead 15º down 30º down
No Tilt 15º Tilt 30º Tilt
Sensor Head Angle: 15º Sensor Head Angle: 30º
Coverage Distance: 10 - 39ft. Coverage Distance: 6.5 - 26ft.
EAVE
Mount
Motion Sensor tilted
45º down
45º Tilt
Sensor Head Angle: 45º
Coverage Distance: 1.5 - 16ft.
