User Manual
Congratulations! You have purchased a piece of engineering that we at Ridea have made with passion. Enjoy your rides with your Ridea component as much as we enjoyed making it.
Thank you for your purchase of a Ridea product. Please read thoroughly this user manual before proceeding with the installation of your new bottom bracket. Although the installation process of
your Ridea
CBB is easy to follow, we recommend taking your bottom bracket to a professional bicycle mechanic with specialized tools to perform the installation.
6
Contents
• Non-drive side cup
• Center sleeve
• Drive side cup
Center Sleeve
BB Cups
Bearing Shields
Important notice
• 2x bearing shields
• 2x 1mm & 2x 2mm chainline adjusters
(compatible with spindles of 30 and 29 mm)
Chainline
Adjusters
CBB
6
T47A
Product number BB shell ⌀ / width
Frame BB
T47 (& mod
M47x1/61mm
OSBB)
T47 (& mod
M47x1/68mm
PF30)
T47 (& mod
M47x1/73mm
PF30)
#CN 47A 30
T47 (& mod
M47x1/86.5mm
BB386)
Note about non-30 mm spindle cranksets
This basic kit of 6CBB T47A includes the necessary items to install your
new BB on a T47 frame shell and on modified PF30, OSBB and BB386
shells with threads. Only cranksets with spindles of 30 mm in diameter are
compatible. If your crankset has a different spindle design (29, 25, 24 mm)
please refer to the Spindle Sleeve Kit manual to install your BB.
Spindle
Crankset
Spindle Kit
FACT/BB30
N/A
⌀30
BB30
N/A
FACT/BB30
N/A
BB386EVO
N/A
⌀29
BB392EVO
BB29/DUB
YES
⌀25
CAMPAGNOLO
YES
⌀24
BB24/SHIMANO
YES
3-2021
