Ridea 6CBB ITA30 User Manual

User Manual
Congratulations! You have purchased a piece of engineering that we at Ridea have made with passion. Enjoy your rides with your Ridea component as much as we enjoyed making it.
Thank you for your purchase of a Ridea product. Please read thoroughly this user manual before proceeding with the installation of your new bottom bracket. Although the installation process of
your Ridea CBB is easy to follow, we recommend taking your bottom bracket to a professional bicycle mechanic with specialized tools to perform the installation.
6
Contents
• 2x BB cups • 2x 1mm & 2x 2mm chainline adjusters
• Center sleeve
• 2x bearing shields
Center Sleeve
BB Cups
Bearing Shields
Important notice
(compatible with spindles of 30 and 29 mm)
Chainline
Adjusters
CBB
6
ITA30
BB shell ⌀ / width
Product number Frame BB
Italian
#CN ITA 30 M36x24 / 70 mm threaded
Note about non-30 mm spindle cranksets
This basic kit of CBB ITA includes the necessary items to install your new BB
6
on an Italian threaded frame shell to be used with cranksets with spindles of
30 mm in diameter. If your crankset has a different spindle design (29, 25,
24 mm) please refer to the Spindle Sleeve Kit manual to install your BB.
Spindle Crankset Spindle Kit
⌀30
BB386EVO
N/A
⌀29
BB392EVO
BB29/DUB YES
⌀25
CAMPAGNOLO YES
⌀24
BB24/SHIMANO YES
