- Page 1 ALOKA ARIETTA 850 Quick Reference Guide...
- Page 3 Your Quick Reference Guide for the ALOKA ARIETTA 850 Premium Ultrasound Processor The information contained in this guide was created to help you better understand your premium ultrasound processor. Information is broken out into eight color-coded sections to make it easy to use.
- Page 4 PATIENT PLUG POWER PROBE/PRESET...
- Page 5 The 4 Ps The 4 Ps are the steps to set up the system: (In this order) PLUG the scope(s) into the port(s) POWER on the system PATIENT DATA - Enter the patient ID on the input screen that appears on startup OR select the New Patient button and then enter the data PROBE/PRESET - Choose the appropriate preset from the Touch Screen Note: When changing scopes (within the same patient), freeze first, change scopes, press the...
- Page 7 TOUCH SCREEN Types of Controls Turns items On/Off Up/Down Left/Right Rotate Choose one or the other Rotary knob controls Takes you to a Increases or submenu decreases choices GETTING STARTED...
- Page 9 CONTROL PANEL Control Panel Lights (Including Touch Screen) Orange – In use Blue – Available for use Unlit – Not currently available for use Note: Control Panel lights will change depending on the imaging mode and when switching between frozen and live scanning. GETTING STARTED...
- Page 10 Page 1 of 2 eFocusing Graymap Color Map Dynamic Range Frequency Menu Focus HI Zoom Depth/Pan Gain Freeze...
- Page 11 BASIC IMAGE CONTROLS – – PRESET DYNAMIC RANGE Are you using the correct Increases or decreases • • preset? Probe (on bottom left) and Preset the contrast in the gray scale. (on bottom right) should match on the main – Adjusts the gain at varying depths.
- Page 12 Page 2 of 2 Persistence Level Search CINE...
- Page 13 ADVANCED IMAGE CONTROLS AGC – Constantly adjusts the brightness level PERSISTENCE – Controls how many frames • • as you move through different tissues. will be overlaid to form each image. A higher number will result in a smoother image. SEARCH/CINE –...
- Page 14 1. Freeze 2. Caliper 3. Trackball 4. Enter...
- Page 15 MEASUREMENT STEPS FREEZE image Press CALIPER Measure Place caliper using TRACKBALL Press ENTER Place second caliper using TRACKBALL For a second measurement, repeat steps 2-5. MEASUREMENTS...
- Page 16 KB & Anno. Home Tabs Set Home Font Size Rotary Knob Trackball Enter...
- Page 17 ANNOTATION STEPS FREEZE image Press the ABC ROTARY KNOB Use TRACKBALL to move to the desired location Choose the desired annotation from the Touch Screen or enter using the keyboard or virtual keyboard • KB, ANNO.+KB OR ANNO. can be chosen using the tabs along the top of the Touch Screen •...
- Page 18 Dual CF Flow Gain & Color Flow PW Gain & Pulsed Wave eFlow Power Doppler...
- Page 19 DOPPLER CONTROLS Available Doppler modes: Color, Power, eFlow and Pulsed Wave FLOW GAIN (Color, Power, eFlow) • - Controlled by the rotary knob surrounding the CF button PULSED WAVE GAIN • - Controlled by the rotary knob surrounding the PW button ROI (Region of Interest) BOX •...
- Page 20 Review Screen Select Desired HDD Space Images Availability Sends Images Find Past Images Viewing Modes Full Screen Controls Deletes Selected Images Store Review Button Print & Store Print...
- Page 21 IMAGE STORAGE AND MANAGEMENT STORE • - Store images by pressing the Store button - Frozen images will be stored as a single frame image - Real-time (live) images will be stored as a video clip - Start and stop recording with the Store button - Single images can be captured anywhere within a Cineloop - Video clips can be stored when playing back a Cineloop PRINT...
- Page 22 Review Screen (Copy) (PC Format) Delete Delete Select/Deselect All Deselect all Disk Remain Archive Setup...
- Page 23 REVIEWING IMAGES 1. Press the REVIEW button to access stored images 2. Current exam’s images will be displayed 3. Select/Deselect images as desired 4. Images can be sent to a PACS system or copied to an external media in a variety of formats - Single Frame: JPEG, BMP, TFF - Video: AVI, MPEG USB Ports located behind the Touch Screen...
- Page 24 Elasto Pressure Bar (Must choose the appropriate preset. Note: Pressure Bar has fewer options.) Strain Graph...
- Page 25 STEPS TO OBTAIN A GOOD ELASTOGRAPHY IMAGE 1. Obtain a good B mode image (depth and gain) with respiratory variation perpendicular to the ultrasound beam 2. Touch the ELASTO button 3. Adjust the ROI position and size using the ENTER key and TRACKBALL - Press ENTER to switch between size and location - Include normal gastric/duodenal wall - Omit fluid-filled structures (i.e.
- Page 26 Area Frame Strain Graph Select Reconfig. Average Frame...
- Page 27 ELASTOGRAPHY TIPS STRAIN GRAPH A good elastography image is one filled with the most persistent colors and – • has a consistent sine wave on the strain graph. AREA RECONFIG Allows relocation of the ROI on a frozen image using the trackball. •...
- Page 28 Strain Ratio Auto/Manual Measurement Menu Enter Left Trackball...
- Page 29 STRAIN RATIO MEASUREMENT STEPS 1. Obtain a frozen, optimized elastography image 2. Press the MEASUREMENT MENU button 3. Select STRAIN RATIO on the Touch Screen - Ensure that the ROI setting method is on MANUAL 4. Place ROI A on the lesion - Set the starting point by pressing ENTER - Move the TRACKBALL to adjust the size - Press ENTER to set the size and location...
- Page 30 Strain Ratio Auto/Manual Measurement Menu Enter Left Trackball...
- Page 31 STRAIN RATIO MEASUREMENT TIPS Assist Strain Ratio (ASR) helps chose To move an ROI, before setting the ROI the ideal ROI placement 1. Press the LEFT button 1. Obtain a frozen, optimized 2. Place cursor in center of the ROI elastography image 3.
- Page 32 Strain Histogram Rectangle Measurement Menu Undo Enter Left Trackball...
- Page 33 STRAIN HISTOGRAM MEASUREMENT: STEPS & TIPS TIPS: STEPS: Obtain a frozen, optimized elastography image To perform another strain histogram • measurement on the same image, Press the MEASUREMENT MENU button select RECTANGLE on the Touch Screen Select STRAIN HISTOGRAM on Touch Screen (this will clear the current measurement data) Place + over area of interest (starting point) To change location of the ROI before setting:...
- Page 34 LOCK WHEELS & ADJUST CONSOLE HEIGHT 1. Step on the front caster wheels to lock them. 1. Adjust the height of the control panel by holding the handle with both hands while 2. Depress the lock pedals for the rear wheels. stepping on the front center pedal.
- Page 35 ROTATING CONTROL PANEL & CLEANING Grasp the handle while depressing the lever to swivel the control panel up to 25 left or right. Releasing the lever will lock the panel in place. Lever System Cleaning Note: - Monitor should always be dried with a soft cloth following any moist cleaners. - Between patients: Freeze, unplug dirty scope, unfreeze with no scope plugged in.
- Page 36 ADJUSTING THE MONITOR POSITION Grasp the frame of the monitor in both hands and move it in a large swinging movement to adjust its height or orientation. Even when the monitor arm axis is vertical, it is easier to move the monitor if you swing it.
- Page 37 LOCKING THE MONITOR 1. Push the 1 arm to the rear Releasing the Monitor Hold down the monitor lock release 2. Make the 3 arm parallel with the base button while raising the arm 3. Face the monitor upwards Raise the monitor 4.
- Page 39 TROUBLESHOOTING • Can’t turn it on – Check circuit breaker on back of the system near the floor • Power is on, but menus/controls aren’t working – Use the Probe button to activate the preset • Image or control issues – Are you on the correct preset? •...
- Page 41 At Olympus our partnership doesn’t end after the product is shipped. The point of transition signals a new phase of the relationship we have with our customers: one that is built on the trust and confidence we offer through a dedicated and committed team of support personnel.
