Pin No. Pin Name
104 GND
105 PAR_D6
106 PAR_D8
107 PAR_D10
108 PAR_D12
109 GND
110 PAR_D15
111 PAR_D16
112 PAR_D18
113 PAR_D20
114 PAR_D22
115 GND
116 VIO (+3.3 V)
117 GND
118 GND
119 NC
120 NC
1
Functionality not implemented on the SDP board.
2 Shared across both connectors.
Each interface provided by the SDP-B is available on unique pins of the SDP-B 120-pin connector. The connector pin numbering scheme
is outlined in Figure 3.
Description
Connect to ground plane of board.
Parallel Data Bus Bit 6.
Parallel Data Bus Bit 8.
Parallel Data Bus Bit 10.
Parallel Data Bus Bit 12.
Connect to ground plane of board.
Parallel Data Bus Bit 15.
Parallel Data Bus Bit 16.1 (No connect.)
Parallel Data Bus Bit 18.1 (No connect.)
Parallel Data Bus Bit 20.1 (No connect.)
Parallel Data Bus Bit 22. (No connect.)
Connect to ground plane of board.
+3.3 V Output. 20 mA maximum current available to power IO voltage on daughter board.
Connect to ground plane of board.
Connect to ground plane of board.
No Connect. Leave this pin unconnected. Do not ground.
No Connect. Leave this pin unconnected. Do not ground.
1
1
1
1
