Hardware Function; Battery Installation - Qstarz BT-Q1000XT Quick Installation Manual

English
................................................................................................................................................................................................................
C. Hardware Function
Hardware
Function
Power Jack
Mode Switch
(OFF)
Mode Switch
(NAV)
Mode Switch
(LOG)
POI Button
Mode Switch (OFF)
D. Battery Installation
D-1 Put Battery in place: Press the PUSH button on the bottom
side of the unit and pull out the battery cover. Insert battery in the
unit and put battery cover on to the cabinet, then push down and
force it forward to fit firmly.
D-2 Take Battery out: Press the PUSH button on the bottom side of
the unit and pull out the battery cover. Then take out the battery
from the unit.
.........................................................................................................................................................................................
2
Take the power cable and connect it to the
power jack (mini USB type) for charging only
Power off BT-Q1000XT
When switch to NAV mode, BT-Q1000XT can be
used to navigate with handheld devices (PDA /
Smartphone / Laptop...), and the Log function will
be enabled if the present time is within the
preset time schedule.
When switch to LOG mode, BT-Q1000XT can be
used to record your travel path, and navigation
function is still enabled.
Push the POI button to log favorite Point of
Interest
Mode Switch (NAV)
Description
Mode Switch (LOG)
