Page 1
(2) + Cigarette Adapter (3) + mini USB Cable (4) + Driver CD (5) + Leather Bag (6) + Warranty Card + User’s manual NOTE: The Cigarette Adaptor can only be used to charge BT-Q1000eX. Please don’t make use of it with devices other than BT-Q1000eX. B. Appearance 1.
Page 2
3 short beeps when POI button POI button 3 short beeps being pressed Memory 3 long beeps when the device is out 3 long beeps exhausted of memory Sleep mode 1 long and 1 1 long and then 1 short beep when ......................................www.Qstarz.com...
Register your Qstarz product to get the latest news, software update, event, and product information. http://www.qstarz.com/reg.php Update the Software Please always go to Qstarz download page to check if there is any latest software update http://www.qstarz.com/download.php Start to use Step 1: Install Battery Open the Battery Cover and Insert the Battery.
English ………………………………………………………………………………………………………………………………………………………………………………………. Step 2: Charge Battery Plug in USB cable and charge it for 3 hrs until the green power LED goes off ......................................www.Qstarz.com...
Page 5
GPS Lap Timer 10Hz English ………………………………………………………………………………………………………………………………………………………………………………………. Step 3: Mount Q1000eX 10Hz - 1 Mount Q1000eX on your eXtreme sports equipment. ………………………………………………………………………………………………………………………………………………………………………………………. www.Qstarz .com...
Page 6
If the device will be exposed to outside environment, such as attached on motorcycle, any other safety protection equipment must be applied to prevent the device from sliding out of the bag......................................www.Qstarz.com...
Page 7
Note: Q1000eX is for outdoor use; an open sky outdoor environment will enable faster satellite acquisition and provide better positioning accuracy. 1. Switch Q1000eX to 10Hz mode 2. Confirm GPS gets fix GPS LED flashes 2 short beeps 3. Start to Race ………………………………………………………………………………………………………………………………………………………………………………………. www.Qstarz .com...
Page 8
English ………………………………………………………………………………………………………………………………………………………………………………………. Step 5: Install Qstarz QRacing Software Install the QRacing from Qstarz software CD. You may also install PC Suite software (QSports and QTarvel) for manage other sports activity or geotagging your travel photos. Note: Users have to input product key at the first time of use.
Page 9
GPS Lap Timer 10Hz English ………………………………………………………………………………………………………………………………………………………………………………………. Step 6: Import Data from Q1000eX 10Hz 1. Switch on and Connect to PC, then open QRacing 2. QRacing will automatically detect the device and ask if you want to read log from device. ………………………………………………………………………………………………………………………………………………………………………………………. www.Qstarz .com...
Page 10
3. Click on “Yes” to import the data and Select your Racing Type. Step 7: Edit Beacon After import data from Q1000eX, if you have not edited beacons for this track, QRacing will ask you to edit beacons......................................www.Qstarz.com...
Page 11
After setting up beacons, change to Analysis page to view and analyze your lap time and the best result will be highlighted in blue. Avg/Max/Min Speed and Distance View Sector View Sector = the time from one split point to next split point. ………………………………………………………………………………………………………………………………………………………………………………………. www.Qstarz .com...
Page 12
English ………………………………………………………………………………………………………………………………………………………………………………………. Spilt View (Cumulative) Split = the cumulative time from start point to a split Point Point Current Speed View ......................................www.Qstarz.com...
Page 13
3. Click the play button on the status bar. It can replay the selected 3 laps and display the racing information by time and speed simultaneously. ………………………………………………………………………………………………………………………………………………………………………………………. www.Qstarz .com...
English ………………………………………………………………………………………………………………………………………………………………………………………. Step 10: Preference setting In the Menu > Tool > Preference or click on the Preference button on Track page will allow user to select their preference setting when playing the track......................................www.Qstarz.com...
Page 15
Step 11: Video QRacing can sync the racing video with the track. In Video page; click on the button “Set video for track...” the video setting dialog will pop out. You can add, remove and edit the videos. ………………………………………………………………………………………………………………………………………………………………………………………. www.Qstarz .com...
Page 16
(Circuit, Drag or Rally racing) and compare with other user’s track. *For detailed instructions, please refer to QRacing’s user manual attached with the software. *Or visit our online tutorial video at: http://www.qstarz.com/Products/Software%20 Products/QRacingVideo.html ......................................www.Qstarz.com...
