Hearth and Home Technologies Outdoor Lifestyles ODLANAIGST-48 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Model:
WARNING!
Risk Of Fire!
Do not install glass doors on this appliance.
Glass doors could cause overheating
of adjacent structures.
Outdoor Lifestyles by Hearth & Home Technologies Inc. • Lanai 48 See Thru Installation Manual • 4113-901 Rev. D • 8/21
Installation Manual
Installation and appliance setup
MH61458
11
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
•
Shut off gas to the appliance.
•
Extinguish any open flame.
•
If odor continues, leave the area immediately.
•
After leaving the area, call your gas supplier or fire
department.
•
Failure to follow these instructions could result in fire
or explosion, which could cause property damage,
personal injury, or death.
WARNING
Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING: For outdoor use only.
Installation and service must be performed by a qual-
ified installer, service agency, or the gas supplier.
WARNING:
Improper installation, adjust-
ment, alteration, service or maintenance can cause
injury or property damage. Read the installation,
operating and maintenance instructions thoroughly
before installing or servicing this equipment.
WARNING:
If the information in this manual
is not followed exactly, a fire or explosion may
result causing property damage, personal injury, or
loss of life.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Outdoor Lifestyles ODLANAIGST-48 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hearth and Home Technologies Outdoor Lifestyles ODLANAIGST-48

Summary of Contents for Hearth and Home Technologies Outdoor Lifestyles ODLANAIGST-48

  • Page 1 Installation Manual Installation and appliance setup INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. NOTICE: DO NOT discard this manual! DANGER FIRE OR EXPLOSION HAZARD If you smell gas: • Shut off gas to the appliance. •...

  • Page 2: Table Of Contents

    Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •...

  • Page 3: Standard Work Checklist

    Standard Work Checklist Attention Installer: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual Customer: ________________________ Date Installed: _________________________ Lot/Address ______________________ __ Location of _________________________...

  • Page 4: Product Specific Information

    Product Specific Information  A. Appliance Certification D. Non-combustible Materials Specification Model: ODLANAIGST-48 Material which will not ignite and burn. Such Laboratory: Underwriters Laboratories(UL) materials are those consisting entirely of steel, Type: Outdoor Decorative Gas Appliances Standard: ANSI Z21.97-2017, CSA 2.41-2017 iron, brick, tile, concrete, slate, glass, plasters or any combination thereof.

  • Page 5: Getting Started

    Getting Started A. Design and Installation Considerations B. Tools and Supplies Needed The Lanai series gas appliance is designed for outdoor Before beginning the installation be sure that the use and may be installed as a stand alone unit or built following tools and building supplies are available.

  • Page 6: Inspect Appliance And Components

    C. Inspect Appliance and Components Hearth & Home Technologies disclaims any responsibility for, and the warranty will be • Carefully remove appliance voided by, the following actions: components from the packaging. • Installation and use of any damaged • Remove non-combustible material appliance.

  • Page 7: Framing And Clearances

    Framing and Clearances A. Appliance Dimension Diagrams Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Figure 3.2 and Figure 3.3. 39-1/2 in. (1003 mm) 17 in. 39-1/2 in. (1004 mm) (432 mm) 33-1/8 in.

  • Page 8: Clearances To Combustibles

    B. Clearances to Combustibles When selecting a location for the appliance, it is important to consider the required clearances to walls (see Figures 3.2, 3.3, and 3.4.) WARNING! Risk of Fire or Burns! Provide adequate clearance around air openings and for service access.
  • Page 9 ODLANAIGST-48 NOTICE: Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/ diagrams are not drawn to scale. Actual installation may vary due to individual design preference. Note: For actual appliance dimensions refer to Section 3.A. 1/2 in 11-5/8 in (13 mm) (295 mm) 52-1/8 in...

  • Page 10: Vent Minimum Clearances

    C. Vent Minimum Clearances = AREA WHERE TERMINAL IS NOT PERMITTED = AIR SUPPLY INLET = Appliance OPENING H or i Electrical Service U.S.A. Installations: In accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas Code. Canadian Installations: In accordance with the current CSA B149.1, Natural Gas and Propane Installation Code. U.S.A.

  • Page 11: Hearth Extension/Floor Protection

    • Built-in Installation When this appliance is installed into a wall, we 8 in. recommend that the wall be an exterior wall (202 mm) min. Non-combustible Ceiling or system. Overhang • See framing measurements in Figure 3.2 and 3.4. • You must maintain 1 ⁄...

  • Page 12: Moisture Resistance

    F. Moisture Resistance This outdoor appliance will shed moderate amounts of water, but is not waterproof. This appliance must be enclosed or covered with noncombustible finish material and all joints sealed to prevent water infiltration. The firebox will not perform as an exterior wall. Moisture penetration must be considered for construction that places the appliance in structure walls or on moisture sensitive surfaces.

  • Page 13: Appliance Preparation

    Appliance Preparation A. Securing and Leveling Appliance NOTE: Use high temp silicone or sealant recommended by the manufacturer of the house CAUTION! Risk of cuts, abrasions or flying wrap to seal between combustible sheathing debris. Wear protective gloves and safety glasses house wrap and non-combustible sheathing.

  • Page 14: Electrical Information

    Electrical Information A. Wiring Requirements C. Installing the Electrical The Lanai is supplied with the junction box located Note: The Lanai appliance MUST be connected to a GFCI (Ground Fault Circuit Interrupt) protected circuit on the right side of the appliance. There is no breaker.
  • Page 15 • Wire junction box and reassemble. See Figure 5.1. Black and white wires must be wired inside box. Figure 5.3. Wire Junction Box • • Plug in transformer and power supply to junction box. See Figure 5.4. Power Supply Transformer Figure 5.4.
  • Page 16 Wiring Diagram JUNCTION BOX V AC POWER SUPPLY YELLOW CABLE NOTE: The five black plugs on the control module are designed for the LED strips only and can be used for the LEDs in any configura�on. The yellow port is for wall controls only.

  • Page 17: Wall Switch Control Assembly

    D. Wall Switch Control Assembly ► • Using the tabs, mount the wall control switch assembly to a stud within 14’ of the appliance. The Lanai series outdoor gas appliance is supplied with a wall switch control panel. See Figure 5.7. Control Mounting Box Wall Switch...

  • Page 18: Gas Information

    Gas Information A. Valve Access WARNING The valve and controls are located in the appliance control box. See Figure 6.1. Fire Risk. The control box and controls can be accessed by Explosion Hazard. lifting engine assembly and shown in Figure 6.1 High pressure will damage valve.

  • Page 19: Gas Connection

    C. Gas Connection convert the unit for use with propane. • Conversions must be made by a qualified • Refer to Section 3 for location of gas line service technician using Hearth & Home access in appliance. Technologies specified and approved parts. •...

  • Page 20: Finishing

    Finishing A. Facing Material Mantel and Wall Projections WARNING! Risk of Fire! Comply with all minimum The fireplace structure can be covered with any clearances to combustible as specified. Framing or noncombustible material. Refer to Section 1.D. finishing material closer than the minimums listed must be constructed entirely of noncombustible WARNING! Risk of Fire! DO NOT apply materials (i.e.
  • Page 21 Good Faith Guidelines for TV Installa�ons above a Typical Gas Fireplace TV recessed into the wall TV on the wall Noncombustible Mantel (required) Measured from top of rebox opening. 6” Min. 6” Min. 6” Min. 14” Min. 14”Min. 12” 12” Min.

  • Page 22: Appliance Setup

    Appliance setup A. Remove the Shipping Materials Media placement Template Remove the plastic coating and shipping materials Deflection Glass from the firebox. WARNING! Risk of Fire! Close the ball valve before installing the media template to prevent accidental lighting. Remove the media template before lighting the appliance.

  • Page 23: Reference Materials

    Reference Materials A. Accessories LP Conversion Kit: • LPK-ODLANAIG48 Media Kits: • Media-Ebony-48 • Media-Cobalt-48 • Media-Red-48 • Media-Amber-48 Optional Screen – ODLANAIG-48SCN • The Lanai series outdoor gas appliance offers a protection screen that is designed to protect the inside of the appliance from trash and other debris (sticks, leaves, etc.) while not in use.

  • Page 24: Addendum

    B. Addendum How to Calculate the Minimum Opening Needed In an Outdoor Living Space 30% (or .30) of the outdoor living space periphery needs to be open. 1. Add lengths of the outside living space. 16’+20’+16’+20’=72’ 16’ 2. Divide the open area length by the total outdoor living space.
  • Page 25 Outdoor Lifestyles, a brand of Hearth & Home Technologies 2571 215th Street West, Lakeville, MN 55044 www.hearthnhome.com Please contact your Outdoor Lifestyles dealer with any questions or concerns. For the location of your nearest Outdoor Lifestyles dealer, please visit www.hearthnhome.com Outdoor Lifestyles by Hearth &...
