PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
Unpack all parts from the carton to ensure there are no missing or damaged parts. If any parts are missing or damaged, do
not attempt to assemble or use the product. Please contact customer service for replacement.
SAVE THESE INSTRUCTIONS. This manual contains important safety and operation instructions for power units.
Carton Contents
A – Cascade top
(#FA0332AA01)
B – Cascade bottom
(#FA0332AA02)
C – UL listed transformer
(#CE09136)
D – Low voltage halogen lamp
(#CB02367)
E – UL listed pump
(#PT-505MIX)
F – Cover
(#FA0332AA03)
Replacement Parts (not included)
Bulb: # MR11 12Volt. 10watts max.
submersible lamp
UL Listed Pump: # PT-505MIX
UL Listed Transformer: # 48C.YL-12-12V
Contact Customer Service for missing
parts replacement.
If the cascade top and cascade bottom
are missing or damaged, the unit must
be returned to retailer.
ITM./ART. 201545
River Rock Fountain
Any questions, problems, or missing parts?
Please do not return this product to the retailer.
Please call customer service at (866) 583-7034 from 8am – 10pm (EST), Mon. – Sat.
or e-mail customerservice@srg-usa.com.
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
NOTE: Diagram for illustrative purposes only and not to scale.
Page 1
Advertisement
Table of Contents
Related Manuals for Stone Art 201545
Summary of Contents for Stone Art 201545
- Page 1 ITM./ART. 201545 River Rock Fountain Any questions, problems, or missing parts? Please do not return this product to the retailer. Please call customer service at (866) 583-7034 from 8am – 10pm (EST), Mon. – Sat. or e-mail customerservice@srg-usa.com. PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
- Page 2 ASSEMBLY INSTRUCTIONS Recommended for outdoor use only. If used indoors, adjust pump pressure to minimize water splashing. Protect indoor flooring from potential water damage due to splashing from moving/falling fountain water. Use a protective sheet that does not stain or damage the flooring. 1.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS FOR TRANSFORMER When using electrical products, basic precautions should always be practiced including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS. Read and follow all instructions that are on the product or provided with the product. For a cord-connected or direct plug-in power unit, do not use an extension cord. Reference the National Electrical Code, ANSI/NFPA 70, specifically for the installation of wiring and clearances from power and lighting conductors.
- Page 4 SUBMERSIBLE LIGHT BULB REPLACEMENT INSTRUCTIONS: 1. If an accent light bulb is burned out, unplug the transformer from the power source and allow a few minutes for the light bulb to fully cool before handling. 2. Remove the lamp’s plastic cover by twisting in a counter clockwise motion and remove the transparent cover.
