Unpack all parts from the carton to ensure there are no missing or damaged parts. If any parts are missing or damaged,
do not attempt to assemble or use the product. Please contact customer service for replacement.
Parts List
A – Fountain Upright
1 pc.
B – Fountain Pedestal
1 pc.
C – Pump
1 pc.
D – Transformer
1 pc.
E – Lamp Bulbs
1 set of 3 pcs.
F – Pump Cover
1 pc.
G – Screw & Washer
2 pcs. each
Tools Required for Assembly
Screwdriver (not included)
Replacement Parts
Bulb:
12 Volt. Type JC submersible
halogen bulb, 10watts max.
Pump:
# HI-350 (O) L14-2*10W/P300.
Transformer: #66C. YL-50-12V.
Contact Customer Service for
missing parts.
If the fountain upright or basin are
damaged, the unit should be
returned to or exchanged at the
retailer
Item #963149
Classic Medallion Pedestal Fountain
Questions, Problems, Missing Parts?
Before returning to retailer, please call customer service at (201) 896-6030 from
9am – 4pm (EST), Mon – Fri or e-mail customerservice@silkroadgifts.com.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
NOTE: Diagram for illustrative purposes only and not to scale. There may be
technical and design modifications to constantly improve this product.
Advertisement
Table of Contents
Related Manuals for Stone Art 963149
Summary of Contents for Stone Art 963149
- Page 1 Item #963149 Classic Medallion Pedestal Fountain Questions, Problems, Missing Parts? Before returning to retailer, please call customer service at (201) 896-6030 from 9am – 4pm (EST), Mon – Fri or e-mail customerservice@silkroadgifts.com. PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY. Unpack all parts from the carton to ensure there are no missing or damaged parts. If any parts are missing or damaged, do not attempt to assemble or use the product.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS • When using electrical product, basic precautions should always be practiced including the following: • READ AND FOLLOW ALL SAFETY INSTRUCTIONS that are on the product or provided with the product. • We recommend that installation work and electrical wiring be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction.
- Page 3 ASSEMBLY INSTRUCTIONS Estimated assembly time: Approximately 15 minutes 1. Place the fountain pedestal on a flat, level surface and place the pump, with the outlet facing upwards, and lights unit into the bottom of the basin making sure the flow rate of the pump is set to the maximum (+) position (if applicable).
- Page 4 CARE AND MAINTENANCE 1. Keep the water clean and clean the fountain periodically to prevent mineral deposits and contamination which may clog the pump. 2. Use a pre-filter on your pump if available. 3. Regular cleaning of the pump will be necessary depending upon the environment in which it is operated. Clean the pump when it is visibly soiled or when a noticeable drop in performance is detected.
