Unpack all parts from the carton on a protected surface to ensure there are no missing or damaged parts. If any parts are missing or
damaged, do not attempt to assemble or use the product. Please contact customer service for replacement.
•
For outdoor use only.
•
Fully submerge pump in water prior to turning on power source and replenish with water as often as necessary.
•
Save these instructions for future use.
PARTS LIST
Fountain body
includes low-voltage pump with
2 pre-attached low voltage finger lights
each with 10W halogen bulb
Low-voltage pump Part #: FC0186CA01
Sailor boy statue
Part #: FC0186CA02
Sailboat
Part #: FC0186CA03
Model #: AUO-48122085, 120V AC
cULus listed transformer
Part #: CE09203
REPLACEMENT PARTS
Halogen Bulb inside Glass Tube Cover 2 pcs
JC Type, 12 volts, 10 watts Max
Sailor Boy Fountain
ITM./ART. 433941
Model FC0186BA
Questions, Problems, Missing Parts, Replacement Parts?
Please call customer service (English only) at (866) 583-7034 from 8am – 10pm (ET),
Mon. – Sat. or e-mail customerservice@srg-usa.com.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
1 pc
1 pc
1 pc
1 pc
NOTE: Diagrams for illustrative purposes only and not to scale.
1
Advertisement
Table of Contents
Related Manuals for Stone Art FC0186BA
Summary of Contents for Stone Art FC0186BA
- Page 1 Sailor Boy Fountain ITM./ART. 433941 Model FC0186BA Questions, Problems, Missing Parts, Replacement Parts? Please call customer service (English only) at (866) 583-7034 from 8am – 10pm (ET), Mon. – Sat. or e-mail customerservice@srg-usa.com. PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY. •...
- Page 2 ASSEMBLY INSTRUCTIONS Assemble the fountain in the location you intend to use it. Do not move with water in the fountain. Place the Sailor Boy statue and Sailboat onto their matching holes on the fountain body. (Fig. 1) From the opening at the back of the fountain body, place the pump and 10W finger lights assembly upright in the basin and insert the water supply tube into the pump outlet on top of the pump.
