Unpack all parts from the carton to ensure there are no missing or damaged parts. If any parts are missing or damaged,
do not attempt to assemble or use the product. Please contact customer service for missing parts.
Carton Contents
Basin
1 pc.
Pedestal
1 pc.
Bowl
1 pc.
Ball
1 pc.
Oil Lamp Canister
1 pc.
(Oil not included)
Pump
1 pc.
Water Supply Tube
1 pc.
Submersible Light
1 pc.
Transformer
1 pc.
Replacement Parts (not included)
Bulb:
MR-11 type halogen bulb,
12 volts, 10 watts maximum
Pump:
# HI-2000
Transformer: #48C-YL-12-12V
Contact Customer Service for
missing parts.
If the fountain ball, bowl, pedestal, or
basin are missing or damaged, the
unit must be returned to or
exchanged at the retailer.
Item #167009
Zen Oil Lamp Fountain
Questions, Problems, Missing Parts?
Before returning to retailer, please call customer service at (866) 728-6187 from
9am – 5pm (EST), Mon – Fri or e-mail customerservice@srg-usa.com.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
NOTE: Diagram for illustrative purposes only and not to scale. There may be
technical and design modifications to constantly improve this product.
Advertisement
Table of Contents
Related Manuals for Stone Art 167009
Summary of Contents for Stone Art 167009
- Page 1 Item #167009 Zen Oil Lamp Fountain Questions, Problems, Missing Parts? Before returning to retailer, please call customer service at (866) 728-6187 from 9am – 5pm (EST), Mon – Fri or e-mail customerservice@srg-usa.com. PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY. Unpack all parts from the carton to ensure there are no missing or damaged parts. If any parts are missing or damaged, do not attempt to assemble or use the product.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS When using electrical products, basic precautions should always be practiced including the following: 1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. 2. Read and follow all instructions that are on the product or provided with the product. 3. For a cord-connected or direct plug-in power unit, do not use an extension cord. 4.
- Page 3 ASSEMBLY INSTRUCTIONS Estimated assembly time: Approximately 15 minutes Assemble the fountain in the location you intend to use it. Do not move with water in the fountain. 1. Place the fountain basin on a flat, level surface and lead both pump power cord and light power cord through the cord slot on the underside of the basin.
- Page 4 CARE AND MAINTENANCE Keep the water clean and clean the fountain periodically to prevent mineral deposits and contamination which may clog the pump. Use a pre-filter on your pump if available. Regular cleaning of the pump will be necessary depending upon the environment in which it is operated. Clean the pump when it is visibly soiled or when a noticeable decrease in performance is detected.
- Page 5 GARDEN TORCH FUEL CANISTER INSTRUCTIONS: Filling: Unscrew flame guard and wick assembly from the fuel canister by turning in a counter-clockwise direction. Fill fuel container with citronella torch fuel (citronella torch fuel not included). Do not fill past line marked on canister.
