PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
Unpack all parts from the carton to ensure there are no missing or damaged parts. If any parts are missing or
damaged, do not attempt to assemble or use the product. Please contact customer service for replacement.
Carton Contents
Fountain Top
Basin
UL Listed Transformer
Low Voltage Halogen Lamps
UL Listed Pump
Inner Basin Cover
Spare Bulb
Replacement Parts (not included)
High Intensity Halogen Bulb: MR11 type halogen
12 volts, 10 watts maximum
UL Listed Pump: PT-505MIX
UL Listed Transformer: 57C.YL-25-12V
Please contact customer service for damaged or
missing parts
.
ITM./ART. 201570
Sedona Fountain
Any questions, problems, or missing parts?
Please do not return this product to the retailer.
Please call customer service at (866) 583-7034 from 8am – 10pm (EST), Mon. – Sat.
or e-mail customerservice@srg-usa.com.
1 pc
1 pc
1 pc
2 pcs
1 pc
1 pc
2pcs
NOTE:
Diagram for illustrative purposes only and not to scale.
Advertisement
Table of Contents
Related Manuals for Stone Art Sedona 201570
Summary of Contents for Stone Art Sedona 201570
- Page 1 ITM./ART. 201570 Sedona Fountain Any questions, problems, or missing parts? Please do not return this product to the retailer. Please call customer service at (866) 583-7034 from 8am – 10pm (EST), Mon. – Sat. or e-mail customerservice@srg-usa.com. PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY. Unpack all parts from the carton to ensure there are no missing or damaged parts.
- Page 2 ASSEMBLY INSTRUCTIONS Assemble the fountain in the location you intend to use it. Do not move with water in the fountain. Place the basin on a flat, level surface. Route the pump power cord out from the cord slot at the bottom of basin. Place the fountain top onto the center of basin making sure to align the tabs in the wedge plate before lowering it.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS FOR TRANSFORMERS When using electrical products, basic precautions should always be practiced including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS. Read and follow all instructions that are on the product or provided with the product. For a cord-connected or direct plug-in power unit, do not use an extension cord. Reference the National Electrical Code, ANSI/NFPA 70, specifically for the installation of wiring and clearances from power and lighting conductors.
- Page 4 SUBMERSIBLE LAMP BULB REPLACEMENT INSTRUCTIONS: 1. If a light bulb is burned out, unplug the transformer from the power source and allow a few minutes for the light bulb to fully cool before handling. 2. Remove submersible lamp form the basin lamp socket. 3.
