INDUSTRIAL HEATING
TECHNOLOGY
FOR MORE INFORMATION PLEASE SEE OUR HOME PAGES: WWW.PAKOLE.COM
Appliance type:
AIRFUSOR
AFR-0
AFR-1
AFR-2
AFR-3
AFR-SP
ATTENTION! Read and understand this manual thorougly before in-
stalling starting or servicing this equipment.The inproper installation or us-
ing can cause serious damages!Keep this mnual in a safe place in order to
obtain information in case of incidental problems!
GENERAL SAFETY NOTICES
Disregard of instructions and notices of this Manual can cause serious
bodily injuries or damages as follows: burning, explosion, suffocation, car-
bon monoxide poisoning, electric shock and in extreme case death!
This appliance can only be used and serviced by such persons who under-
stood and follow the instructions of this Manual
If you need help or information concerning the appliances – for example
installation guide or labels etc. – in that case contact with the manufacturer!
This appliance must not be used by children and mentally or sensitively de-
ficient persons! Take care that the children do not handle it and do not play
with devices!
FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU
Waterfan Heater
Instruction Manual
Ver.:01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pakole AIRFUSOR AFR-0
Summary of Contents for Pakole AIRFUSOR AFR-0
- Page 1 Waterfan Heater Instruction Manual INDUSTRIAL HEATING TECHNOLOGY FOR MORE INFORMATION PLEASE SEE OUR HOME PAGES: WWW.PAKOLE.COM Ver.:01 Appliance type: AIRFUSOR AFR-0 AFR-1 AFR-2 AFR-3 AFR-SP ATTENTION! Read and understand this manual thorougly before in- stalling starting or servicing this equipment.The inproper installation or us-...
- Page 2 Contents - WATERFAN HEATER FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
-
Page 3: Table Of Contents
5. Automatomatic control-installation 12ss Comfort panel description First start Turning off Operation Maintenance 6. Technical parameters heater 7. Electrical connection diagrams controlUTOMAL 22 8. Inetlligent automatic Programmable logic controller manual Controller programming 9. Maintenance 10. Guarantee terms and conditions FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 4: General Information
Pay special attention when working with electrical elements of the device. Any installation operations must be carried out by qualified persons with appropriate authorizations FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 5: Installer's Responsibilities
Data board The appliance is equipped with data board, which is placed on the outside of housing. On this data board there are information about type of appliance / gas and electrical connec- tion. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 6: Safety Signs
Qualified service engineers are those having specific technical experience and/or valid license in the field of heating and cooling installation for home and industry. In any case, call the Manufacturer office or the closest dealer (www.pakole.com) and ask for further informations. - Page 7 DANGER • Fans can reach a speed of 1000 rpm. Do not insert any object nor hands in the electric fan. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
- Page 8 • If you are going to leave the heater switched off for a long time, first make sure that in no way this could cause harm to anyone in ONLY any way. QUALIFIED PERSON FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
-
Page 9: Transportation, Unpacking, Handling 00
There is an envelope inside the unit containing the installation, use and maintenance manual and the warranty documents. The identification label bearing the following data is applied on each unit: • Manufacturer’s data • Model of the unit and Identification code • Technical data and Wiring diagram FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 10: Appliance Structure
*for temperatures of 90/70 and inlet temperature of O˚C **maximum height of assembly for vertical airflow, max working range of up to 380m². Horizontal range of isothermal stream at velocity boundary/speed limit of 0,5 m/s ***measurement obtained when 5 m away from the device FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 11: Assembly
0°, 30° or 60 °. A mounting bracket holder is made of curved profile. It has two holes for vertical assembly. Assembly to the wall and/or to the ceiling is possible at different angles but it requires making necessary holes in the holder. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... - Page 12 20mm. Mounting pins and connecting elements are not included with the unit. To sustain proper functioning of the device keep a safe dis- tance– 200mm from its sides and 300 mm from its backside (from the fan) FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
-
Page 13: Electrical Installation
• In case of any doubts or problems, unplug the device and contact the device’s installer or PAKOLE Trade Ltd. Authorized Service. Water installation The installation of the unit should be done in a way enabling maintenance service; on both stub pipes manual closing valves should be installed in order to cut off the device. - Page 14 INTELLIGENT Panel The system is ready to start once the connections between the thermostat and the valve actuator are done, 230V power is supplied to the thermostat and the fan’s motor is powe- red by the revs controller. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
-
Page 15: Comfort Panel Description
1.Set minimum temperature on thermostat – after 7 seconds valve will be clo sed and heating switched off. 2.Set main switch to the “0” position (off); fan will be switched off and the ther mostat will be off the power. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 16: Operation
NOTICE ! In case of any metallic knocks, vibration or increase in sound level check if the fan mounting/fixing does not work loose contact the installer or PAKOLE Trade Ltd. Authorized Service FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 17: Technical Parameters Heater
Manual - WATERFAN HEATER 6.Technical parameters heater AirFusor AFR-0 inlet/outlet water temperature 90/70 80/60 70/50 inlet air temperature air flow 4900 m3/h (speed 3) heat output 21,1 19,9 18,7 17,5 16,3 18,3 17,1 15,9 14,7 13,6 15,4 14,2 12,9 11,7 10,6 outlet air temperature ˚C... - Page 18 44,2 42,0 40,2 38,4 36,6 38,5 36,6 34,8 32,6 30,8 32,7 30,5 28,4 26,1 23,9 outlet air temperature ˚C 54,0 56,4 58,5 60,6 62,5 48,0 50,6 52,5 54,5 56,4 41,0 43,5 45,6 47,5 49,5 water flow m3/h pressure drop FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
- Page 19 29,6 27,4 25,3 23,6 22,0 25,3 23,1 20,9 19,3 17,6 20,9 19,0 17,1 15,2 13,2 outlet air temperature ˚C 39,7 41,4 43,7 47,5 50,5 34,1 37,4 40,7 44,0 47,1 31,1 33,0 36,6 39,9 43,3 water flow m3/h pressure drop FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
-
Page 20: Electrical Connection Diagrams
I-II-III and ON / OFF. The thermostat and switches HEAT / FAN / COOL remain not active. Additional jumper on terminals 4-5 might be applied when for ex different (supplied by user) thermostat is used to control the system. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... - Page 21 * The unit set does not consist of: a master switch, a fuse, a feeding cable Connection of HEATER unit with transformer speed regulator * When using transformer speed regulator please use only maximum speed connector on a fan - U1 high speed FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
- Page 22 (maximum extension of up to 10 MULTI 6 splitters). In such case, in the first Splitter MULTI 6 there should be connector DS-N left open, in other Splitters MULTI 6 (2..10) connector DS-N must be closed. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
-
Page 23: Programmable Logic Controller Manual
To switch on the heater, press .If the programmable controller is off, the OFF symbol will be displayed. When a controller is off, press and hold the button for 3 seconds and the configuration will start. Press to select menu function. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 24: Inetlligent Automatic Controlutomal
Error warning If any errors have occurred, one of the following messages will be displayed: LO – room temperature is below 0°C, HI – room temperature is higher than 50°C, ERR –electrical shorts or controller is damaged FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 25: Controller Programming
Heating, Cooling or Auto mode. Heating: the controller controls a system of heaters. Cooling: the controller controls a system of fans. Auto: the controller controls a system of heaters or fans depending on the outside temperature. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 26: Maintenance
(copper) as well as other ele- ments of the hydraulic system/circulation. The liquid must be diluted with water according to the solution recommended by the anti-freeze manufacturer. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... -
Page 27: Guarantee Terms And Conditions
- low temperatures on electrical and mechanical parts such as valves, electric and electronic controlling devices, - water condensation and frost/ice near the device, - thermal shock of the heater and heat exchanger caused by sudden changes of outside temperature. FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU... - Page 28 7. The Claimant is obliged to give a written confirmation of the service provided. 8. PAKOLE Trade Ltd. is entitled to refuse the warranty service if SONNIGER has not received full payment for the product complained about under the Guarantee or any previous servicing activities.
- Page 29 Unit number…………..……………………………………………………………………………....Purchase date….…………………………………………………………………………....... Startup date……… …………………………………………………………………………………....Installation company date: Name of startup Installer:………………………………………………………..........Company name..…………………………………………………………………………………...... …………………………………………………………………………………………………......Address:.……………………………………………………………………………..……………...... Phone..………………………………………………………………………………………………....Signature of startup installer……………..:……………………………………………………......Maitanance and repair registration: Maitanance and repair Stamp and signature of Date description installation company FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
- Page 30 PAKOLE TRADE Ipari és Kereskedelmi Kft. H-8000 Székesfehérvár, Börgöndi út 8-10. Honlap: http://www.pakole.hu E-mail: mail@pakole.hu Tel.: +36 22 316 484 Fax.: +36 22 316 074 FURTHER INFORMATION: HTTP://WWW.PAKOLE.HU...
