Cleveland
MODULAR BASES
MODULAR CABINET BASE
STEAM COIL STEAM GENERATOR
24" (600 MM) or 36" (900 MM) WIDE BASE
Cleveland Standard Features
I Type 430 Stainless Steel exterior enclosure and Table Top
I 6" Stainless Steel Legs with level adjustment with flanged
feet
I Solid State steam generator Water Level Controls
I Low Water Power Cut-off
I Pressure Limit Controls with 15 psi Safety Valve
I Major Components serviceable from the front of unit
I Steam Generator empties under pressure (blowdown)
automatically upon each Shut-Down. Automatic Water
Refill on Start-Up
I Separate "Start/Reset" Illuminated switch controls, plus
Pressure Gauge
I Steam Generator Drain incorporates Water Cooling and
"Jet/Rinsing"
I Steam Generator is complete with Access Hole/Cover Plate
and Sight Glass Gauge
I Secondary Low Water Cut-Off, factory installed (CALS)
(Required for AZ. AR. CA. CO. CT. DE. FL. GA. HI. IL. IA. KS. MD. MA. MI.
MN. MT. NE. NV. NM. NC. OK. OR. PR. RI. TN. UT. VA. WA. WV., Buffalo, NY,
Wash. DC)
I Standard voltage is 115 volt, 60 Hz, single phase
I Single cold water connection (no hot water required)
Options & Accessories
Ë Voltages for controls other than standard
Ë Stainless Steel Base Frame (FSS)
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900
Web Site: www.ClevelandRange.com
Fax: 1-216-481-3782
Email: Steam@ClevelandRange.com
MODEL:
24-SM
Short Form Specifications
Shall be CLEVELAND, Modular Cabinet Base with Steam Coil Steam
Generator Model _____ -SM. Type 430 Stainless Steel exterior enclosure,
Table Top and four Level Adjustable Legs. Console mounted controls,
Pressure Gauge and "Start/Reset" control switches.Solid State Water Level
Steam Generator Controls. Steam Generator drains under pressure (blow-
down) after each Shut-Down, Automatic Water Fill on Start-Up. 15 psi Safety
Valve.
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
