Cleveland 24-GM-K6-200 Specifications

MODULAR BASE WITH KETTLE(S)
200M BTU GAS-FIRED STEAM GENERATOR with NICKELGUARD™
ONE or TWO, 6 GALLON KETTLE(S)
CABINET BASE: 24" (600MM) or 36" (900MM) WIDE
Cleveland Standard Features
Factory assembled Kettle/Steam Generator NickleGard
Base combination with one or two,6 gallon kettles with
200M BTU Gas-Fired Steam Generator
Solid State steam generator Water Level Controls
Low Water Safety Cut-Off
Pressure Limit Controls with 15 psi Safety Valve
Type 430 Stainless Steel exterior enclosure, and table top
(with Drain Trough which has 1.50" diameter male drain),
#4 exterior finish
Type 304 Stainless kettle(s), #4 exterior finish
Separate "Start/Reset" Illuminated Switch Controls, plus
Pressure Gauge
Solid State Electronic Spark Ignition for energy savings
Major components serviceable from the front of the unit
6 gallon kettle(s) are 2/3 Steam Jacketed and include Lift
off Cover(s)
Hot and Cold Water Faucet with Swing Spout
Kettle(s) have 50 psi Steam Jacket Rating, 50 psi chrome
plated Safety Valve(s) and Manual Tilting, balanced design
Tilt Handles can be mounted on either side
Steam Generator empties under pressure (blowdown)
automatically upon each Shut-Down. Automatic Water
Refill on Start-Up
Standard voltage for controls is 115 volt, 60 Hz, single
phase
Adjustable Flanged Feet (FF-A)
Options & Accessories
Power Take-Off Kit (GPTO)
Secondary Low Water Cut-Off, factory installed (CALG)
(Required for AZ. AR. CA. CO. CT. DE. FL. GA. HI. IL. IA. KS. MD. MA. MI.
MN. MT. NE. NV. NM. NC. OK. OR. PR. RI. TN. UT. VA. WA. WV., Buffalo, NY,
Wash. DC)
Gas, other than natural
Type 316 Stainless Steel kettle interior for high acid food
products (316)
Food Strainers (FS)
Stainless Steel Base Frame (FSS)
300,000 BTU Gas-Fired Boiler with Nickelguard
Boiler Descaling Pump Kit (107142)
Cleveland Range LLC.
MODELS: 24-GM-K6-200
36-GM-K66-200
36-GM-K66-300
ITEM NUMBER __________________________________________
JOB NAME / NUMBER __________________________________
Short Form Specifications
Shall be CLEVELAND, Modular Cabinet Base with one or two, 6 gallon
kettle(s), Model _____ GM-K _____ -200, 200M Nickelguard BTU Gas-Fired
Steam Generator, type 430 Stainless Steel exterior enclosure, Table Top,
Back Splash and 4 level adjustable feet. 2/3 Steam Jacketed type 304
Stainless Steel kettle(s) with 50 psi Steam Jacket Rating; needle type
Steam Control Valve on each kettle. Console mounted Controls, Pressure
Gauge and Illuminated "Start/Reset" Control Switches. Solid State Water
Level Steam Generator Controls and Electronic Spark Ignition. Steam
Generator drains under pressure (blowdown) after each Shut-Down with
Automatic Water Refill on Start-Up. 15 psi Safety Valve
1333 East 179th St., Cleveland, Ohio, U.S.A. 44110
Ph: 1-216-481-4900 Fx: 1-216-481-3782
Visit our Web Site at www.clevelandrange.com
VII 21
SECT. PAGE
0402
