Cleveland 24-GM-200 Specifications

Gas-fired steam generator with nickelguard 200, 250 or 300m btu 24" (600mm) or 36" (900mm) wide base

Advertisement

Quick Links

Cleveland
MODULAR BASES
MODULAR CABINET BASE
GAS-FIRED STEAM GENERATOR with NICKELGUARD™
200, 250 or 300M BTU
24" (600MM) or 36" (900MM) WIDE BASE
Cleveland Standard Features
I Type 430 Stainless Steel exterior enclosure, Back Splash
and Table Top with #4 finish
I HInged Cabinet Door
I 6" Stainless Steel Legs with level adjustment and flanged
feet
I Solid State steam generator Water Level Controls
I Low Water Safety Cut-off
I Pressure Limit Controls with 15 psi Safety Valve
I Solid State Electronic Spark Ignition for energy savings
I Major components serviceable from the front of unit
I Nickelguard Steam Generator empties under pressure
(blowdown) automatically upon each Shut-Down. Automatic
Water refill on Start-Up.
I Separate "Start/Reset" Illuminated switch controls, plus
pressure Gauge
I Steam Generator Drain incorporates Water Cooling
and "Jet Rinsing"
I Insulated steam generator reduces heat loss to work area
I Gas Pressure Regulator
I Steam Generator is complete with Access Hole/Cover Plate
and Sight Glass Gauge
I Standard voltage for controls is 115 volt, 60 Hz, single
phase
I Single Cold water connection (no hot water required)
Options & Accessories
Ë Power Take-Off Kit (GPTO)
Ë Secondary Low Water Cut-Off, factory installed (CALG)
(Required for AZ. AR. CA. CO. CT. DE. FL. GA. HI. IL. IA. KS. MD. MA. MI.
MN. MT. NE. NV. NM. NC. OK. OR. PR. RI. TN. UT. VA. WA. WV., Buffalo, NY,
Wash. DC)
Ë Gas, other than natural
Ë Insulated Flue for island installation
Ë Stainless Steel Base Frame (SSF)
Ë Boiler Descaling Pump Kit (107142)
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900
Web Site: www.ClevelandRange.com
Fax: 1-216-481-3782
Email: Steam@ClevelandRange.com
MODELS:
24-GM-200
Short Form Specifications
Shall be CLEVELAND, Modular Cabinet Base, Model _____ -GM _____ M,
Nickelguard, BTU gas generator, type 304 Stainless Steel Exterior enclosure,
Table Top and 6" Level Adjustable Legs. Console mounted controls,
Pressure Gauge and Illuminated "Start/Reset" control switches. Solid State
Water Level Steam Generator Controls. Steam Generator drains under pres-
sure (blow-down) after each Shut-Down, Automatic Water Fill on Start-Up. 15
psi Safety Valve.
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
36-GM-300
VII
SECT.
PAGE
0707
3
