Cleveland 24-EM-24 Specifications

Modular cabinet base electric steam generator 24, 36 or 48 kw 24" (600mm) or 36" (900mm) wide base

Advertisement

Quick Links

Cleveland
MODULAR BASES
MODULAR CABINET BASE
ELECTRIC STEAM GENERATOR
24, 36 or 48 KW
24" (600MM) or 36" (900MM) WIDE BASE
Cleveland Standard Features
I Type 304 Stainless Steel exterior enclosure; TableTop with
#4 finish
I Hinged Cabinet Door
I 6" Stainless Steel Legs with level adjustment
I Solid State Steam Generator Water Level Controls
I Low Water Power Cut-off
I Pressure Limit Controls with 15 psi Safety Valve
I Major components serviceable from the front of the unit
I Steam Generator empties under pressure (blowdown)
automatically upon each Shut-Down. Automatic Water
Refill on Start-Up
I Separate "Start/Reset" illuminated switch controls, plus
Pressure Gauge
I Steam Generator Drain incorporates Water Cooling and
"Jet Rinsing"
I Steam Generator is complete with Access Hole/Cover Plate
and Sight Glass Gauge
I Secondary Low Water Cut-Off, factory installed (CALE)
(Required for AZ. AR. CA. CO. CT. DE. FL. GA. HI. IL. IA. KS. MD. MA. MI.
MN. MT. NE. NV. NM. NC. OK. OR. PR. RI. TN. UT. VA. WA. WV., Buffalo, NY,
Wash. DC)
I Standard voltage is 208/220 volt, 60 Hz, 3 Phase,
3 Wire
I Single cold water Connection (no hot water required)
Options & Accessories
Ë Power Take-Off Kit (EPTO)
Ë Voltages other than standard, including: 220/240, 440/480,
575 volt
Ë Single Phase operation (24 KW only)
Ë 10" Adjustable Legs (LF10)
Ë Flanged Feet (FF)
Ë Stainless Steel Base Frame (FSS)
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900
Web Site: www.ClevelandRange.com
Fax: 1-216-481-3782
Email: Steam@ClevelandRange.com
MODELS:
24-EM-24
24-EM-36
24-EM-48
Short Form Specifications
Shall be CLEVELAND Model _____ -Em _____ KW Electric Steam Generator,
Modular Cabinet Base, type 304 Stainless Steel exterior enclosure, Table
Top and 6" Level Adjustable Legs. Console mounted Controls, Pressure
Gauge and Illuminated "Start/Reset" Control Switches. Solid State Water
Level Steam Generator Controls. Steam Generator drains under pressure
(blowdown) after each Shut-Down, Automatic Water Fill on Start-Up.15 psi
Safety Valve.
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
36-EM-24
36-EM-36
36-EM-48
VII
SECT.
PAGE
0707
1
