ClearCube I8442 Quick Start Manual

I8442 I/Port
Power Button
Wireless Local
Loop Indicator
(WLL Optional
Feature)
Pedestal
Line Out
Line In
10/100/1000
Mbps Ethernet
COM Port 2
COM Port 1
VGA
PS/2 Mouse
ClearCube Technology
Quick Start Guide
ClearCube® I8442 I/Ports are thin clients that enable users to
access remote computing devices, such as ClearCube blades or
other computing resources.
The I8442 package contains:
• I8442 I/Port thin client
• I8442 pedestal
• This quick start guide
Smartcard
• Mouse (if ordered; consult your shipping invoice)
Reader
• Power cord appropriate for your country
(Optional Feature)
This guide describes how to set up the I8442 I/Port thin client. See
support.clearcube.com
• Sentral User's Guide describes how to use ClearCube Sentral
to manage thin client connection brokering.
• XLmanage Installation Guide and XLmanage User's Guide
describe how to perform basic I8442 configuration and
administration tasks.
USB 2.0 Ports
Safety and Precautions
• Do not install the thin client in areas where it can become wet
or be exposed to water.
• Only use the power cord shipped with the thin client.
• Ensure there is four inches of space surrounding the thin client.
Inadequate ventilation can damage the unit.
• Ensure the thin client is always vertical and inserted in the
included pedestal.
Microphone
Setting up Your I8442 Thin Client
USB 2.0 Ports
1. Carefully unpack the I8442 and components. Ensure that you have
Parallel Port
the following items:
•
•
•
DVI-I
•
PS/2 Keyboard
2. Place the I8442 on a desktop.
3. Connect a keyboard and moue to the thin client. As shown in the
figures, USB ports are located on the front and rear of the I8442
AC Power In
and PS/2 ports are located on the rear.
4. Establish a network connection between the thin client and the
remote computing device by performing one of the following:
–
8834 Capital of Texas Hwy N Austin, Texas 78759
for the following additional information:
Power cord included with the thin client
Mouse to connect to the I8442
Keyboard to connect to the I8442
Monitor to connect to the I8442
Connect the network cable (RJ-45) to the Ethernet port on
the rear of the thin client.
—OR—
voice 512 652 3500 www.clearcube.com
