- Page 1 SHOVEL FLUID SECTION 60 cm Pump REXSH0060 User Manual 582136110 2020-10-27 Index A Translation of the original instructions SAMES KREMLIN SAS 13 Chemin de Malacher 38240 Meylan www.sames-kremlin.com 33 (0)4 76 41 60 60...
- Page 2 Any communication or reproduction of this document, in any form whatsoever, and any exploitation or communication of its contents are prohibited, except with the express written consent of SAMES KREMLIN. The descriptions and features contained in this document are subject to change without notice.
-
Page 3: Table Of Contents
Contents Evolution table of the document ..........................5 Guarantee ..................................6 DECLARATION OF CONFORMITY ......................7 SAFETY INSTRUCTIONS ..........................8 ............................8 ERSONAL SAFETY Overview ..................................8 Meaning of the pictograms ............................9 Security devices ................................. 10 Danger of Pressure ..............................10 Injection hazards ................................ - Page 4 Wet Cup ..................................28 Tightening of the Wet Cup ............................28 Tightening procedure ..............................28 ..........................29 AFETY IN PRODUCTION ..............................29 TART UP ..........................30 HUTDOWN PROCEDURE Pump ..................................30 ....................31 IAGNOSTIC HELP ROUBLESHOOTING GUIDE Possible symptoms of faults / Causes of faults / Remedy to be applied ..............31 MAINTENANCE ............................
-
Page 5: Evolution Table Of The Document
Evolution table of the document Recording revisions Editor Object Revision Date Modified by SEGUIN Shovel fluid section 12/05/2020 60 cm REXSH0060 Dear customer, you have just purchased your new equipment and we thank you for it. We have taken the utmost care, from design to manufacture, so that this equipment gives you complete satisfaction. -
Page 6: Guarantee
The warranty excludes wear parts, deterioration or wear resulting from abnormal or unscheduled use by SAMES KREMLIN, failure to observe instructions for proper operation or lack of maintenance. -
Page 7: Declaration Of Conformity
Declaration of Conformity 1 Declaration of Conformity Refer to the existing declaration delivered with the product. 582136110-SH0060-indA-EN.docx 27/10/2020... -
Page 8: Safety Instructions
It must be used only for the purpose for which it was intended. Do not modify or transform the material. Parts and accessories must only be supplied or approved by SAMES KREMLIN. The equipment must be checked periodically. Defective or worn parts must be replaced. -
Page 9: Meaning Of The Pictograms
Safety instructions Meaning of the pictograms Danger pinching, Danger : high Danger moving parts Risks of product crushin pressure emanation Danger : hot parts or Danger : flammability Risk of explosion Danger : electricity surfaces risks Danger (user) Gloves required Warning Danger Grounding Protective helmet... -
Page 10: Security Devices
Safety instructions Security devices Attention Guards (motor cover, coupling guard, housings, ...) are set up for safe use of the equipment. The manufacturer cannot be held responsible for any bodily injury as well as failures and / or damage to the equipment resulting from the destruction, the occultation or the total or partial removal of the protectors. -
Page 11: Injection Hazards
Safety instructions Injection hazards "HIGH PRESSURE" technology requires the utmost care. Operation can cause dangerous leaks. There is a risk of product injection into exposed parts of the body, which can lead to serious injury and the risk of amputation : ... -
Page 12: Hazards Of Toxic Products
Safety instructions Hazards of toxic products Toxic products or vapors can cause serious injury through contact with the body, in the eyes, under the skin, but also by ingestion or inhalation. It is imperative : To know the type of product used and the dangers it represents, ... -
Page 13: Integrity Of The Material
Safety instructions 2.2 Integrity of the material Material recommendations Protectors are put in place for safe use of the equipment. The manufacturer cannot be held responsible in case of: Bodily injury. As well as breakdowns and / or damage to the equipment resulting from the destruction, the misuse or the total or partial withdrawal of the protectors. -
Page 14: Products Implemented
It will determine the risks of immediate reactions or due to repeated exposures to the staff. SAMES KREMLIN declines any responsibility, in case of: Bodily or psychic injuries. Direct or indirect material damage due to the use of chemical substances. -
Page 15: Environment
Environment 3 Environment The equipment must be installed on a horizontal, stable and flat ground (eg concrete slab). Non-moving equipment must be fixed to the ground by suitable fasteners (spit, screws, bolts, ...) to ensure their stability during use. To avoid risks due to static electricity, the equipment and its components must be grounded. - Page 16 Environment Material marking Each device is equipped with an identification plate with the name of the manufacturer, the reference of the device, important information for the use of the device (pressure, power, ...) and sometimes against the pictogram shown below. The equipment is designed and manufactured with high quality materials and components that can be recycled and reused.
-
Page 17: Available Configurations
Available Configurations 4 Available Configurations Rexson parts number of High Viscosity Pumps Presentation of the pompe REXSH0060 A very versatile pump, the REXSH0060 hydraulic is used for airless applications as well as for the extrusion of thick products (>50000 cP*). Different configurations are available. - Page 18 Available Configurations 4.1 Table 1 Fluid Section-Air Motor Selection Available Motors (MO) Pressure Ratio Maximum Air Inlet Maximum Outlet Pressure Fluid Pressure NONE MOTOR 1500 31 : 1 2700 MOTOR 3000 62 : 1 5400 4.2 Table 2 Fluid Section – Pump Foot Selection Available foot pump (FO) Available material (MA) SS : Stainless steel...
-
Page 19: Identification
Identification 5 Identification 5.1 Description of the marking of the plate Principles This equipment complies with the following provisions: Machinery Directive (2006/42 / EC), Low Voltage Directive 2006/95 EEC EMV Directive 2004/108 EEC Safety of machinery - Basic terms, general implementation guidelines DIN EN ISO 12100 T1/T2 ... - Page 20 Identification Description SAMES KREMLIN Manufacturer's mark STAINS FRANCE POMPE / PUMP Pump reference and serial number. The first two digits indicate the year of manufacture. REF / SERIE PROD Maximum product pressure (Bar/Psi) MAX. PRES. (Bar/Psi) Maximum air pressure (Bar/Psi)
-
Page 21: Technical Characteristics And Performance
Technical characteristics and performance 6 Technical characteristics and performance 6.1 General characteristics Technical characteristics Volume per 60 cm cycle 2,03 oz Stroke 120 mm / 4,72 in Fluid outlet 3/4" connections F BSPP Weight 8 kg / 17,6 lb Maximum fluid 80°C / 176°F temperature Wetted parts... - Page 22 Technical characteristics and performance (General characteristics - continued) Pump Foot (FO) Technical characteristic Follower Plate Ø 80 mm Drum Bung mounted 60 Liters Drum Bung mounted 200 Liters Drum Materials of construction (MA) Stainless steel Mixed steels Pump body Wet Cup Stainless steel Stainless steel Upper body...
-
Page 23: Principle Of Operation
Technical characteristics and performance 6.2 Principle of operation Expected use These pumps coupled to air or hydraulic motors are intended for transferring, transferring or spraying different liquid or pasty products with a desired flow rate and output pressure. Functional description When the piston (1) rises, the upper flap (2) closes, the lower flap (3) opens and the pallet (4) closes. - Page 24 Technical characteristics and performance ATTENTION! The friction generated by the movement of the product inside the pump and its accessories, as well as that caused by the seals, creates static electricity that can cause fire or explosion. Therefore, the fluid section system must be earthed via the motor ground cable (see the motor instruction manual for its ground connection).
-
Page 25: Installation
(pneumatic or hydraulic) compatible race. It is imperative to comply with an air motor / hydraulic combination provided by SAMES KREMLIN Make sure that all connections of the pump and fluid section components - cables, hoses and pipes - are installed in such a way that they do not cause people to fall. -
Page 26: Air Supply Connection
Installation 7.2.2 Air supply connection Ensure that in bound air supply and hose are of correct size to reduce pressure fluctuations and pressure drops. 7.3 Storage Pump Place the equipment away from moisture after closing the various air inlets and various openings (plugs). Storage before installation: ... -
Page 27: Commissioning
Commissioning 8 Commissioning The fluid sections are integrated in a system, if necessary refer to any additional instructions for further information on commissioning. Pump Pumps are tested for operation at the factory using a light weight oil lubricant. Before commissioning, this lubricant must be removed by flushing with a suitable solvent. -
Page 28: Use Of The Product
Use of the product 9 Use of the product 9.1 User settings Wet Cup Before commissioning, fill the wet cup halfway with lubricant "T". The wetting cup nut must be tightened moderately. Overtightening quickly damages the gland packing. A wrench is supplied to allow proper tightening. -
Page 29: Safety In Production
Use of the product 9.2 Safety in production Guards (motor cover, coupling guard, housings, ...) are set up for safe use of the equipment. The manufacturer can not be held responsible in case of bodily injury as well as breakdowns and / or damage of material resulting from... -
Page 30: Shutdown Procedure
Use of the product 9.4 Shutdown procedure Pump To avoid the risk of personal injury, material injections, injuries caused by moving parts or electric arcs, it is imperative that the following procedure be followed before any work is carried out when shutting down the system, assembling, cleaning or changing the nozzle. -
Page 31: Diagnostic Help / Troubleshooting Guide
Use of the product 9.5 Diagnostic help / Troubleshooting guide Possible symptoms of faults / Causes of faults / Remedy to be applied Defaults Possible causes Remedies Leakage at the cup seals Insufficient tightening of the Tighten the cup. packing nut Incorrect assembly of seals Check the assembly. - Page 32 Use of the product Defaults Possible causes Remedies Pump strokes quickly Bad feeding of the pump. Check parameters downward (simple effect accessories (pressure follower working) plate or suction rod,…). Accessories can be not adapted or clogged. Product is too viscous. Bad definition of the pump.
-
Page 33: Maintenance
If the information given here does not solve the problem you are experiencing, please contact your local SAMES KREMLIN representative for assistance. During prolonged shutdown, stop the pump when the piston is in the low position. -
Page 34: Preventive Maintenance Plan
Maintenance 10.1 Preventive Maintenance Plan ATTENTION Before pump maintenance service work performed imperative follow depressurization procedure and the safety instructions. Routine maintenance after certain number operating hours is recommended. This is defined by the service department of the user and depends on the product, the working cycle and the usual pressure. -
Page 35: General Preconisation Maintenance
Maintenance 10.2 General preconisation maintenance ATTENTION Before pump maintenance service work performed imperative follow depressurization procedure and the safety instructions. Before each reassembly Clean the parts with the appropriate cleaning solvent. Fit new seals if necessary, after greasing them. ... -
Page 36: Disassembly / Reassembly Operation
Disassembly / Reassembly Operation 11 Disassembly / Reassembly Operation ATTENTION Before pump maintenance service work performed imperative follow depressurization procedure and the safety instructions. ATTENTION The equipment is subject to the ATEX directive and must not be modified under any circumstances. Failure to comply with this recommendation does not engage our responsibility. - Page 37 Disassembly / Reassembly Operation (For a full description of spare parts, see Part 12 - Spare Parts) 582136110-SH0060-indA-EN.docx 27/10/2020...
- Page 38 Disassembly / Reassembly Operation (For a full description of spare parts, see Part 12 - Spare Parts) 27/10/2020 582136110-SH0060-indA-EN.docx...
-
Page 39: Disassembly Of The Pump
Disassembly / Reassembly Operation Disassembly of the pump Unscrew the 2 nuts (13) and put aside the flange (1), the tie rods (14) and the protection (4), Clamp the pump horizontally through the body with a vice (7), ... -
Page 40: Upper Valve
Disassembly / Reassembly Operation Upper valve - Unscrew the nut (23) and the shovel rod (31), - Unscrew the piston valve (22), - Unscrew the piston bush (20) and remove the piston nut (16), the male washer (17), the piston seals (18) and the female washer (19), ... -
Page 41: Reassembly Of The Fluid Section
Disassembly / Reassembly Operation Reassembly of the fluid section : Lubricate the wetting cup seals and the piston head seals, Locate the seals (9) inside the pump body (7) of the valve body (21) (and of the extension (45) for the pump, model ... -
Page 42: Spare Parts
Spare parts 12 Spare parts Use only genuine SAMES KREMLIN accessories and spare parts designed to withstand the pump's operating pressures. WARNING: these parts are not supplied with the fluid section alone as they depend on the engine. 27/10/2020 582136110-SH0060-indA-EN.docx... - Page 43 Spare parts WARNING: these parts are not supplied with the fluid section alone as they depend on the engine. 582136110-SH0060-indA-EN.docx 27/10/2020...
-
Page 44: Parts
Spare parts Parts REXSH0060-- REXSH0060-- REXSH0060-- REXSH0060- CS FP- -D1- -D2- -SS-FP- Ind. Description # Ref. Spare part level** Connection flange See motor coupling kit table Protection See motor coupling kit table Wetting cup nut 044 200 005 'F' washer See repair kit table Pump body 209 603... -
Page 45: Lower Adapter Flange
Depending upon choice - refer to table (Ind. 9, 11, 18, 26, 36, Seal kit 41, 42) * Recommended maintenance parts N S : Denotes parts are not serviceable ** Specific parts (see motor configuration) - contact SAMES KREMLIN in case of need Lower adapter flange Spare part Ind. Description # Ref. -
Page 46: Repair Kit
Spare parts Repair Kit Spare part Ind. Description # Ref. level** Repair kit 105 436 'F' washer 209 614 'M' washer 209 615 'M' washer 209 672 'F' washer 209 671 'M' washer 209 674 ... -
Page 47: Seal Kits Composition - Pump Rexsh0060----01 To 03
Spare parts Seal Kits composition – Pump REXSH0060----01 to 03 REXSH0060----01 REXSH0060----02 REXSH0060----03 # FLUID SECTION Kit: 105 275 105 276 105 277 Ind. Description Material Material Material O-Ring 84 180 84 393 FKM / FEP 84 180 209 616 PTFE 209 616 PTFE... -
Page 48: Seal Kits Composition - Pump Rexsh0060----04 To 06
Spare parts Seal Kits composition – Pump REXSH0060----04 to 06 # FLUID SECTION REXSH0060----04 REXSH0060----05 REXSH0060----06 Kit: 105 278 105 279 105 312 Ind. Description Material Material Material O-Ring 84 180 84 180 84 180 LEATHER 209 618 209 619 PTFE G 84 409 209 617...
