- Page 1 SureTouch Refrigerated Liquid Dispensers Operations Manual D-19-032RevD...
-
Page 3: Table Of Contents
Cleaning and Maintenance ....... 12 Recommended Cleaning Schedule..12 Exterior and Splash Panel ..... 12 Button Panel .......... 12 Catch Tray and Screen ......13 SureShot Technical Assistance Center Valve Area ..........13 1-888-777-9990 or 902-865-9602 Product Compartment ......13 Product Case ......... 13 service@sureshotdispensing.com... -
Page 5: The Dispenser
FlexoShot dispensers use a manually operated lever to deliver product in the quantity desired. AC220-FP – FlexoShot with optional Fill-In-Place shown (Dispenser may not be exactly as shown) SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 6: Main Components
Dispense Handle (FlexoShot only) Splash Panel Side Console Power Switch Circuit Breaker 4" Legs with Adjustable Feet AC220-FP FlexoShot with optional Fill-In-Place shown (Dispenser may not be exactly as shown) SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 7: Specifications
(24) hours. Your immediate inspection and reporting protects you against loss. Notify SureShot Dispensing Systems® within twenty-four (24) hours of any damage claims. No returns will be accepted without prior approval. Obtain an authorized return number by contacting the SureShot Technical Assistance Center at 1-888-777-9990 or 902-865-9602. -
Page 8: Electrical Requirements
The temperature control has been pre-set at the factory. You can feel the cold temperature by placing your hand on the top or back wall inside the product compartment. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 9: Delivery System Preparation
5. Fill the cleaned, sanitized tank to the full line with pre- chilled product. (Optional with Fill-in-Place. Filling may be performed once the tank is in the product compartment.) 6. Install lid. Tanks – Step SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 10: Load Product
6. Close the dispenser lid. 7. Close the product compartment door. 8. Reset product level with IntelliShot dispensers. See Reset Product Level – IntelliShot (Portion Controlled) Fill-In-Place Dispensers on page 7. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 11: Reset Product Level - Intellishot (Portion Controlled) Fill-In-Place Dispensers
Dispenser returns to normal operating conditions after three (3) seconds of inactivity. FlexoShot (Manually Operated) Dispensers 1. Place cup under dispense point of desired product. 2. Press lever down until desired portion is dispensed. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 12: Button Panel
An LED above each product selection button starts to flash when product is getting low. Lockout Indicator (Optional) An LED above each product selection button illuminates indicating product is empty or is locked out for cleaning. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 13: Lcd Display
3. Press the Adjustment Up or Adjustment Down button until desired language is displayed. 4. Press and hold the Program Mode button until beeps are heard to exit Program Mode. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 14: Side Console Functions
2. d1 will display for three (3) seconds and temperature will remain on the Temperature Display Window confirming Continuous Display Mode is active. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 15: Side Console Display Window
5. Wait four (4) to six (6) hours for the new temperature to stabilize. If the product temperature is still not correct, repeat steps 1 through 5. Note: Do not adjust temperature setting more than three (3) times. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 16: Cleaning And Maintenance
3. Rinse using a soft cloth dampened with warm, clean water. 4. Dry thoroughly with a soft cloth. 5. Button panel will automatically enable and return to normal operating mode after several seconds (up to 30). SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 17: Catch Tray And Screen
4. Wash in hot water (minimum 140 °F/60 °C) with a good quality cleaner. Wash thoroughly to reach all corners and crevices. 5. Rinse well with warm, clean water. 6. Dry thoroughly with a soft cloth or air dry. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 18: Product Tanks And Lids
Wipe dry with a soft cloth to prevent water spotting. 7. Remove the screw at the top of the metal valve insert. Step 7 Clean valve insert and screw and keep for reuse. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... - Page 19 Wipe dry with a soft cloth to prevent water spotting. 7. Remove the screw at the top of the metal valve insert. Wipe screw and valve insert clean and keep for reuse. Step 7 SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602...
-
Page 20: Door Gasket
4. Rinse using a soft cloth dampened with warm, clean water. 5. Dry thoroughly with a soft cloth. 6. Close product compartment door. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 21: Condenser
5. Install or replace with new transparency and repeat steps in reverse order, taking care not to pinch cable next to hinge. Step 3 Step 4 SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 22: Troubleshooting
7. Ensure all steps for “Dispenser does not turn on” above are followed. If dispenser still does not dispense product, contact the SureShot Technical Assistance Center at 1-888-777-9990 or 902-865-9602. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... - Page 23 4. Check that the condenser is not dirty. See page 17. 5. Check that the fan is operating. See page 17. If dispenser remains unusually warm, contact the SureShot Technical Assistance Center at 1-888-777-9990 or 902-865-9602. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602...
- Page 24 Red light in a product Lockout Indicator (Optional) selection button An LED embedded in each product selection button illuminates remains on indicating product is empty or is locked out for cleaning. SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602...
-
Page 25: Wiring Diagram
WIRING DIAGRAM SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... -
Page 26: Service And Warranty
This will save you time. Reshipment If packaging is not available, it may be purchased from the SureShot Parts Department by calling 1-888-777-9990 or 902-865-9602. Ensure pieces which may shift in transit are secured using masking tape. -
Page 27: Usa And Canada Warranty
EQUIPMENT INC. IN NO EVENT DOES THE LIMITED WARRANTY EXTEND BEYOND THE TERMS STATED HEREIN. A.C. Dispensing Equipment Inc. 100 Dispensing Way Lower Sackville Nova Scotia, Canada B4C 4H2 1-888-777-9990 or 1-902-865-9602 www.sureshotdispensing.com 15/08/2014 SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602... - Page 28 A.C. Dispensing Equipment Inc. 100 Dispensing Way Lower Sackville Nova Scotia, Canada B4C 4H2 1-888-777-9990 or 1-902-865-9602 www.sureshotdispensing.com SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602...
