Unic MIRA User Manual

TECHNICAL CHARACTERISTICS
DIMENSIONS cm MIRA TWIN MIRA
Width 34 64
Height 51 51
Depth 57 57
Weight kg 39 55
WATTAGE Mono only
110V mono 1.7 Kw -
200V mono 2.3 Kw 3.5 Kw
(option 2.3)
220V mono-380V tri+N 2.7 Kw 4.3 Kw
(option 2.7)
230V mono-400V tri+N 3 Kw 4.7 Kw
(option 3)
240V mono-415V tri+N 3.2 Kw 5.1 Kw
(option 3.2)
Safety advices
- This appliance is not intended for use by persons (includind children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of appliance by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with the
appliance.
- This appliance is intended to be used only for its specific purpose.
The manufacturer shall not accept any liability for damages due to improper
or wrong use.
- Access to the service area is restricted to persons having safety and
hygiene knowledge with practical experience of the appliance.
- Before plugging in or unplugging the power cord, place the main switch to
position 0.
- If the power cord is damaged, it must be replaced by the manufacter, its
service agent or similar qualified persons in order to avoid a hazard.
- For electrical safety, be sure the appliance is correctly earthed.
The manufacturer shall not accept any liability for damage due to faulty earth.
- Only a qualified technician is allowed to access the internal parts of the
appliance for maintenance and service operation.
TRI MIRA QUATTRO MIRA ADJUSTEMENTS
86 108 Temperature
51 51 Steam Pressure
57 57 Pump Pressure
76 96 HP Valve
LP Valve
- - Dose of ground
coffee
3.5 Kw 5.2 Kw Dose of water
4.3 Kw 6.3 Kw Infusion time
4.7 Kw 6.8 Kw
5.1 Kw 7.5 Kw
- Be careful of hot surfaces such as: cup warmer, group heads, hot water
and steam outlets.
- Do not expose oneself to steam or hot water flow.
Important notes
- This appliance is intended to be:
• Placed on an horizontal and stable surface
• Used in an ambient temperature between 5°C and 35°c
(41°F-95°F).
• Installed to comply with the national rules that may be applicable.
• Connected to a water system with pressure ranging from 1 to 8 bar
(0.1 to 0.8 Mega pascal)
- Before connecting the electrical supply, verify that the electrical network
comply with the data plate of appliance.
- For more details about installation, adjustments and connections, please
refer to the installation guide or the technician guide.
- This appliance must not be exposed to water jet or splash.
- Be careful not to block the air inlets with towels or other items.
- If the appliance has to be stored with ambient temperature less than 5°C
(41°F), the water circuit (boiler-pipes) should be emptied.
Z.I. 4e RUE - BP. 425
ww.unic.fr
06515 CARROS CEDEX 1 - FRANCE
info@unic.fr
Tel: (33) 04 92 08 62 60
Fax: (33) 04 93 29 24 23
118 à 120°C
0.9 à 1 bar
9 bar
13 bar
(8 bar MIRA)
3.2 bar
7 GR
5 à 7 cl
20 à 25s
Thank you for choosing UNIC, the first French manufacturer
of professional espresso machines since 1919.
The manufacturer reserves the right to modify the
appliances presented in this publication without notice.
Read carrefully the safety instructions before use.
