GYS GYSPOT 2600 Manual

GYSPOT 2700
STEEL DENT
PULLING
Ref. 055353
EQUIPMENT
The GYSPOT 2700, with its 2600A maximum output is the ideal product for dent pulling and
straightening of low thickness car body elements (bonnet, door, roof panel etc.) The product is
multifunctional, and effective for many applications. With its low power consumption, it can work on
a simple 230V power supply.
A MULTIFUNCTIONAL DENT PULLER
4 modes available :
• Welding of stars and washers for panel pulling.
• Wavy wire welding, ideal for a curved profile (e.g.
wheelarch)
• Contact shrinking, to work on light impacts and for
the highest quality finish.
• Able to use a graphite pencil.
EASY TO USE
• Switch to go to graphite pencil mode.
• Intuitive, the control knob enables selection of both
the output power and the requested mode.
• Manual, the weld is controlled by simply a light press
of the gun trigger.
DELIVERED AS A STANDARD WITH:
• 1 spot inertia hammer (1,1kg)
and 1 star holder tip.
• 3 stars
• 1 contact shrinking tip
• 1 earth pad
50/60hz 50/60hz
230V 1~ 230V 1~
16/09/2016
U U
I I 2 2
2 max 2 max
A A
V V
2600 2600 Manual Manuel 5,4 5,4
- EN 60974-1
OPTION:
Trolley
Spot 600
Ref: 053533
Spotter Box 2700
Ref: 053922
I I
RMS RMS
A A
A A
16 16 1800 1800 OK OK
Cables length
Power supply: 2 m
Earth: 1.7 m
Trolley
Spot 800
Ref: 051331
cm cm kg kg
20x32x18 20x32x18 14 14
MADE in FRANCE
www.gys.fr
Gun: 1.8 m
