ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3720PT-3PK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Not Included)
Rev: 19-07-11
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3720PT-3PK
Summary of Contents for Furniture of America CM3720PT-3PK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3720PT-3PK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc x 2 #A x 24pcs Seat Bolt Ø1/4" x 2" #2 x 2pcs x 2 #B x 2pcs Right Leg Bolt Ø1/4"...
- Page 4 #11 x 2pcs #9 x 1pc Back Leg (Right ) Short Stretcher #10 x 1pc Long Stretcher Page 4 of 7...
- Page 5 Align legs (#2,3) with stretchers (#4) and seat (#1), then secure legs (#2,3) to seat (#1) by using bolts (#A) with washers (#D,E). # A x 8pcs #D x 8pcs #E x 8pcs Secure stretchers (#4) on legs (#2,3) by using screws (#C). # C x 8pcs Page 5 of 7...
- Page 6 Align long stretcher (#10) to table legs (#6,7), then secure by using bolts (#B) with barrel nuts (#F). # A x 4pcs # B x 2pcs #D x 4pcs #E x 4pcs #F x 2pcs Align table legs (#6,7) to the table (#5), then secure by using bolts (#A) with washers (#D,E).
- Page 7 Secure the stretchers (#11) by using screws (#C). # C x 4pcs ASSEMBLY IS COMPLETED Page 7 of 7...
