General International 10-810 Operating & Maintenance Instructions

Two stage dust collector
Hide thumbs

Advertisement

Quick Links

Download this manual
•Excellent for collecting the large chips which will drop into
the garbage can before reaching the impeller.
•The filter bag filters out the remaining sawdust down to
5 microns.
•With the cyclone effect fitting onto a standard garbage can
there is no longer a need to dump the chips and dust from
the collection bag to a disposable bag.
•Simply set the garbage can on the curb with the lid to be
emptied.
•5 micron filter bag as standard accessory.
•45 gallon (55 gallon U.S.) drums not included.
•Overall height 121
1 ⁄
" (3080 mm).
4
• Mobile base for garbage can included.
FEATURES
AIR SPEED
AIR DELIVERY
AIR FLOW CAPACITY
AIR SUCTION
FILTER BAG
SPACE OCCUPIED
PACKING SIZE
MOTOR
NET WEIGHT
GROSS WEIGHT
SPECIFICATIONS
41 M/SEC
80 M
3
/MIN
2800 CFM
8" ( 203 mm) x 1 hole
Ø24" x 70 7/8" (Ø610 x 1800 mm)
64" x 55" x 110 1/4" (1630 x 1400 x 2800 mm)
51" x 34 1/4" x 28 3/8" (1300 x 870 x 720 mm)
3 HP
550 LBS (250 Kg)
616 LBS (280 Kg)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 10-810 and is the answer not in the manual?

Questions and answers

Related Manuals for General International 10-810

Summary of Contents for General International 10-810

  • Page 1 FEATURES SPECIFICATIONS 41 M/SEC AIR SPEED •Excellent for collecting the large chips which will drop into AIR DELIVERY 80 M /MIN the garbage can before reaching the impeller. AIR FLOW CAPACITY 2800 CFM •The filter bag filters out the remaining sawdust down to 8"...
  • Page 2 GENERAL ® INTERNATIONAL guarantee All component parts of GENERAL INTERNATIONAL machinery are carefully inspected during all production stages and each machine is thoroughly inspected upon completion of assembly. Because of quality, GENERAL INTERNATIONAL agrees to repair or replace any genuine part or parts which, upon examination, proves to be defective in workmanship or material within a period of 24 months from date of purchase.In order to obtain warrantee, all defective parts must be returned pre-...

  • Page 3: Unpacking And Assembly

    2 STAGE DUST COLLECTOR 10-810 GENERAL® INTERNATIONAL 2-Stage Dust Collectors are carefully tested and inspected before shipment and if properly used will give perfect results. However, a reasonable amount of care and attention is necessary to ensure perfect performance and accurate work.
  • Page 4 OPERATIONS Note: This dust collector may produce a slight odor for the first couple hours of operation due to the protective coating which is applied to internal components. This odor will dissipate and should be disregarded. This dust collector is designed to help maintain clean, safe conditions around dust creating machine in work shop and factory.
  • Page 5 Fasten the motor base to motor Fasten air flow pipe to blower Remove the paper backing and with four 3/8" x 1 inch-long screws, housing with four 3/8" flat washer start the gasket material around four 3/8" flat washers, and four 3/8" and four 3/8"...
  • Page 6 11. Place another support bracket on 12. Place one lower leg to the outside 13. Make sure the lower leg on the the inside of two legs. of upper leg and support bracket. outside of upper leg and support bracket on the inside of upper leg. Fasten upper leg, lower leg and support bracket with four 3/8"...
  • Page 7 18. Position rubber gasket on the outer 19. Fasten hose connector to cover 20. Assemble hose over bottom outlet edge of hole of collecting drum with four 5/16 X 1" screw, four 5/16" of cyclone separator and tighten cap and hose connector on the flat washer, four 5/16:"...
  • Page 8 A A S S S S E E M M B B L L Y Y D D R R A A W W I I N N G G 1 1 0 0 - - 8 8 1 1 0 0...

  • Page 9: Parts List

    PARTS LIST 10-810 REF. N0. REF. N0. DESCRIPTION DESCRIPTION 5/16" x 3/4" HD HEX SCREW LOWER LEG 5/16" FLAT WASHER 5/16" FLAT WASHER MOTOR BASE 5/16" x 1" HD HEX SCREW 5/16" HEX NUT Ø 7" FLEXIBLE HOSE MOTOR Ø 7" HOSE CLAMP BLOWER COVER 5/16"...
  • Page 10 10-810 8360, Champ-d’Eau, Montreal (Quebec) Canada H1P 1Y3 Tel.: (514) 326-1161 Fax : (514) 326-5555 www.general.ca IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity...
