FOREWORD
Dear Customer,
Congratulations! Over one crore Indians are part of the TVS XL family and now, it gives us great pleasure to welcome you
to it. We hope you have a great journey ahead just as millions of satisfied TVS customers have.
With stringent quality checks, great attention and care has been taken to ensure that your TVS XL 100 is in a perfect
operating condition as it leaves our factory. With a powerful engine and great new features, all you have to do is to fill up
your new TVS XL 100 with fuel and get going.
This manual will help you get the best performance out of your new TVS XL 100. From information on how best to ride it
to its maintenance, you will find all the relevant information in the following pages. Follow them carefully to make the
most of your vehicle.
We're delighted to inform you that as part of our company policy, you are entitled to benefits for the maintenance of your
vehicle. Free services and other warranty repairs can be availed from the TVS Motor Company Authorised Distributor or
Dealer / Authorised Service Centers nearest to you. The staff at the Authorised Distributor or Dealer / Authorised Service
Centers have been trained by us to take great care of your after sales/service requirements.
We wish you a long and fruitful journey ahead with your TVS XL 100, for years and years to come.
Warm regards,
TVS MOTOR COMPANY LIMITED
