Summary of Contents for Chauvet PK PAR56C
- Page 1 Snapshot PK PAR56C™ Ok on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL Chauvet, 3000 N 29th Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 . (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com...
-
Page 2: Table Of Contents
Lamp Replacement ... 6 ... 6 OUNTING Orientation ... 6 Rigging ... 6 4. APPENDIX... 7 ... 7 ENERAL AINTENANCE ... 7 ROUBLESHOOTING ... 7 ECHNICAL UPPORT ... 8 ETURNS ROCEDURE ... 8 LAIMS ... 8 ECHNICAL PECIFICATIONS PK Par56C User Manual 2006-12-08/12:16... -
Page 3: W Hat Is Included
Earth Ground. Contact Us W o r l d W i d e General Information Technical Support World Wide Web PK Par56C User Manual EGIN Chauvet Lighting 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115... -
Page 4: S Afety I Nstructions
Avoid direct eye exposure to the lamp while it is on. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. PK Par56C User Manual 2006-12-08/12:16... -
Page 5: Introduction
1 year limited warranty Note: These fixtures can operate at 230V with optional 230V lamps. If you wish to run this fixture at 230V, you must purchase a compatible 230V lamp from your Chauvet dealer. Product Overview Lamp Access Thumbscrew... -
Page 6: Lamp
You will need to install a lamp prior to the initial operation of the fixture. A 300W lamp is included. Up to a 500W lamp may be used in this fixture. See page 8 for a list of compatible lamps which you can order from any Chauvet dealer. Warning! When replacing the lamp, please wait 15 minutes after powering down to allow the unit to cool down! Always disconnect from main power prior to lamp replacement. -
Page 7: Appendix
Check to make sure the lamp socket is plugged into the lamp. Check to make sure the fixture is plugged into an active power circuit. If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location below. -
Page 8: R Eturns P Rocedure
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return.
