Service Manual

Washing Machine

Model: DWD-HT1011 / HT1211
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
DWDHT10001
S/M No. :
Jun. 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-HT1011 and is the answer not in the manual?

Questions and answers

Санал
April 21, 2025

Почему не срабатывает звуковой сигнал после стирки

0

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DWD-HT1011

Summary of Contents for Daewoo DWD-HT1011

  • Page 1: Service Manual

    DWDHT10001 S/M No. : Service Manual Washing Machine Model: DWD-HT1011 / HT1211 Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER...

  • Page 3: Specifications

    INLET HOSE POWER CORD DETERGENT CASE CONTROL PANEL HOSE DRAIN DOOR ADJUSTABLE LEG LOWER COVER MODEL DWD-HT1011 / HT1211 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595 x 610 x 850 MM WEIGHT 52Kg(NET) / 55Kg(GROSS) WATER CONSUMPTION POWER CONSUMPTION 2200W...

  • Page 4: Installation

    2. INSTALLATION Transit bolts The appliance is fitted with transit bolts to prevent internal damage during transport. Removing transit bolts 1. To prevent internal damage during transport, the 2. Unscrew the 3 bolts with the spanner supplied, special 3 bolts are locked. Before operating the and take out the 3 bolts with the rubber bungs.

  • Page 5: Installation Place Requirement

    Installation place requirement Level floor : Allowable slope under entire washer is 1°. Power outlet : Must be with 1.5 meters of entire side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required.

  • Page 6: Connecting Inlet Hose

    Connecting inlet hose In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. FOR ORDINARY TAP 1 Pull down the collar 2 Loosen the four...

  • Page 7: Installation Of Drain Hose

    Installation of drain hose Installation of drain hose Laundry tub max. 100 cm min. 60cm strap max. 100 cm min. 60cm • The drain hose should not be placed higher than 100cm above the floor. • Proper securing of the drain hose will protect the floor from damage due to water leakage. •...

  • Page 8: Level Adjustment

    Level adjustment 1. The level adjustment of the washing machine prevents excessive noise and vibration. Install the washing machine on a solid and even floor surface, if possible, in a corner of the room. Note: The wooden floor may cause excessive vibration.

  • Page 9: Maintenance

    3. MAINTENANCE Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent. Immediately wipe off any spills.

  • Page 10: Cleaning The Water Inlet Filter

    Cleaning the water inlet filter Cleaning the water inlet filter • "IE" error message will blink on the control panel when water does not enter the detergent drawer. • "IE" error message will blink on the control panel when water does not enter the detergent drawer. •...

  • Page 11: Cleaning The Detergent Case

    Cleaning the detergent case Cleaning the detergent case After a while detergents and fabric softeners leave a deposit in the detergent case. After a while detergents and fabric softeners leave a deposit in the detergent case. • It should be cleaned from time to time with a jet of running water. •...

  • Page 12: Direction For Disassembly

    4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1) Open the door and remove the gasket clamp. 2) Remove the gasket from the front cabinet. 3) Remove the door lock switch. 4) Remove two screws, and push the door lock switch to the right direction.
  • Page 13 3) Remove the nut by using a box wrench, and 4) Loosen the nut by using a box wrench, and pull out remove the earth terminal. the heater. UNIVERSAL MOTOR 1) Remove the belt from the pulley. 2) Lay the right side of the washer on the floor, and remove the connector.

  • Page 14: Drain Pump

    DRAIN PUMP 1) Lay the right side of the washer on the floor. 2) Remove connectors. 3) Remove the screws. 4) Remove the drain hose and the hose water supply. 5) Remove the inner drain hose, and remove the drain pump. DIRECTION FOR DISASSEMBLY...

  • Page 15: Explode View And Parts List

    5. EXPLODE VIEW AND PARTS LIST BOX INLET AS EXPLODE VIEW AND PARTS LIST...
  • Page 16 PART NAME PART CODE SPECIFICATION Q'TY REMARK HANDLE CASE (CASE HANDLE) 36111T3F00 ABS, D-H'S 1ST DWD-HT1011 CASE DETERGENT 36111T3G00 D-H'S 1ST , PP D-HT1011 CAP SOFTENER 3617512000 D-FT'S, F1-F7, PP BOX INLET 3610526500 3618103300 PP , NOZZLE T NOZZLE AS...
  • Page 17 PANEL FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PANEL F 36142T4D00 ABS, D-H'S 1ST DECO WINDOW 36116DWM00 ABS, D-H'S 1ST DECO COURSE 36116DWN00 ABS, D-H'S 1ST BUTTON OPTION 3616650000 ABS, D-H'S 1ST BUTTON FUNCTION 3616650100 ABS, D-H'S 1ST WINDOW COURSE 3615512800 ABS, D-H'S 1ST...
  • Page 18 CABINET FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET F D-HT's/HD's SWITCH DOOR LOCK 3619047100 SCREW TAPPING 7122401208 T2S TR4*12 SUS COVER PUMP 3611433400 ABS, D-H'S FRAME DOOR I 36122WD600 PP, D-H'S SCREW TAPPING 7115402008 T1S FLT4*20 SUS DOOR GLASS 361A11070T GLASS PI300 M,F...
  • Page 19 TUB ASS’Y EXPLODE VIEW AND PARTS LIST...
  • Page 20 PART NAME PART CODE SPECIFICATION Q'TY REMARK BALANCER WEIGHT F L/R 3616106320 D-FD14 5.5KG SPECIAL SCREW 3616029400 SWCH 8.5X30 GASKET 3612327600 EPDM NOZZLE SHOWER 3618113200 CLAMP GASKET AS 3611204530 HSW3, F'S WIRE L1060 TUB *F 3618821010 FRPP FH7304GM SPECIAL SCREW 3616029800 SWCH 6.5X30 FIXTURE HEATER...
  • Page 21 CABINET AS EXPLODE VIEW AND PARTS LIST...
  • Page 22 PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET 3610811101 D-F's FRAME TOP *L 36122UDY00 SGCC 1.2T, FT1081 FRAME TOP *R 36122UDZ00 SGCC 1.2T, FT1081 FRAME LOWER 36122WD500 SGCC T1.0 BASE UNDER *L 3610395000 SGCC T1.6 100X500 BASE UNDER *R 3610395100 SGCC T1.6 FRAME UPPER 36122UE000...
  • Page 23 PLATE T AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PLATE TOP AS 3614543400 D-H'S 1ST SCREW TAPPING 7122401411 T2S TRS 4*14 MFZN EXPLODE VIEW AND PARTS LIST...

  • Page 24: Functions Of The Control Panel

    6. FUNCTIONS OF THE CONTROL PANEL Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 25 ADD+ Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, '2:00' is displayed.

  • Page 26: Functions Of The Controller

    7. FUNCTIONS OF THE CONTROLLER Sequence Chart Synthetic Intensive Baby care Division Progress Time Small High Small Sensing 20sec. Water Supply 2min. Pre Wash 10min. 8min. Drain 1min. B-Spin 1min. Middle Spin 3min. Sensing 20sec. Water Supply 2min. Wash 1 70min.
  • Page 27 Sports Bubble Speed Rinse + Wool Tub Clean Color wear Shower Wash Spin Division Progress Time Small Small Small Small Soak 30min. Water Supply 2min. (1min.) Wash 1 60min. (Heating) 50min. 30min. 20min. 5min. (20min.) Wash 2 23min. 13min. 5min. Drain 1min.

  • Page 28: Function Of The Convenient Service

    8. FUNCTION OF THE CONVENIENT SERVICE The test mode of the operation You can check the PCB AS and the operation of the washing machine simply. • The method to test and operate 1 Press the Power button. 2 Press the Option button 3 times while press the Temp button. At this time, the version is displayed on the Custom LED 3 Whenever the Time Delay button is pressed, the washing machine is operated as following.
  • Page 29 The spinning test mode You can continually spin the washing machine with constant speed. • The method to test and operate 1 Press the Power button. 2 Press the Time Save button 3 times while press Temp button. 3 '400' displays on '18:88 LED'. 400 means the spinning rpm. You can adjust the spinning rpm by pressing Spin button.

  • Page 30: Troubleshooting Guide

    9. TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. SYMPTOM CAUSE SOLUTION...
  • Page 31 SYMPTOM CAUSE SOLUTION Washer does not start. Electronical power cord may not be Make sure plug fits tightly in wall outlet. plugged in or connection may be loose. House fuse blown, circuit breaker Reset circuit breaker or replace fuse. tripped, or a power outage has Do not increase fuse capacity.
  • Page 32 MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. WATER INLET The water level sensor (sensor pressure) is an inferior product Change the water level sensor...
  • Page 33 MESSAGE ERROR CAUSE SOLUTION The water temp. is over 45˚C in delicate & wool course. WATER TEMP. Change the thermistor wash. ERROR (The thermistor wash is an inferior product or broke down.) The heater wash dose not work. HEATER WASH Change the heater wash.

  • Page 34: Wiring Diagram

    10. WIRING DIAGRAM WIRING DIAGRAM...
  • Page 35 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: AEWOOELEC” S/M NO. : PRINTED DATE: Jun. 2012...
  • Page 36 ABOUT THIS MANUAL ABOUT THIS MANUAL k k l l F F l l & & m m # % % e e $ $ n n o o l l k k $ $ ` ` # # l l m m % % " " O_ p.q rds 3t8 juvw ix {|} ~...
