OPERATION GUIDE 2022 BEACHY
GB

Advertisement

Table of Contents
loading

Related Manuals for Hobby BEACHY 2022

Summary of Contents for Hobby BEACHY 2022

  • Page 1 OPERATION GUIDE 2022 BEACHY...
  • Page 2 1. Introduction Dear Caravaner, Congratulations on the purchase of your new HOBBY Caravan. The trust you have placed in us is both an incentive and an obligation to continuously implement new ideas, technical innovations and fine touches to design our caravans even better.

  • Page 3: Table Of Contents

    1. Introduction Table of Contents Introduction General information .............................. 1 Key to using in These Operating Instructions ....................2 Safety Intended use ................................4 General information .............................. 4 Fire protection ................................ 4 Emergency equipment ............................5 Before the journey ..............................6 2.5.1 What to observe before your first journey ......................
  • Page 4 1. Introduction Water General information ............................48 Water pump ................................48 Water flushing toilet ............................50 Built-in devices General information ............................53 Dometic cooler ..............................53 10 Accessories ..................................55 11 Maintenance and upkeep 11.1 Maintenance .................................56 11.2 Hitch head ................................57 11.3 Brakes ..................................58 11.4 Changing bulbs in the rear lights ........................59 11.5 Changing the battery and maintenance of the smoke detector ..............60 11.6 Ventilation ................................61 11.7 Upkeep ...................................62...

  • Page 5: General Information

    These operating instructions also describe equipment which may vary from the standard scope of delivery. Therefore, HOBBY shall not be liable for any claims arising from the contents of this handbook. The equipment that has been implemen- ted at the time of printing is described in these operating instruc- tions.

  • Page 6: Key To Using In These Operating Instructions

    Procedural guidelines are also based on key points and begin Name Datum Art der Änderung ETL. Konstr. with a bullet point. "•". Näherei Zulieferer Hobby Wohnwagenwerk Datum Name Gezeichnet Geprüft Ing. H. Striewski GmbH, Harald-Striewski-Str.15, 24787 Fockbek Maßstab Zeich.Nr.: Art.Nr.:...
  • Page 7 “ ”. For technical reasons, optional extras cannot always be installed in all models. Should you have any questions, please speak to your Hobby dealer. Should there be any equipment or a model that is not described in this user manual, please note the enclosed additional operating instructions.

  • Page 8: Safety

    2. Safety 2.1 Intended use This caravan has been designed as a mobile travel accommodation for private, not commercial use. This is a recreational vehicle that is fit for habitation. It offers accommodation that can be used temporarily or seasonally and which meets the requirements for the construction and use of the vehicle on the road.

  • Page 9: Emergency Equipment

    2. Safety Fighting a fire • Evacuate all passengers immediately. • Disconnect the gas supply when using gas-operated devices. • Gas containers which cannot be removed should be cooled with water. • Shut off the electrical supply. • Sound the alarm and call the fire service. •...

  • Page 10: Before The Journey

    Any changes made to the caravan that fall under nati- onal traffic regulations must be approved and entered in the registration document! If you have any further questions or difficulties, your authorised Hobby dealer will always be available to assist you!

  • Page 11: Before Each Journey

    2. Safety Fit for a Speed of 60 mph (Germany) 1. Your HOBBY caravan is technically equipped for a maximum speed of 60 mph. Under no circumstances may this speed be exceeded! 2. Note the permissible maximum speeds for towing in the country in which you are travelling! 3.
  • Page 12 (see also Chapter 3.3 Loading). • If necessary, switch the cooler to operate in 12V mode. Name Datum Art der Änderung ETL. Konstr. Näherei Zulieferer Hobby Wohnwagenwerk Datum Name Gezeichnet Geprüft Ing. H. Striewski GmbH, Harald-Striewski-Str.15, 24787 Fockbek Maßstab Zeich.Nr.: Art.Nr.: •...

  • Page 13: While Driving

    2. Safety Place a note with all important measurements and weights in a clearly visible place on the dashboard. 2.6 While driving Driving Staying in the caravan during the drive is prohibited by law! Take a test drive or a safety training course before the first long drive to better acquaint yourself with the carriage in driving conditions.

  • Page 14: After Each Journey

    Driving in reverse Your HOBBY caravan has a braking system with automatic reverse. It enables you to drive backwards without applying the brakes, because the overrun coupling does not differentiate between overrunning or reversing the caravan.
  • Page 15 2. Safety • Level the caravan lengthwise using the jockey wheel. • If on uneven or sloping ground level the the caravan sideways using boards or wheel chocks. Do not use the corner steadies to compensate for un- even ground. Securing the vehicle Rules for securing the vehicle: •...

  • Page 16: Chassis

    For the sake of traffic safety, the vehicle undercarriage must be maintained just as conscientiously as the base vehicle itself. This maintenance should be carried out by your HOBBY dealer. If spare parts are required, use only the original parts supplied by the manu-facturer.

  • Page 17: Loading

    - Heavy objects such as the awning, boat engine or beverage cases. Stowage areas Name Datum Art der Änderung ETL. Konstr. Näherei Zulieferer Hobby Wohnwagenwerk Datum Name Gezeichnet Geprüft Ing. H. Striewski GmbH, Harald-Striewski-Str.15, 24787 Fockbek Maßstab Zeich.Nr.: Art.Nr.: Pro le Nr:...

  • Page 18: Tow Hitch Load

    1. Gross vehicle weight rating (g.v.w.r.) The indication of the gross vehicle weight rating is taken directly from the HOBBY factory. This mass takes into account the specific operating conditions that are based on the model of the caravan and its specifications, including such factors as material strength, load- carrying capacity of the axles and tyres, etc.
  • Page 19 These optional extras will be shown in the actual mass of the vehicle if − they are not part of the standard spec of equipment, − Hobby was responsible for assembling them, − the customer can order them. 4. Actual mass Sum of the mass when ready to drive and the optional extras or additional equipment assembled by the manufacturer.

  • Page 20: Stabiliser Hitch

    3. Chassis 3.4 Stabiliser hitch KS 25 The caravan has been fitted with a stabiliser hitch (class B50-X) with friction pads to reduce fish-tailing. This system conforms to ISO 11555- 1. It has been permitted for use up to a maximum speed of 100 km/h. Please note the additional operating instructions and the manufacturer's safety instructions.
  • Page 21 3. Chassis Do not step on the drawbar when the trailer is hitched. The maximum loads for the caravan and/or base vehicle could be exceeded and the combination could buckle. Use only the grab handles provided to manoeuvre the caravan (see 2.7 After driving) and never the lever of the KS 25.
  • Page 22 3. Chassis Unhitching • Make sure that overrun gator is fully extended. It will not be possible to release the hitch from the tow ball if it is compressed. • Pull the handbrake on and secure the caravan with wheel chocks if necessary.

  • Page 23: Jockey Wheel

    3. Chassis 3.5 Jockey wheel Rotating it upwards and securing it • Hitch the caravan to the towvehicle, aligning the jockey wheel to the rear end of the caravan. • Loosen the clamping handle • Pull the jockey wheel up as far as possible. •...

  • Page 24: Overrunning Equipment And Wheel Brakes

    (see photo Fig. Should you exchange the carabiner, ensure that you get an equivalent replacement. The standard version of your Hobby caravan is equipped with a carabiner used by fire departments. A so-called spring hook must not be attached directly to the eyelet, because it can only supply the strength required to fully apply the brake if it is the fastener for a loop.

  • Page 25: Electronic Trailer Stabilisation (Ets Plus)

    (Knott). 3.8 Electronic Trailer Stabilisation (ETS Plus)* ETS Plus is a safety system that can be retrofitted for HOBBY cara- vans with a mechanical overrun brake. It automatically recognises if the trailer starts to sway and, if necessary, can stabilise the car and caravan by applying the caravan brakes.
  • Page 26 3. Chassis • Before your journey, check the light-emitting diode (LED) on the ETS Plus. • ETS Plus operates within a temperature range of -20°C to +65 °C. • Do not reach into the moving parts of the ETS Plus central unit! •...

  • Page 27: Wheels And Tyres

    4. Wheels and Tyres 4.1 Wheels The following applies for wheel bolts: If you are driving a new vehicle, or after changing a tyre, tighten the wheel bolts or nuts after you have driven the first 50 km and then again after the following 100 km.

  • Page 28: Tyre Pressure

    Wheels and Tyres 4.3 Tyre pressure Tips for checking tyre pressures: • Check and correct tyre pressure every four weeks (but at least every three months) and before every journey. • Tyres must be checked when they are cold. • When inspecting or correcting warm tyres, the pressure must be 0.3 bar higher than when the tyres are cold.

  • Page 29: Rims

    4. Wheels and Tyres Tyre manufacturers' recommendation • Change tyres after six years, regardless of profile depth. • Avoid striking curbs, potholes or other obstacles. Age of tyres You should change your tyres before they reach six years old because the rubber deteriorates over time and also when they don't move for long periods of time.

  • Page 30: Changing A Wheel Tyre

    Wheels and Tyres 4.6 Changing a wheel tyre Preparing to change the tyre • If possible, only change the tyre when the tow vehicle is coupled to the caravan. • Park the car and caravan on as firm and even a surface as possible. •...
  • Page 31 4. Wheels and Tyres Changing the wheel • If the vehicle is parked on soft ground, lay a stable reinforce ment under jack* (i.e., a board). • Set the corresponding jack onto the fixed part of the axle not the swinging arm or on the chassis beam ias close as is possible to the axle on the side where the wheel is being changed.

  • Page 32: Tyre Repair Kit

    Wheels and Tyres 4.7 Tyre repair kit All models are equipped with a tyre repair kit; this is part of the stan- dard equipment. Do not use the tyre repair kit if the tyre was damaged as a result of driving without air. Small punctures (of up to 6 mm), especially in the tyre tread, can be sealed using the tyre repair kit.
  • Page 33 4. Wheels and Tyres Shake the bottle of tyre sealant. Screw the white attachment on to the bottle, then attach the filler hose and connect it to the valve. Fill in the recommended amount of tyre sealant. Pushing the filler hose onto the tyre valve Pull off the filler hose.

  • Page 34: Exterior Structure

    5. Exterior structure 5.1 Forced and fixed ventilation The following applies for ventilation Proper ventilation and dehumidifying of the caravan is a prerequisite for ideal living comfort. Vents for draft-free forced ventilation have been integrated in the floor of your caravan; for forced dehumidifying , they have been integrated in the roof lights.
  • Page 35 5. Exterior structure Entry step When entering and exiting the vehicle: • Place the entry step in front of the entrance door to the caravan. • Ensure that the step is placed on a level surface; this prevents the step from falling over. Note the varied step heights and, when exiting, ensure you will step onto firm and even ground.
  • Page 36 5. Exterior structure Partitioned outer rear flap The upper flap and the lower door can only be opened and closed from the inside. You could be seriously injured! Because of its high posi- tion on the vehicle, the rear flap is not meant to be used for entering or leaving the vehicle! Partitioned rear flap Top flap open...
  • Page 37 5. Exterior structure Locking devices for doors and flaps The entrance door and the lower part of the rear flap can be fastened using the locks on the outside wall of the vehicle. To lock • Open the door or flap all the way. •...

  • Page 38: Corner Steadies

    5. Exterior structure 5.3 Corner Steadies The corner steadies are located in the front and rear under the caravan. Winding the corner steadies down • Park the vehicle as horizontally as possible. • On soft ground, lay a sturdy mat or suitably sized board under the eet of the corner steadies to prevent the caravan from sinking.

  • Page 39: Bicycle Carrier

    5. Exterior structure 5.6 Bicycle carrier * Please read the separate operating instructions before using the bicycle carrier. Before driving for the first time, take some time to practice so as to familiarise yourself with driving conditions. A frame bicycle carrier In the “BEACHY”...

  • Page 40: Interior Structure

    6. Interior structure 6.1 Opening and closing doors and drawers Walk-in wardrobe/Porta Potti • Push down on the handle to open or shut the door. Door handle Kitchen drawer/cupboard with pushlock The cabinet and drawer are each secured by a separate pushlock To open • Press the pushlock (latching button) so that the button pops out. • Pull on the pushlock until the drawer slides out or the cabinet door opens. Pushlock in connection with kitchen cabinet and drawer To close • Push the pushlock to shut the drawer or the door of the cabinet.

  • Page 41: Folding Table

    6. Interior structure 6.2 Folding table Folding table To lower • Unhook the brackets and fold the table legs inwards. Folding table 6.3 Seating and sleeping areas Converting the seating area The seating area can be converted to comfortable beds. Preparing to convert the bed • Fold the two folding tables together (see Chapter 6.2 Tables). • Place the separate board as an extension between the bench seats.

  • Page 42: Rearranging The Cushions

    6. Interior structure • Place the two folded tables as an extension between the bench seats. • Place the back cushions from the side of the vehicle as a mat- tress on the extension between the bench seats. • Place the back cushions from the side of the vehicle on the mattress as a topper. 6.4 Rearranging the cushions When converting the seating area into a bed, do not place the cushions directly on the surface of the table. There is a danger that it could be scratched or mould could build up from condensation. We recommend that you use an absorbent cloth (e.g. terry cloth or cotton). Ensure that the tabletop, seat chests as well as cushions are well secured so that nothing can fall.

  • Page 43: Windows

    6. Interior structure 6.5 Windows Depending on how the window has been constructed, it has one or more latches with locking knobs . To open these window catches, press the lock buttons . Various window fixings have been fitted in the vehicle. Window with ratcheting stays To open • Turn all of the window latches by 90°. • Press the window catch outwards until you hear it click. The window will automatically remain in this position. The angle of opening can be increased in predefined steps. To close • Lift the window slightly to unhook the stay. • Close the window. • Turn all of the window catches to the original position so that Catch they clasp behind the latches and pull the pane into the seal. Before closing the window, check that the curtains are not caught in the sealing. Apart from the open and closed positions, the window catches can also be locked in the middle slot of of the latches to allow air in, this is the vent position. High humidity may cause a light mist to form within the Closed Vent position...

  • Page 44: Roof Lights

    6. Interior structure 6.6 Roof lights Safety instructions • N ever open the roof lights if there is a strong wind/ rain / hail, etc. or when the temperature outside is below -20° C! • Never use force to open the roof lights if they are frozen or covered with snow, because you may break the hinges and the opening mechanism. • Before opening, remove snow, ice or heavy dirt. Make a note of the required space needed before opening the roof light under a tree, in a garage, etc. • C lose and lock roof lights before driving. Open fly screen and blind (fully open position).

  • Page 45: Installation Of Electrical Devices

    7. Installation of electrical devices 7.1 Safety tips The installation of electrical devices in the HOBBY caravan has been carried out in accordance with the valid regulations and standards. Please note • Do not remove the signs on electrical components giving safety instructions or danger warnings.

  • Page 46: Electrical Supply

    7. Installation of electrical devices Fuses • Only replace a blown fuse after the cause of the error has been fixed by an authorised specialist. • The new fuse must have the same amperage as the old one. Remote control(s), bed/kitchen •...
  • Page 47 7. Installation of electrical devices To connect to a mains hook up point • Pull out the 13-pin plug that connects to the tow vehicle. • Switch off the automatic circuit breaker by pressing the ro- cker button down • Take hold of the bottom of the cover flap of the CEE external and pull it up (see Chapter 5.2 Cover Flaps).
  • Page 48 7. Installation of electrical devices • The 230 V mains connection in the caravan has been designed for a total power consumption of 2300 W. If additional devices requiring electricity are connected, such as a water heater, etc., ensure that this electric power value is not exceeded, taking other electrical equipment in use, such as the cooler, therme, etc., into account.
  • Page 49 7. Installation of electrical devices Devices that cause it to trip when in use show that there is a fault; they must be checked and/or repaired by an electrical engineering specialist. Switching it back on again and again will do no good. The automatic circuit breaker also goes off when the ro- cker switch is held firmly in place.

  • Page 50: Electrical System

    7. Installation of electrical devices 7.4 Electrical system As soon as there is a mains connection, the electrical system will switch from battery operation to mains operation. The electrical supply unit uses a transformer to change the external mains voltage for the 12V electrical devices.

  • Page 51: Diagram Of The Electrical Distribution Board

    7. Installation of electrical devices 7.5 Diagram of the electrical distribution board Ambience (Light in outer Steady plus Steady plus Steady plus Steady Wardrobe Dauerplus Dauerplus Dauerplus Dauerplus Kitchen Ceiling LED seating light tent) currently 12V socket USB socket USB socket plus water Beleuchtung Ambiente LED...

  • Page 52: Water

    8. Water 8.1 General information We recommend that you inspect any water you have left in the tank, this is very critical before using the water again • Water that is suitable for drinking should always be used when working with food. This also applies to washing your hands and cleaning the objects that have come into contact with food.
  • Page 53 8. Water Fresh water canister The fresh water canister is located in the lower kitchen cabinet and holds a volume of 13 litres. Use the blue service cap to fill the canister with fresh water. Check the blue service cap regularly; it may become loose if the fresh water canister is filled often.

  • Page 54: Water Flushing Toilet

    8. Water 8.3 Water flushing toilet Portable Porta Potti toilet Your portable toilet is made up of two detachable sections: the flush- water tank and the waste-holding tank. to both tanks. Before using the toilet, it is vital that you add toilet addi- tives (where available) to both tanks.
  • Page 55 8. Water Using the toilet Schließen Sie die Abdeckung und öffnen und schließen Sie die Ver- schlussplatte, um aufgestaute Wärme oder Höhendruck abzulassen und um ein Spritzen zu verhindern. Öffnen der Verschlussplatte To vent any built-up heat or altitude pressure and prevent for splashing close the cover and once open and close the blade.
  • Page 56 8. Water Emptying the waste tank You need to empty the waste-holding tank when the level indicator turns red. • Separate the tanks • Take the waste-holding tank to an authorised waste disposal point. • Remove the cap from the pour out spout, while it is pointing up- wards •...

  • Page 57: Built-In Devices

    9.1 General information In this chapter, you will find information on the devices that have been built into the Hobby caravan. This information refers only to the operation of these devices. To some extent, the devices described are special accessories.
  • Page 58 9. Built-in devices 12V operation (thermoelectric mode) While driving, 12V operation can only be used when the engine is run- ning. During breaks or on longer stopovers, switch off 12V operation and, if required, select a different mode of operation. •...

  • Page 59: Accessories

    • HOBBY cannot accept liability for any damages caused by parts or changes that have not been approved by HOBBY. The following table includes a list of weights for accessories. If these parts are carried in or on the caravan and are not included in the standard specification, they must be taken into consideration when determining the full load.

  • Page 60: Maintenance And Upkeep

    • Have all further maintenance performed once annually at a HOBBY dealer. • Have all maintenance on built-in devices performed in accor- dance with the corresponding maintenance intervals indicated in the operating instructions. Hobby’s voluntarily granted (5 year) warranty against leaks in the mobile home, as set out in the guarantee conditions, will only take effect if the (chargeable) in- spections for leaks were carried out correctly. To this end, the mobile home must be taken to a Hobby dealer 12-18 months after receipt of the vehicle. After the initial...

  • Page 61: Hitch Head

    11. Maintenance and upkeep Rubber spring axles require no maintenance. The axle(s) of the caravan is (are) fitted with compact wheel bearings. The cylinder hub, compact bearings and axle nuts form a closed unit. The compact bearings are free of maintenance due to their special grease. You can find further guidelines in the operating instructions from the axle supplier. 11.2 Hitch head Tow ball on base vehicle Ensure that the tow ball meets the required dimensions and is unda- maged, clean and free of grease. If using Dacromet-coated (dull-silver coating for corrosion protection) or lacquered tow balls, the coating must be completely removed before your initial journey using sandpaper (grain: 200 240) and then cleaned, e.g. using a nitro thinner or spirit, so that it is not deposited on the surface of the friction pads. The metal surface of the tow ball must be bright. A damaged or dirty tow ball causes increased wear and tear on the friction pads; a greased tow ball greatly reduces the stabilizing effect.

  • Page 62: Brakes

    11. Maintenance and upkeep Changing the friction pads It is easy to replace the friction pads if they are worn out or co- vered in oil or grease. KNOTT offers the appropriate replacement set for replacing the front and back friction pads. Please note the detailed instructions for assembly in the manufacturer's spare part kit. Use only original KNOTT friction pads. These have been precisely tailored to meet the require- Friction pads ments of the KS 25 stabiliser hitch. If other friction pads are used, either the stabilising effect will be negatively influenced or the ball neck could be damaged. Noises Noises may occur while towing your caravan; however, they have no influence on the operation and stabilising effect of the stabiliser hitch. Possible causes of these noises can be: 1. a painted (dacromet coated) ball on the tow vehicle. 2. A galvanized or varnished tow ball on the tow vehicle. 3. A damaged, rusty or dirty tow ball on the tow vehicle. 4. Dirty or worn out friction pads in the hitch.

  • Page 63: Changing Bulbs In The Rear Lights

    11. Maintenance and upkeep 11.4 Changing bulbs in the rear lights Disconnect the power supply before changing the lamps! Lamps can be hot! Ensure that no liquids (e.g. rainwater) flow into the cover. Changing the licence plate illumination • To change the registration plate light, first unscrew these screws • Detach the cables and attach them to the new light.

  • Page 64: Changing The Battery And Maintenance Of The Smoke Detector

    11. Maintenance and upkeep 11.5 Changing the battery and maintenance of the smoke detector Please observe the operating instructions of the device manufacturer. Maintenance The smoke detector system does not require any maintenance. From time to time, remove the dust from the cover of the detector and en- sure that the air slots are not dirty or blocked up by insects or similar objects. If necessary, the detector should be wiped off with a dry cloth and then hoovered on the outside approx. twice a year. Smoke detector closed Test button Holes for the lock Block battery, type 9VDC 6F22 Pins for battery contact Locking pegs Changing the battery To ensure that the block battery continues to function correctly it must be changed regularly, but no later than when the warning signal beeps. • Carefully turn the cover of the smoke detector anti-clockwise until it can be removed from its mount. Smoke detector opened • Take out the used block battery and unpin it from the pins.

  • Page 65: Ventilation

    11. Maintenance and upkeep 11.6 Ventilation Sufficient ventilation and de-aeration of the vehicle interior is essen- tial to maintaining a comfortable climate. You will notice an increased amount of condensation inside the caravan on cooler days or after it has not been used for a prolonged period of time. This condensation may be particularly heavy on single-glazed windows. Damp spots are sometimes even noticeable on furniture surfaces, the inner side of outside walls, and often also in cupboards. Furthermore, such damp- ness can cause mould to build up, which then rapidly spreads to other surfaces. This situation not only impairs your sense of well-being, but can also lead to damaged components. This condensation is generally caused by the air in the room. One of the properties of air is that it can absorb water. The hotter the air is, the more water it can absorb (relative humidity). If air that is totally saturated with water vapour cools down and reaches its saturation point, it gives off part of the water in the form of condensation. This is also known as a “cold bridge”. However, condensation occurs primarily when there is little airflow due to structural conditions or insufficient airing. Condensation forms most readily - in tight spaces, - from the breath and perspiration of the passengers, - by having damp clothing, inside the caravan, While sleeping, a person loses about one litre of water per night through the pores of their skin and breathing. The additional water vapour in the air must be discharged from the recreational vehicle...

  • Page 66: Upkeep

    11. Maintenance and upkeep 11.7 Upkeep The following applies for their care: • clean plastic parts using hot water up to 60°C and mild washing-up liquid. Only wash the caravan at specially designed wash sites. Use cleaning solvents as sparingly as possible. Aggressive cleaners such as rim cleaner pollute our environment. Use only dishwashing liquid or commercial cleaning agents, always taking care to follow the instructions for use, and test the cleaning agent to make sure it is suitable. Cleaning products not recommended for use - abrasive cleaning agents (scratch the surface) - cleaning agents that contain acetone (immediately damage the plastic) - dry cleaning products - diluents - alcohols - aggressive or solvent-based cleaners - cleaners from the chemical group such as ketone, ester and aro- matic solvents - aromatic hydrocarbons (e.g. all automotive fuels)
  • Page 67 Rules for polishing surfaces • In exceptional cases, treat damaged paint surfaces with polish. We recommend paste polishes free of solvents. Do not polish too often since polishing removes the top layer of paint. Frequent polishing causes more damage than it remedies. Rules for treating tar and resin stains • Remove residues from tar and resin as well as other organic stains with petroleum ether or spirit. Do not use aggressive solvents such as products containing esters or ketone. Rules for damage repair • Repair all damages without undue delay to prevent further damage caused by corrosion. Consult your HOBBY dealer. Chassis The chassis of the caravan has been specially coated. If the protec- tive coating is damaged, repair it immediately. Coated areas should not be treated with spray oil.
  • Page 68 11. Maintenance and upkeep Chassis Should salt adhere to the hot-dip galvanised chassis, it will damage it and may cause white rust. However, white rust is not a defect, but merely an optical impairment. After driving in winter or through salty water, the hot-dip galvanised surfaces should be rinsed with clear water. Clean the corner steadies with water and a damp sponge, then dry and grease them, especially the spindle. Skylights, windows, mirrors and doors Window surfaces require particularly careful treatment as they scratch very easily, never clean using a brush. Rules for upkeep • Rub the rubber seals lightly with talcum power. • Only clean acrylic glass window panes with a clean, moist sponge and a soft towel. Dry cleaning can scratch the panes. Use plain water to clean the windows. Wipe the mirror dry with a soft cloth. Never use cleaning agents or ab- rasive and aggressive detergents that contain softeners or solvents! Wipe windows with a damp microfibre or...
  • Page 69 11. Maintenance and upkeep Rules for cleaning seat covers, upholstery covers and curtains • Clean seat covers with a soft brush or vacuum cleaner. • Have mattresses, cushions, bedspreads and curtains dry-cleaned when they are badly soiled. Do not wash them yourself! Never remove the covers from mattresses or cushions. • Clean with the foam with a gentle detergent if required. Cleaning instructions for materials that contain Teflon • Always treat spots immediately. • Sponge spots, but do not rub them. • Work from the edge towards the middle of the spot. • Never use household cleaners to remove spots. • Use a vacuum cleaner on the cushions regularly to remove any dirt that may have collected. We recommend the following methods for cleaning Method A: • Use only commercial cleaning agents that have a water basis.
  • Page 70 11. Maintenance and upkeep Rules for cleaning PVC surfaces Sand and dust can damage the surface of the PVC floo- ring if it is walked on regularly. When in use, clean the floor daily with a vacuum cleaner or broom. • Clean the surface with a special solvent for PVC surfaces. Do not place carpets on wet PVC surfaces. Carpets and PVC surfaces could stick together. • Never use chemical cleaners or steel wool, because they will damage the PVC surface. Rules for furniture surfaces • Clean wooden furniture finishes with a moist cloth or sponge. • Rub dry with a soft, dust-free cloth. • Use mild furniture polish. The following applies for the portable toilet Thetford recommends cleaning your toilet regularly to prevent limescale and ensure optimal hygiene. • Clean the inside of the bowl with a soft brush and a special cleaning product.

  • Page 71: Winterising The Caravan

    11. Maintenance and upkeep The following applies for the fresh water canister • Rinse it regularly with clean, clear water. Cleaning the fresh water canister • After emptying the water from the fresh water canister, use a cloth to remove the remaining liquid that has collected in the groove. Remove all spray cans with cleaners and polishes from the vehicle after finishing the upkeep! Otherwise, there is a danger of explosion at temperatures over 50° C! Fresh water canister 11.8 Winterizing the Caravan For many people, the camping season ends when the temperature...

  • Page 72: Winter Useage

    11. Maintenance and upkeep The following applies for the interior fittings • Clean the interior of your caravan. Hoover cushions and mattresses. If possible, store them outside the vehicle in a dry place. Alternatively, place them in such a way inside the caravan that they do not come into contact with condensation. • Use soapy water to clean linoleum and smooth surfaces. • Leave vents for forced ventilation open. If the caravan is kept in an enclosed space,, you can leave the skylight open. • Air the caravan thoroughly every four to six weeks when the weather is dry. • Set up a dehumidifier (such as salt) inside the caravan and dry the granulate or change it regularly. • If necessary, heat the caravan to prevent the build-up of mould from condensation. • Switch off the 12 V main switch. 11.9 Winter useage The BEACHY model has not been equipped by the ma- nufacturer for camping in winter.

  • Page 73: Waste Disposal And Environmental Protection

    12. Waste disposal / environmental protection 12.1 The environment and mobile travel Environmentally sound use Naturally, motor home, caravan and van owners and users are espe- cially responsible for the environment. Therefore, you should always use your caravan in an environmentally sound manner.
  • Page 74 12. Waste disposal / environmental protection Rules for rubbish disposal • Separate rubbish and bring recycleable materials to the appropri- ate collection sites. • Empty disposal bins as often as possible in the bins or containers provided for this purpose. This prevents unpleasant odours and rubbish build-up. Rules for rest areas • Always clean up picnic spots before you leave, even if the rub- bish has been left by someone else. • Never dispose of your household rubbish in the containers provi- ded in rest areas. • Do not let the motor of your tow vehicle run unnecessarily while standing still. A cold motor causes a lot of contamination while idling. The quickest way to reach operating temperature is while driving.

  • Page 75: Technical Data

    13. Technical Data 13.1 Chassis data Model g.v.w.r. Per- Axle(s) Wheel Leading Stabiliser Hitch Towbar [kg] mitted brake equipment axle load BEACHY 360 30EG • VGB 13 M 20-2425/1 KFL 12 B KS25 (210197.001) One Piece BEACHY 420 30EG • VGB 13 M 20-2425/1 KFL 12 B KS25 (210197.001)
  • Page 76 13. Technical Data Rims Tyre Wheel arch Floor Total Track Dis- Length Length Total size length width tance length Wheel Size Model towbar caravan mounting 5½ J x 14 5/112, ET 30 Steel 684 x 224 195/70 R 14 XL 3229 2165 1950...

  • Page 77: Tyre Pressures Values

    13. Technical Data 13.5 Tyre pressure values As a rule of thumb, it may be assumed that a filled tyre suffers a loss of pressure of 0.1 bar every two months. Check the pressure regularly to avoid damage to tyres or a puncture. Tyre size Air pressure in bar 195/70 R 14 XL or reinforced...

  • Page 78: Index

    Index Index Fresh water canister 49 Accessories 55 Fuses, assignment of 46 Additional equipment 15 Additional loads 13 Airing 61 General inspection 6 Awning rail 34 Greasing 56 Ground fault circuit interrupter (GFCI) 44 Guide rail for outer tent 44 Basic equipment 19 Bed conversion 38 Bicycle carrier 35...
  • Page 79 Index Seating area 37 Securing the vehicle 11 Shunting 10 Smoke detector 5 Sockets inside the caravan 46 Suitability for a speed of 100 km/h 7 Technical data 71 Technically permissible maximum weight 14 Toilet 50 Tyre pressure 24 Tyre profile depth 24 Tyre repair kit 28 Tyres 23 Tyres, age of 24...
  • Page 80 Hobby-Wohnwagenwerk Ing. Harald Striewski GmbH Harald-Striewski-Straße 15 D-24787 Fockbek/Rendsburg www.hobby-caravan.de...
