Introduction
Dear Motor Home Owners,
We would like to congratulate you on the purchase of your new HOBBY motor home and
hope that you will always enjoy traveling with it.
Please read this manual carefully, even if you have been driving a motor home for a longer
period of time. It will help you to avoid operating errors and damage to the vehicle and its
equipment. Correct handling of all technical details will increase your driving comfort and
maintain the value of your motor home.
We wish you and your companions many enjoyable trips and hope you always have a safe
journey.
