Chauvet CH-211 User Manual

Replacing Fuses

If the unit does not function at all when connected to the main power supply i.e. does not
illuminate after replacing the lamp. Then it is highly likely that the fuse has blown.
Disconnect from main power supply before attempting to replace either lamps or fuse.
In order to replace the fuse, disconnect from the main power supply first, and then unscrew the
fuseholder cover to reveal the fuse. The unit has a label attached which indicates the correct fuse
rating and you will also find this listed as part of the specifications for the unit later in this guide. It
is most important that replacement fuses are of the correct rating. Failure to use the correct fuse
could damage the lighting effect beyond economic repair.
The fuse should simply be placed inside the holder and the screw cap replaced, when this is
done connect to the main power supply to check. If the unit is still not working then please contact
your dealer or CHAUVET for servicing.
Caution
Do not touch unit or lamps while hot.
No user serviceable parts inside, please refer to CHAUVET for service.

Power Connections

The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.

Packing List

Please check contents of your packaging carefully for the following items:
1 x CH-211 Starburst (Master Head)
3 x CH-211 Starburst (Linkable Heads)
4 x 64514 / 64516 Lamps
3 x 3m (10') linking cables
1 x Literature – user guide / warranty card

Technical Specifications

Power 120V~60Hz AC
Fuses 20mm Glass 3.15A Quick Blow
o
2 x 5-pin (180 ) DIN twistlock
Control In/Out
sockets
1 x 120V 300W
Lamps
Part No 64514
Dimensions 228mm x 159mm x 159mm / 9in x 6.25in x 6.25in
Weight
230V~50Hz AC
20mm Glass 1.6A Quick Blow
o
2 x 5-pin (180 ) DIN twistlock
sockets
1 x 230V 300W
Part No 64516
1.81kg / 4lbs
S S S S t t t t a a a a r r r r b b b b u u u u r r r r s s s s t t t t
CH-211
Users Guide
Please read these instructions carefully before use
