  • Page 1 ™ UltraWave BR100 Microwave Detection Sensor Product Guide E5DA0102-001, Rev A July 23, 2020...
  • Page 2 The information provided in this guide has been prepared by Senstar Corporation to the best of its ability. Senstar Corporation is not responsible for any damage or accidents that may occur due to errors or omissions in this guide. Senstar Corporation is not liable for any damages, or incidental consequences, arising from the use of, or the inability to use, the software and equipment described in this guide.
  • Page 3: Table Of Contents

    Table of contents 1 System planning - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5 Site design - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5 Zone conditions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6 Zone height - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6...
  • Page 4 Silver Network connections - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 19 Stacking BR100 units - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -21 3 Setup and calibration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23 Setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23...
  • Page 5: System Planning

    System planning The BR100 Microwave Detection Sensor is designed for outdoor perimeter intrusion detection. BR100 consists of a microwave transmitter unit and receiver unit, which detect motion in a defined area (see Figure 1). The transmitter emits microwave energy, which the receiver constantly monitors.
  • Page 6: Zone Conditions

    Site design Note Certain obstacles with large cross sections such as loose fences and large sheets of metal (e.g., a tractor trailer) require additional clearance. For this kind of obstacle, double the recommended separation distance. Zone conditions The detection sensitivity of each zone depends on several factors: •...
  • Page 7: Mounting Angle

    Site design transmitter units receiver units maximum zone height 135 cm mounting heights 55 cm Figure 2 Stacking BR100 units Mounting angle For microwave pairs with a unit separation of 50 m or less, the microwave units are mounted with a 5º...
  • Page 8: Power Requirements

    PoE class 3 switch that is located within 100 m (328 ft.) of the transmitter/ receiver, and minimum Category 5 shielded network cable. Note Senstar recommends using a fully managed PoE switch to supply power to the BR100 transmitter/receiver. Page 8...
  • Page 9: Alarm Data Communications

    Site design Alarm data communications BR100 alarm data communications can be provided in two ways, via relays in Local control mode and over the Silver Network in Remote control mode. Each BR100 unit (transmitter and receiver) has two user-configurable relay outputs and one input. The relay contacts are held in the closed position during normal operation and open to signal an event, or if power is lost.
  • Page 10: Relay Contact Ratings

    A 2.5 m (8 ft.) post is generally used with 1 m (3.3 ft.) of the post buried in a concrete footing. Figure 6 is an illustration of a post-mounted BR100 unit. Note Senstar recommends hiring a local fencing contractor to install the BR100 mounting posts. Consult the local building code for information on installing mounting posts. Page 10...
  • Page 11: Surface-Mount Applications

    Site design BR100 unit 4.8 to 11.4 cm post power and alarm wiring in conduit mounting height from top of mounting bracket to ground ground level buried conduit to alarm panel & power supply concrete footing rebar through post Consult the local construction codes for information about using concrete footings in ares where ground freezing occurs.
  • Page 12: Br100 Alarm Reporting

    Site design BR100 alarm reporting The BR100 system reports a sensor alarm when a target disturbs the microwave field. If a large target (e.g., a vehicle) enters the microwave field and blocks the beam, the BR100 sensor goes into alarm and continues the alarm until the object leaves the field. If the calibration parameters are outside the valid range at startup, or during operation, the BR100 system goes into constant alarm until the calibration problem is corrected.
  • Page 13: Installation

    Installation The cover on each BR100 unit enclosure is secured with two captive screws that are factory installed to a finger-tight torque specification. There are no user-serviceable components inside the compartment. The cover should only be removed: • to access the circuit card assembly for setup and calibration purposes (via a UCM connection) •...
  • Page 14: Mounting The Br100 Units

    LED # Description LED # Description door open: enclosure door open fault: comm fault on B-side USB active: active UCM connection speed: communication speed TXA: transmitting data on A-side duplex: 2-way communications RXA: receiving data on A-side alarm: microwave sensor alarm active fault A: comm fault on A-side fail: major malfunction no detection TXB: transmitting data on B-side...
  • Page 15: Post-Mounting Procedure

    Post-mounting procedure 1. Pass the gear clamp through the slots in the mounting bracket. 2. Tighten the mounting bracket assembly on the BR100 unit. 3. On the mounting post, measure the mounting height of the BR100 unit and mark the post at that point.
  • Page 16: Surface Mounting Procedure

    post mounting slots mounting bracket 7 mm (0.25 in.) mounting holes Figure 10 Mounting setup Surface mounting procedure 1. Measure the mounting height of the unit from the ground and mark the surface at that point. 2. Using an 11 mm (7/16 in.) wrench, remove the hardware attaching the mounting bracket to the unit.
  • Page 17: Transmitter/Receiver Wiring Connections

    Transmitter/receiver wiring connections The BR100 wiring connections are made on 45º spring terminal blocks. The spring terminals accept wire sizes from 16 to 24 AWG with a 9 mm (0.35 in.) strip length. The DC power input is made on T4 and the input/output (I/O) connections are made on T4 and T5. Each unit’s auxiliary (AUX) input is available when using Remote control mode (network alarm data communications).
  • Page 18: Relay Contact Ratings

    Note The contact closure input to the AUX input must be voltage-free. Relay contact ratings The solid state relays are Form A (N.O.) rated for 60 V @ 100 mA maximum, non-inductive load. The relay contacts are held in the closed position during normal operation and open to signal an event, or if power is lost.
  • Page 19: Power Over Ethernet

    Note The BR100 units can use either Ethernet or RS-422 for network communications. CAUTION Senstar strongly recommends the use of external lightning protection devices for all outdoor cable runs (i.e., power, I/O, PoE, RS-422). Silver Network connections Figure 13 illustrates the data flow directions for an RS-422 based Silver Network.
  • Page 20 maximum 60 devices first device second device last device 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 shield shield Network Interface Unit shield...
  • Page 21: Stacking Br100 Units

    Stacking BR100 units To increase the height of the microwave field, it is possible to stack two units on one mounting post. The initial mounting height of the lower unit is 55 cm (22 in.) and the upper unit is 1.35 m (4.4 ft.) Each BR100 sensor must use a different Frequency Pair.
  • Page 22: Setup And Calibration

    BR100 setup and calibration should be performed by a qualified technician. BR100 setup and calibration is done using Senstar’s Universal Configuration Module (UCM). The UCM is a Windows-based software application that performs the calibration, setup, maintenance and diagnostic functions for Senstar’s line of intrusion detection sensors. The UCM connects directly to the BR100 unit via USB.
  • Page 23: Transmitter Setup

    Setup Transmitter setup 1. Remove the cover from the BR100 transmitter unit enclosure and use the USB cable to connect the UCM computer to the USB port on the PCB. 2. Start the UCM application and establish a connection. select the Network Type select the Device Type specify the connection the device ID displays...
  • Page 24: Setting The Transmitter Unit's Frequency Pair

    Setup Setting the transmitter unit’s Frequency Pair 1. With the UCM connected to the transmitter unit, select the Config tab. set the transmitter’s network address update the transmitter’s firmware select the Locale (region of operation) select the Frequency Pair the Power level displays (based on the selected Locale) Figure 19 UCM Config tab (transmitter unit) 2.
  • Page 25: Receiver Setup

    Setup Receiver setup After setting the transmitter’s Locale and Frequency Pair, the receiver can be setup and calibrated. 1. Connect the UCM to the receiver unit, and then select the Config tab. 2. Set the receiver’s Locale and Frequency Pair to match the transmitter’s settings. 3.
  • Page 26: Network Configuration

    Setup Network configuration For BR100 units that use network alarm data communications, you must define the network type under the Network Cfig tab. The network configuration can be set only by using a direct USB connection between the UCM computer and the USB port on the unit. 1.
  • Page 27: Input Configuration Procedure (Local Control Mode)

    The relays remain active for an event’s duration or for the selectable relay Active Time, whichever is longer. Note Senstar recommends that the relay outputs be configured to report Input Power Fail, and Fail Safe conditions, in addition to Microwave Alarms.
  • Page 28: Output Relay Setup (Remote Control Mode)

    Setup 1. Select a relay (the parameters listed below a relay apply only to that relay). 2. Specify the Hold/Active Time parameter. 3. Specify the conditions from the Local Aux Control Activation field under which this relay will activate. 4. Repeat this procedure for the second relay. 5.
  • Page 29: Receiver Calibration

    Receiver calibration Receiver calibration Once the BR100 transmitter and receiver are setup and configured, perform the receiver calibration. CAUTION Ensure that the microwave detection zone is not disturbed during the calibration process. 1. On the receiver’s UCM Status tab, select the Recalibrate button. The receiver performs a self-calibration.
  • Page 30 Receiver calibration Note Verifying the BR100 alignment on page 37 for information about using the UCM plot display to determine the received signal strength. The following procedure is best done with two people (one at the receiver and one at the transmitter). However, it can also be done by one person walking back and forth.
  • Page 31: System Verification Tests

    System verification tests System verification tests Once the setup and calibration procedures are completed, test and verify the BR100 sensor. The type of tests recommended to verify the proper operation of the BR100 system depends on the type of installation, and your site specific security requirements (see Site design on page 5).
  • Page 32 System verification tests set the Thresholds conduct tests raise Threshold(s) NAR = nuisance alarm rate NAs = nuisance alarms microwave lower Threshold(s) alarms? monitor NAR too many NAs? Recalibrate button verify installation installation OK? correct problems monitor NAR too many NAs? calibration complete Figure 22 BR100 verification test flow chart...
  • Page 33: Maintenance

    Maintenance This section details the recommended BR100 unit maintenance, site maintenance and testing required to ensure proper operation. BR100 unit maintenance Twice per year following major seasonal changes, inspect and clean the microwave units: • Use a soft damp cloth to wipe off the antenna covers. •...
  • Page 34: Br100 Testing

    To ensure the required level of detection, you should simulate the worst case scenario for your type of installation following the semi-annual recalibration (see System verification tests on page 32). Beam-break alarm test Depending on your site-specific security requirements, Senstar recommends conducting a beam-break alarm test: • daily for high security applications, •...
  • Page 35: Verifying The Br100 Alignment

    Verifying the BR100 alignment If the BR100 sensor is encountering detection problems it is possible that one of the unit’s may be out of alignment. The UCM includes a received signal strength indicator (RSSI) that indicates the signal strength at the receiver unit. Make minor adjustments to the alignment of both units to see if the RSSI can be increased.
  • Page 36: Updating The Firmware

    Updating the firmware Updating the firmware To update the BR100 unit’s firmware, begin by establishing a UCM connection. In the Program field, select the Application button. Select the Browse button, then navigate to the location of the .XDU file. Wait while the UCM downloads Once the programming is the .XDU file to the processor.
  • Page 37: Specifications

    Specifications Power consumption 1.2 W per unit (max.) • Operating range • 5 m to 100 m (16.4 ft. to 328 ft.) Beam width 20 cm to 4 m (8 in. to 13.1 ft.) • Velocity response • 3 cm/sec to 15 m/sec (1.2 in./sec to 50 ft./sec) •...
  • Page 38: Parts List

    Parts list Component Part Number Description BR100 microwave sensor system BR100 sensor E5FG0101 BR100 transmitter and receiver pair system BR100 transmitter unit transmitter unit E5EM0101 replacement transmitter unit BR100 receiver unit receiver unit E5EM0102 replacement receiver unit BR100 accessories 00SW0100 Universal Configuration Module software, Windows-based application, setup, calibration and diagnostic tool UCM cable...
