FPS 2-2
Fence Protection Systems
Installation &
Operation Manual
G2DA0102-001, Rev A
First Edition
August 7, 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FPS 2-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SENSTAR FPS 2-2

Summary of Contents for SENSTAR FPS 2-2

  • Page 1 FPS 2-2 Fence Protection Systems Installation & Operation Manual G2DA0102-001, Rev A First Edition August 7, 2009...
  • Page 2 The information provided in this guide has been prepared by Senstar Corporation to the best of its ability. Senstar Corporation is not responsible for any damage or accidents that may occur due to errors or omissions in this manual. Senstar Corporation is not liable for any damages, or incidental consequences, arising from the use of, or the inability to use, the software and equipment described in this guide.
  • Page 3 SENSTAR Corporation website: www.senstar.com email: info@senstar.com INSTALLATION AND OPERATION INSTRUCTIONS FENCE PROTECTION SYSTEMS August 2009...
  • Page 4 Limited Warranty The Company warrants that the electronic components of the products manufactured by the Company are free from all manufacturing defects. The Company's warranty does not extend to the performance of the products, which may vary depending on environmental conditions, use and installation practices. The Company's liability under this warranty shall be limited to, at its option, either repairing or replacing the defective components of the products or granting a credit for the products or parts thereof.

  • Page 5: Table Of Contents

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS CONTENTS PAGE QUICK START ..............9 GENERAL ................18 THEORY OF OPERATION ..........20 FENCE CONDITIONS ............23 INSTALLATION ..............27 INITIAL SETUP AND ADJUSTMENT ......... 57 SYSTEM START UP AND TESTING ........63 MAINTENANCE/TROUBLESHOOTING ......
  • Page 6 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS LIST OF FIGURES PAGE Figure 1 Typical MX-1000/5000/FPS System Conn ..10 Figure 2 Fence Mounted FPS Processor ......11 Figure 3 Cable Tie Installation ..........12 Figure 4 Transducer Cable Connections ......12 Figure 5 FPS Processor Wiring Connections .....
  • Page 7 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS LIST OF FIGURES ................PAGE Figure 37 Splice Termination ............ 43 Figure 38 End-of-Line Termination with 2 Megaohm Resistor................43 Figure 39 EOL Condulet attached to Fence ......44 Figure 40 Condulet Splice Attached to Fence ....44 Figure 41 Condulet “G”...
  • Page 8 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS This page intentionally left blank.

  • Page 9: Quick Start

    5000/ Fence Protection System, including installation of the MX-1000/5000, FPS-2-2M fence protection, and MPS microwave system. Prerequisites for using the quick start procedures are: • Attendance at one or more Senstar MX-1000/5000/ training class. • Prior MX-1000/5000 field installation experience.
  • Page 10 The interconnect cable must be an approved three-pair, 18-gauge, individually shielded twisted pair cable, with overall foil shield, braid shield, and high density polyethylene jacket, such as the Senstar Interconnect Cable or factory-approved equal. Figure 1. Typical MX-1000/5000 / FPS System Connections...
  • Page 11 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Mount each FPS processor as shown in Figure 2. • Use metal brackets or Unistrut-type mounting material to provide a solid backing. A fence post will provide a solid mounting. • Arrange the conduit/control wiring entrance as shown. •...

  • Page 12: Transducer Cable Connection

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Run the sensor cable from each FPS processor as shown in Figures 2 and 3. NOTE: Your installation may utilize either standard "black" sensor cable or Helisensor. Observe special requirements for each type sensor. •...
  • Page 13 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Connect the control wiring to each processor as shown in Figure 5. • Verify that all shields are connected as shown. Keep the shields separate as shown. DO NOT connect the individual cable shields to one another. •...
  • Page 14 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Mount each MPS microwave unit (pair) as shown in Figure 6. Note that the installation includes the microwave pair and the stand-alone transponder. • Install each piece of equipment generally as shown. Figure 6.
  • Page 15 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 7. MPS-4100TR Host Receiver Connections to MX-1000/5000...
  • Page 16 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Connect the power supply transformer and battery as shown in Figure 8. Figure 8. MX-1000/5000 Power Supply Connections • Connect the transponder loop cable as shown in Figure 9. Perform the connections for each transponder loop connected to your system.
  • Page 17 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 9. MX-1000/5000 Loop Connections...

  • Page 18: General

    Two zone alarm processor for use with fiber optic communication system Senstar FPS systems can be used individually or combined with several FPS units and an alarm control system and accessories, providing the fence protection for the complete facility perimeter.

  • Page 19: Table 1 Fps Features

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ FPS-EX 1 Zone Cost effective ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ FPS-EXH 1 Zone Cost effective ✔...

  • Page 20: Theory Of Operation

    Any movement in the fence causes a small voltage to appear at the sensor cable output. Senstar tests every foot of the sensor cable to verify that the alarm sensitiv- ity will be uniform over the entire length.
  • Page 21 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS The FPS system is capable of monitoring a transducer cable in excess of 1000 feet, depending on the total capacitance of the cable attached to the sensor input. The graph, Table 2, indicates the sensor cable capacitance relative to length.

  • Page 22: Table 2 Sensor Cable Capacitance

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 11. Block Diagram Table 2. Sensor Cable Capacitance...

  • Page 23: Fence Conditions

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS 4 FENCE CONDITIONS Fence Conditions When the FPS Transducer Sensor Cable is installed on the fence, the sensor cable and the fence be- come the fence protection system. In effect, the sensor cable listens to the fence to detect the signals caused by climbing, jacking, or cutting the fence.
  • Page 24 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 14 Loose fabric or clamp rings at steel wire stiffeners Figure 15 Barbed wire dangling due to missing keepers Figure 17 Missing vertical locking Figure 16 Mounting pole brackets for barbed posts wire, concertina or razor ribbon not properly secured to the fence posts...
  • Page 25 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 18 Excessive play between locking posts and metal insert Figure 19 Chain and lock free to vibrate against gate Figure 20 Too much play between rollers Figure 21 Signs and/or foreign objects not and rails securely attached to the fence fabric or posts...
  • Page 26 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Additional Sources of Nuisance Alarms Further inspection may disclose some of the following conditions that may need correcting: Cables, pipes, wires, other fences, limbs, bushes, flagpoles, etc., that may move in the wind and transfer vibrations to the fence.

  • Page 27: Installation

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS 5 INSTALLATION General The installation of the FPS System consists of a systematic installation of FPS processors, transducer cable, special fence protection units, such as gate protection, and connection to the alarm processing system.
  • Page 28 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 22. Fence-mounted Processor...
  • Page 29 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS When mounting to a fence post, proceed as follows: Fabricate or purchase two pieces of Unistrut or similar type material, for each FPS processor location. The Unistrut should be sufficient length for the processor enclosure or the mounting box as shown.
  • Page 30 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 23. Processor Remote Mounting...
  • Page 31 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 24. Processor Pedestal Mounting Transducer Cable Installation Installation of Standard Coaxial Transducer Cable Installation of the standard coaxial transducer cable is best accomplished with a minimum of two people; one person to unreel the cable (see Figure 25) while the second person attaches the cable to the fence.
  • Page 32 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 25. Unreeling Cable CAUTION: Extreme care should be used when handling the transducer cable as nicking or scraping the outer jacket, and kinking or knotting the cable will shorten the operational life and permit unwanted interference to enter the signal processor. The transducer cable should be left with enough length at the signal processor for a service loop to be used as a moisture drip leg.
  • Page 33 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 26. Cable Tie Installation When the transducer cable is routed from the fence to pass around a fence post or standard and return again to the fence, be sure to leave a slightly loose, but not drooping, loop. Otherwise, when the fence is stressed, the cable can chafe, wearing through the cable jacket.
  • Page 34 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 27. Transducer Cable Around Fence Post Figure 28. Transducer Cable Service Loop The fence fabric on either side of a corner post is quite rigid due to both horizontal and diagonal stiffeners.
  • Page 35 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 29. Increasing Transducer Cable Sensitivity Overlap of adjacent zones is not required but may be desired by some customers. Refer to Figure 30 if overlap is desired. If, at the end of a zone there is an excess of transducer cable, do not coil excess cable as this may become hypersensitive and be the source of nuisance alarms.
  • Page 36 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 30. Zone Overlap...
  • Page 37 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Transducer Cable Installation With Two or More Persons Begin at one end of a zone with one person unrolling the cable and one person loosely tying the cable to the fence. Using cable ties, loosely tie the cable to the fence every 20 to 30 feet to keep it off the ground.
  • Page 38 NOTE: Do not use ordinary cable ties because they will not withstand the effects of sunlight. Senstar provides the proper cable ties with each roll of sensor cable. The Helisensor installation procedure is very similar to the installation of standard coaxial transducer cable, with added requirements for trimming the zone to size.
  • Page 39 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS through the termination box and conduit and to the terminations inside the processor enclo- sure. Terminate the Helisensor to the enclosure as shown in Figures 31 or 32, using the 1/2-inch conduit termination provided. Helisensor should be attached to 1/2-inch conduit fitting before it is secured in the processor enclosure.
  • Page 40 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 32. Helisensor Installation/Termination to NEMA Enclosure...
  • Page 41 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 33. Retrofit Helisensor Termination to Standard FPS Processor...
  • Page 42 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Condulet Installation The Condulet circuit board has been re-designed with the end-of-line resistors built into the board and conformal coatingto prevent moisture in the condulet from shorting the EOL resistors - a com- mon cause of tamper alarms.

  • Page 43: End-Of-Line Termination With 2 Megaohm Resistor

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS For end-of-line termination, attach sensor cable to terminals as shown in Figure 36. Clip jumpers 2 & 4. For double end-of-line terminations, attach sensor cables to both terminals. MAKE 2 CUTS ON EACH JUMPER Figure 36.
  • Page 44 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 39. EOL Condulet Attached to Fence Figure 40. Condulet Splice Attached to Fence Figure 41. Condulet “G” Attached to Fence...

  • Page 45: Transducer Service Kit

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Transducer Service Kit (TSK) Installation Transducer service kits (TSK) are required for all end of line termination and splicing of standard transducer cable. TSK installation is very important to be sure that moisture does not affect transducer cable operation.

  • Page 46: Transducer Cable Preparation

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 42. Transducer Service Kit Figure 43. Transducer Cable Preparation...
  • Page 47 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Gate Installations Gates, including sally ports, require the same protection as the fence. There are many types of gates, but they are generally swinging or sliding. Additionally, gates can be installed as either single or double gates.

  • Page 48: Telegate Installation

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS As the transducer cable approaches the gate, it is tied to the fence fabric, turned and run up vertically approximately one foot, then turned horizontally and tied to the upright gate support post near, but not on, the upper hinge.
  • Page 49 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS The recommended position of the support post for each Telegate is approximately 5 feet from the end of the sliding gate when opened to the maximum position, and not less than 1 foot or more than 2 feet from the centerline of the fence posts on the gate side of the fence.
  • Page 50 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Step 4 Remove the bottom cap by first removing the three 1/4-inch screws. Remove the cap by gently tapping the lip. Step 5 Remove the cable tie and tape and uncoil the armored cable at the top of the Telegate tube. Be careful because when you uncoil the cable the weight can fall to the bottom of the Telegate tube.
  • Page 51 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Microwave Gate Protection The Senstar MPS-4100 microwave system provides coverage of the area around a gate while allowing the gate to move freely. See Figure 47. The FPS transducer cable can terminate at the end of a zone on either side of the gate or nonsensitive cable can be spliced and run underground in conduit to continue the zone.
  • Page 52 The FPS-2-2M includes a transponder circuit board which enables multiplex CEnDe communications to the Senstar MX-1000/5000 Security and Control Center or the Data Collection Unit (DCU). The transponder card requires the proper code to communicate with the control centers.
  • Page 53 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS NOTE: The shields for the data and audio lines are purposely kept separate. DO NOT connect these shields together. EDAPT configured FPS-2-2M units install and connect in the same way as standard units but require different switch and jumper settings.
  • Page 54 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS...
  • Page 55 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS...
  • Page 56 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 51. Relay Jumper Options Special Circuits The FPS-2-2R includes a test input (terminals 7 and 8) which allows testing of each alarm zone. The testing injects an alarm signal at the transducer cable input which, if operating correctly, will produce an alarm output (relay operation).

  • Page 57: Initial Setup And Adjustment

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS 6 INITIAL SETUP AND ADJUSTMENT Processor Adjustments Initial setup and adjustment consists of setting option jumpers and transducer cable gain and count switches. The gain and count switches are the same for both the FPS-2-2M and FPS-2-2R. Switches and jumpers are located on each processor circuit card, so there are two sets of switches, one for each processor zone.
  • Page 58 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Gain Switch S-1. This switch is a four position dip switch set in a binary code for values from 1 to 10. This switch controls the signal processor sensitivity. The higher the number, the more sensitive that zone becomes.
  • Page 59 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Main Board Jumper Settings The main board has jumpers which must be set to configure the processor for either standard or EDAPT operation. Revision C boards have 5 jumpers, Rev D boards have 7. Standard operation is used with all FPS-2-2R units and all standard FPS-2-2M units.
  • Page 60 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Jumper Positions There are two types of FPS-2-2M transponder boards, both of which have factory installed jumpers. The jumpers are set at the factory and SHOULD NOT be changed in the field. Figures 54 and 55 are provided for reference only to show the correct jumper settings for the two types of transponder boards.
  • Page 61 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure 55. Revision G Transponder Board...
  • Page 62 N.C. position. Supervision Each relay output has provisions for the 3 K ohm Senstar supervisory circuit. If the circuit is to be super- vised by a Senstar alarm monitor, or a system from another manufacturer requiring a 3 K ohm resistance circuit, place the jumper in the B position.

  • Page 63: System Startup And Testing

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS 7 SYSTEM STARTUP AND TESTING General System startup and testing consists of powering up the system and making tests to verify proper operation and detection of fence disturbances. Initial testing consists of verifying the continuity and integrity of the transducer cable installed in each zone and the power supply to each processor.
  • Page 64 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS In (b) above, if the reading is other than noted, the cause is due to a break or abrasion in the outer jacket of the transducer cable, causing a short between the shield and the fence fabric. DO NOT continue with testing until the problems have been found, repaired, and an acceptable resistance measurement is attained.
  • Page 65 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Testing Using Senstar’s Field Test/Monitor Unit. NOTE: The Field Test/Monitor Unit can be used to test either the FPS-2-2M or the FPS-2-2R units. Step 1. Remove processor cover. Step 2. Verify that the signal processor gain switch S-1 is set to 4.
  • Page 66 System checkout usually involves testing the complete system from the fence to the central control point including alarm control and remote alarm annunciation. If you are using one of Senstar’s monitor/ display options, refer to the appropriate manual for check-out and operation:...

  • Page 67: Maintenance/Troubleshooting

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS 8 MAINTENANCE / TROUBLESHOOTING General The entire system will continue to perform efficiently only if it is properly maintained. It is highly recommended that the entire system be thoroughly tested and tuned once every three to four months.
  • Page 68 NOTE: Tamper alarms caused by moisture penetration can be intermittent. To repair a damaged transducer cable, splice kits are available from Senstar that require no special tools and can be performed in about 5 minutes. (See Section 5, TSK Installation) Systematic Testing Problems sometimes occur due to equipment failures.

  • Page 69: Procedures

    Repairs to equipment and circuits con- tained in the alarm processor are not recommended. Return components thought to be defective to Senstar for repair in accordance with the repair procedure. Include information describing the nature of the problem with the returned component.

  • Page 70: Table 3 Fps-2-2(*) Troubleshooting Table

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Table 3 FPS-2-2(*) Troubleshooting Table...
  • Page 71 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS...
  • Page 72 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS This page intentionally left blank.

  • Page 73: Fps-2 Connections

    INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS ADDENDUM This addendum addresses the unique aspects of installing the FPS-2 and FPS-EX processors. It is to be used in conjunction with the FPS-2-2 Installation and Operation Instructions. The FPS-2 and FPS-EX are variants of a single board, single zone FPS (Fence Protection System) proces- sor, which is identical in concept and application to the FPS-2-2 dual zone devices.
  • Page 74 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Tamper Switch S-2. This switch, when secure, is “normally closed.” The switch contacts open when the enclosure lid is removed. Variable Resistors R73. This variable resistor is preset at the factory to provide an output voltage of approximately 6.5 VDC at Test Point 7 (TP-7).
  • Page 75 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure A-1. FPS-2 Connections...
  • Page 76 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS Figure A-2. FPS-EX Connections...
  • Page 77 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS...
  • Page 78 INSTALLATION AND OPERATION INSTRUCTIONS — FENCE PROTECTION SYSTEMS...
