AGP Intex Giraffe GHOST Operation Manual page 5

To Install SuperPad
1. Unplug the machine.
2. Peel away the worn out sandpaper disc, leaving the sponge backing pad in place.
3. Carefully center the new sandpaper disc and press into place. It will be held securely by the hook and loop backing.
NOTE: The sponge pad has 2 different hook profile types. The black side is finer hook, the white side is
coarser hook. Choose the side which adheres best to your sandpaper.
To Replace Cushioned Interface Pad
The sponge pad must be perfectly flat to get good sanding results. If it is deformed or damaged it will cause very
uneven sanding. Always replace it when damaged. It is hook and loop on both sides, so to Replace it, peel it away from
the hook and loop on the Sanding Plate Base and, taking great care to keep it perfectly centered, affix a new one.
CAUTION: Ensure that the holes in the Sponge Pad are perfectly aligned with the slots in the Sanding Plate Base.
Improper alignment will lead to excessive vibration.
CAUTION: Only use original parts Sponge Pads for replacement. Outside-sourced sponge pads will not function
properly with this tool.
To Replace Brush Bristles
The brush bristles on the edge of the Sanding Plate Cover serve two
purposes, they keep the sanding disc properly aligned with the work
surface without gouging and they also help the efficiency of the dust
collection by the vacuum cleaner. These brush bristles will wear with
continued use.
The Sanding Plate Cover should be replaced when the bristles are
too worn to ensure effective dust collection and stabilization of the
sanding head.
8
Intex Giraffe GHOST intexinternational.com
® ™
Vacuum Cleaner
Ensure that you have a bag installed in your vacuum cleaner which is approved and rated for drywall dust.
WARNING: Failure to use an approved dust bag in your vacuum will increase the level of airborne dust in the work
area. Prolonged exposure to such dust may cause respiratory harm.
Starting & Stopping Tool
Make sure that the power circuit voltage is the same as that shown on the specification plate
of the machine before connecting the tool to the power circuit.
To switch on:
While holding with the left hand on the shaft and the right hand on the
main handle, first press the Power Button to energize the tool, then
press the Motor On/Off button to start the tool. Anticipate and be ready
for the start up torque when the machine first starts.
To switch off:
Press the Power Button. After the machine has been switched off, the
sanding disc will still rotate for a time. Take care that parts of your body
do not come into contact with the disc and do not set the machine down
while it is still rotating!
Adjusting Rotation Speed
The speed of the machine is variable to suit different tasks.
It can be adjusted from 780/min up to 1250/min in steps of 80/min by
pressing the "Up" and "Down" Speed Selector Buttons. Press "Up" to
increase the speed and "Down" to decrease the speed. The selected
setting will appear on the indicator screen.
Generally, you should use higher speeds for fast stock removal and
lower speeds for more precise control. Note: For fine finish sanding,
use lower speed and fine grit sandpaper discs.
How to operate Hour Tracker
Job Hours Counter (resettable)
1. Press Power Button to turn ON machine
2. Press Power Buttonn again and hold it down while pressing Speed Selector Up Button then pressing Speed Selector
Down Button (i.e. hold Power + , )
3. While continuing to hold the Power Button down, the display will flash "H" followed by the digits in succession
indicating the number of hours, followed by a long pause and then repeat.
Job Hours Counter Resetting
1. Press Power Button to turn ON machine
2. Press Power Button again and hold down while pressing Up then Down 3 times in succession
(i.e. hold Power + , , )
3. Continue to hold the Power Button down and the screen will flash 3 times. The counter is now reset.
Total Hours Counter (not resettable)
1. Press Power Button to turn ON machine
2. Press Power Button again and hold down while pressing Up, Up then Down, Down (i.e. hold Power + , )
3. While continuing to hold the Power Button down, the display will flash "H" (with the dot in the lower right corner of the
screen illuminated), followed by the digits in succession indicating the number of hours, followed by a long pause and
then repeat.
WARNING: To reduce the risk of injury user must read and understand operator's manual.
Indicator
Screen
(1) Power Button
Speed
Selector
Buttons
(2) Motor On/
Off Button
