5.5.11 Pro-AIn-32/16 Rev. B
To this module you find an improved successor module
(see page 63).
The analog input module Pro-AIn-32/16RB has a 16-bit ADC and a program-
mable gain amplifier (PGA). It has 32 single-ended or 16 differential inputs
(software selectable). The inputs are connected on a 37-pin DSUB socket. The
module can be combined with Pro-TC and Pro-PT modules.
The module Pro-AIn-32/16RB is equipped with an input voltage range of ± 10V
and a gain amplifier, programmable by software to 1, 2, 4 or 8. The adjustment
of gain and offset is made by software (see
ware").
1
330k
330k
2
3
330k
330k
4
31
330k
330k
32
Fig. 103 –
On Startup the module is set to 16 differential inputs.
Figures 105 and 106 show the pin assignments of the module. Please consider
the different pin assignment for differential and single-ended inputs.
.
Input channels:
Resolution:
Conversion time:
Sampling rate:
Multiplexer settling time:
Measurement ranges:
Gain:
Accuracy INL
DNL
Input resistance:
Input over-voltage:
Offset error:
Offset drift:
Connector:
Fig. 104 –
ADwin-Pro Hardware, manual version 2.9, June 2006
chapter 6.3.1 "Calibration per Soft-
MUX
PGA
A
Vu= 1, 2, 4, 8
Pro-AIn-32/16 Rev. B: Block diagram
32single-ended oder 16 differetial;
via multiplexer
16 bit
max. 8µs
max. 100ksps
14µs
±10V
1, 2, 4, 8 software selectable
max. ±3 LSB
max. +3, -2 LSB
330kΩ, ±2%
±17V
adjustable
±20 ppm/ºC
37-pin DSub socket
Pro-AIn-32/16 Rev. B: Specification
Pro I: Analog Input Modules
Pro-AIn-32/16 Rev. C
Data
Data Data
Register
D
Address
Addr.
Decoder
Pro-AIn-32/16 Rev. B
