Front Panel
The front panel provides LED's for device status. Refer to the following
table for the meaning of each feature.
LED STATUS
Power Off
On
Status Blink
Off
Ethernet Green On 10/100Mbps Fast Ethernet link detected. No activity.
Green Blink Indicates data traffic on the 10/100 Mbps LAN
11a Blink
11b Blink
Rear Panel
The rear panel features 1 LAN port and Factory Reset button. Refer to the
following table for the meaning of each feature.
Power Used to connect to the power outlet. Only use the power adapter
(DC 5v) provided with the device. Use of an unauthorized power adapter
may cause damage to your device and violate your warranty.
Reset Reset the configuration to default settings.
There are two ways to Reset to factory defaults of the Access Point.
Briefly press the Reset Button for approximately ten seconds, or use
the setup tab of the Web-Based Management Utility.
LAN The RJ-45 Ethernet ports used to connect your PC, hub, switch or
Ethernet network.
Wireless Broadband Anywhere
Description
No Power
Power on
1. Power up 2. firmware upgrade
no Ethernet link detected
Indicates the device is linking or active data through wireless links
Indicates the device is linking or active data through wireless links
