Gemtek Technology Co., Ltd.
WX-5520A
Dual Band WLAN Access Point
User's Manual
Oct. 15, 2002 (Draft 1.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WX-5520A and is the answer not in the manual?

Questions and answers

Related Manuals for Gemtek WX-5520A

Summary of Contents for Gemtek WX-5520A

  • Page 1 Gemtek Technology Co., Ltd. WX-5520A Dual Band WLAN Access Point User's Manual Oct. 15, 2002 (Draft 1.0)

  • Page 2: Table Of Contents

    ................4 WX-5520A AP Default Settings ...… … … … … … … … … … … … … … … ..5 Web Management Settings … … … … … … … … … … … … … … … … 6 Start - Up &...

  • Page 3: Introduction

    WX-5520A Dual Band Access Point Introduction Thank you for purchasing your WX-5520A Dual Band Wireless Access Point. This user guide will assist you with the installation procedure. The package you have received should contain the following items: • WX-5520A Dual Band Wireless AP •...
  • Page 4 WX-5520A Dual Band Access Point Safety Notification Your Wireless AP should be placed in a safe and secure location. To ensure proper operation, please keep the unit away from water and other damaging elements. § Please read the user manual thoroughly before you install the device.

  • Page 5: Hardware Installation

    WX-5520A Dual Band Access Point Hardware Installation Front Panel The front panel provides LED’s for device status. Refer to the following table for the meaning of each feature. STATUS Description Power No Power 　 Power on Status Blink 1. Power up 2.

  • Page 6: Wx-5520A Ap Default Settings

    WX-5520A Dual Band Access Point WX-5520A AP Default Settings The default settings are shown following. User Name admin Password 1234 AP Router IP Address 192.168.5.1 AP Router Subnet Mask 255.255.255.0 RF ESSID Wireless 11a RF Channel 11b RF Channel RF Roaming...

  • Page 7: Web Management Settings

    (Microsoft Internet Explorer or Netscape) and manually input 192.168.5.1 into the address box (as shown below) and press Enter key. In order to configure the WX-5520A Wireless AP, please input the user-name into the User Name box. Enter the password into the Password box and press the OK button. The default User Name is admin, and the default password is 1234.

  • Page 8: Main Page

    WX-5520A Dual Band Access Point MAKE CORRECT NETWORK SETTINGS OF YOUR COMPUTER To change the configuration, use Internet Explorer (IE) or Netscape Communicator to connect the WEB management 192.168.5.1. Main Page Here allow user to configure basic network settings. Wireless Broadband Anywhere...

  • Page 9: Setup

    WX-5520A Dual Band Access Point Setup page The Setup page allow user to configure basic settings. Enter your wireless network’s SSID, select the channel at which the network broadcasts its wireless signal, and enter IP address and subnet mask for the Access Point. Press Apply & Restart button to save the settings.

  • Page 10: Password

    WX-5520A Dual Band Access Point Channel: Select the appropriate channel from the list provided to correspond with your network settings. You shall assign a different channel for each AP to avoid signal interference. Data Rates: The basic transfer rates should be set depending on the speed of your wireless network.

  • Page 11: Firmware Upgrade

    WX-5520A Dual Band Access Point Firmware Upgrade User may download the latest firmware from your vendor’s website and store it in local drive. Find the firmware from local drive and press the Upgrade & Restart button. Restore Default Press OK button will make the AP reset to factory default settings.

  • Page 12: Security

    WX-5520A Dual Band Access Point Security Authentication Type: Open System: The Authentication Type default is set to Open System It is recommended that you use the default setting. Shared Key: Shared Key is when both the sender and the recipient share a secret key. All points on your network must use the same authentication type.

  • Page 13: Access Control

    WX-5520A Dual Band Access Point Access Control The Access Control tab, allows you to block or allow certain computers by their MAC Address. To enable filtering of computers by their MAC Addresses, click the Enable radio button. Enter MAC Address and click Add button.

  • Page 14: Advance Setup

    WX-5520A Dual Band Access Point Advance Setup Beacon Interval: This value indicates the frequency interval of the beacon. A beacon is a packet broadcast by the Access Point to keep the network synchronized. A beacon includes the wireless LAN service area, the AP address, the Broadcast destination addresses, a time stamp, Delivery Traffic Indicator Maps, and the Traffic Indicator Message (TIM).

  • Page 15: About

    WX-5520A Dual Band Access Point next window for listening to broadcast and multicast messages. When the Access Point has buffered broadcast or multicast messages for associated clients, it sends the next DTIM with a DTIM Interval value. Access Point Clients hear the beacons and awaken to receive the broadcast and multicast messages.

  • Page 16: Troubleshooting

    WX-5520A Dual Band Access Point Troubleshooting Basic Functions My Wireless AP will not turn on. No LED’ s light up. Cause: § The power is not connected. Resolution: § Connect the power adapter to your AP and plug it into the power outlet.
  • Page 17 WX-5520A Dual Band Access Point Resolution: § Make sure that each computer has a unique IP Address. If using DHCP through the AP , makes sure that each computer is set to “Obtain an IP Address automatically” and restart the computer.

  • Page 18: Technical Specifications

    WX-5520A Dual Band Access Point Technical Specifications Standards: IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.11b IEEE802.11a Protocols Supported: DHCP Client Management: Web-Based Ports: LAN: 10BASE-T/100BASE-TX Fast Ethernet Wireless AP Specifications General Wireless Specifications: IEEE 802.11b /11a Wireless LAN, Wi-Fi Compatible...
  • Page 19 WX-5520A Dual Band Access Point Access Point Data Rate: 11a : 6,9,12,18,24,36,48,54 Mbps. Turbo: 72 Mbps 11b: 11 Mbps 5.5 Mbps 2 Mbps 1 Mbps Data encryption: 64/128/152 bit WEP Power Specifications : DC power supply Input: DC 100-250 50-60 Hz 1A...

  • Page 20: Federal Communication Commission Interference Statement

    WX-5520A Dual Band Access Point Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 21: R&Tte Compliance Statement

    WX-5520A Dual Band Access Point R&TTE Compliance Statement This equipment complies with all the requirements of the DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of 9 March 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE).
