Available Documentation; System Overview - Comelit HUB32LCD Quick Installation Manual

Available documentation

The SECUR HUB system comes with a series of technical manuals containing detailed information for the installation,
programming and use of the control panel and the available accessories.
• Quick installation manual: This document contains all the information required for product installation and initial startup.
• HUB32LCD installation and programming manual: this document contains all the information required to program a Secur
HUB system via keypad.
• Secur HUB Manager programming manual: this document contains all the information required to program a Secur HUB
system using Secur HUB Manager software.
• HUB32LCD user manual: this document contains all the information required by the end user of a Secur HUB system.
• The documentation is available online, at mycomelit.com

System overview

Comelit art. HUB32LCD is a wireless intruder alarm control panel for use in residential applications and in small- and medium-
sized commercial applications. It has a 16 x 2-character display and a Capsense keypad which allows rapid navigation of the
installer and user menus.
A fundamental advantage of art. HUB32LCD lies in its easy installation and programming: a built-in installation wizard allows
quick system startup, even without using a PC. The programming tools include Windows-based software with confi guration
level selection and an integrated text menu.
Featuring native support for Internet and cloud connection via built-in WiFi and LAN, art. HUB32LCD uses cloud-based
communication for confi guration and remote use, without requiring port forwarding on the router.
Communication between the control panel and the wireless devices takes place by means of a secure and encrypted two-way
protocol which makes it possible to constantly monitor message transmission effi ciency.
In addition to the built-in keypad and the two-way remote controls, users can fully manage art. HUB32LCD using Comelit app,
the application for mobile devices (iOS and Android platforms) which also utilises all the system video verifi cation functions if
IP cameras are installed in the network. Up to four HD IP cameras can be recorded continuously to capture CCTV relating to
events, including 10 seconds of pre-event recording. Live streaming of cameras is also available on the app (MAX 16 cameras).
Thanks to the built-in loudspeaker and microphone, art. HUB32LCD off ers two-way audio communication for personal use
or audio verifi cation of alarms using the 2G or 3G module. For greater usability, voice messages can be enabled for the main
system procedures.
A full set of event signalling channels is provided to satisfy all requirements, including push notifi cations with video verifi cation,
e-mail and IP-based digital protocols for alarm receipt control panels. When a 2G or 3G GSM module is installed, SMS, voice
calls and digital audio protocols are also available.
A wide range of wireless devices is available to satisfy all installation requirements. Refer to the pages below for details of
available products.
