S Y S T E M M A N U A L
Scansionare il seguente codice QR per leggere questo manuale in italiano
Encadrer le code QR ci-après pour lire ce manuel en français
Scan de volgende QR-code voor deze handleiding in het Nederlands
Escanear el siguiente código QR para leer este manual en español
Warning
Intended use
This Comelit product has been designed and manufactured for use in the
creation of security and automation systems in residential, commercial,
industrial and public buildings.
Installation
All activities connected to the installation of Comelit products must be
carried out by qualified technical personnel, with careful observation of
the indications provided in the Manuals / Instruction sheets supplied with
those products. The product must be installed to the highest standards.
Wires
Disconnect the power supply before carrying out any operations on the
wiring. Use wires with a cross-section suited to the distances involved,
observing the instructions provided in the system manual. We advise
against running the system wires through the same duct as power cables
(230V or higher).
Safe usage
To ensure Comelit products are used safely:
• carefully observe the indications provided in the Manuals / Instruction
sheets
• make sure the system created using Comelit products has not been
tampered with / damaged.
Maintenance
Comelit products do not require maintenance aside from routine cleaning,
which should be carried out in accordance with the indications provided in
the Manuals / Instruction sheets.
Any repairs must be carried out:
• for the products themselves, exclusively by Comelit Group S.p.A.,
• for the systems, by qualified technical personnel.
Do not use alcohol or aggressive products for cleaning purposes.
Disclaimer
Comelit Group S.p.A. does not assume any responsibility for:
• any purpose other than the intended use
• failure to observe the indications and warnings contained in this Manual
/ Instruction sheet.
Comelit Group S.p.A. reserves the right to change the information
provided in this Manual / Instruction Sheet at any time and without prior
notice.
Directives
The manufacturer, Comelit Group S.p.A.,  hereby declares that
this equipment conforms to the applicable directives. The full EU
conformity declaration is available on the product web page.
Vedo 2.15.x
VEDO10
VEDO34
VEDO34M
VEDO68
VEDO68M
VEDO200
VEDO200M
In accordance with art. 26 of Italian Legislative Decree dated
14th March 2014, no. 49 "Implementation of directive 2012/19/
EU on Waste Electrical and Electronic Equipment (WEEE)". the
"crossed-out wheelie bin" symbol indicates that at the end of its
useful life, this product must be separated from other waste
before collection for disposal. The user should therefore take the exhausted
appliance to suitable local collection centres for waste electrical and
electronic products. As an alternative to handling this process yourself,
you can take the appliance to your local equipment dealer when purchasing
a new equivalent product. Electronics dealership businesses covering an
area of 400 m² are also obliged to accept waste electronic products
smaller than 25 cm for disposal, without any obligation to purchase.
Suitable separated waste collection for the subsequent reuse of the
appliance sent for recycling, processing and environmentally conscious
disposal helps to avoid potential negative effects on the environment and
human health, and encourages the reuse and recycling of the materials
used in the construction of the appliance.
Key to symbols
ISO 7000-0434
Caution! Refer to the documentation
ISO 3864
Caution! Risk of electric shocks
ISO 7000-1641
Read the operating instructions
IEC 60417-5017
Earth connection
IEC 60417-5134
Devices sensitive to static electricity
IEC 60417-5031
Device powered with direct current
(2002-10)
