Summary of Contents for Comelit ERACLE 16
- Page 1 ERACLE 16 43CPC016EN CONVENTIONAL FIRE ALARM CONTROL PANEL WITH 8 TO 16 ZONES INSTALLATION AND OPERATION MANUAL...
-
Page 2: Table Of Contents
Contents 1. GENERAL INFORMATION ....................4 2. TECHNICAL SPECIFICATIONS ................... 4 2.1 General Technical Specifications of ERACLE 16 ............4 2.2 General Technical Specifications of Relay Module 43ECR032 ......... 5 3. INSTALLING ERACLE 16 ...................... 6 3.1 Wall Mounting ......................7 3.2 Flush Mounting ...................... - Page 3 Operational reliability Pass Durability of operational reliability and response delay: temperature resistance Pass Durability of operational reliability: humidity resistance Pass Durability of operational reliability: vibration resistance Pass Durability of operational reliability: electrical resistance Pass ERACLE 16 - Installation and Operation Manual...
-
Page 4: General Information
16 separate zones, depending on the installed configuration. The ERACLE 16 must be installed according to the Fire Alarm Installation Regulations, mandatory for the territory of the respective country. The electrical power supply to the panel must be isolated and must not be capable of being accidentally switched off. -
Page 5: General Technical Specifications Of Relay Module 43Ecr032
• Humidity Up to 93% (non condensing) WARNINGS: Prior to connecting the ERACLE 16 Fire Alarm Panel, perform a thorough test of the all wiring integrity of the entire system. Should a fault arise during installation and connection, which cannot... -
Page 6: Installing Eracle 16
230 V clamps, to the metal bottom clamps and to the chassis. • After all system programming and testing operation are complete, screw both secure bolts with the help of the hexagonal tool supplied. Figure 1. Figure 2. Figure 3. ERACLE 16 - Installation and Operation Manual... -
Page 7: Wall Mounting
(Positions 17 and 18, page 31) - Figure 7, Position 2. 25mm THICK DRYWALL METAL BOX HANGER SCREWS FOR HANGER FIXING SCREWS FOR FLUSH MOUNTING WASHER Figure 6. Figure 7. ERACLE 16 - Installation and Operation Manual... -
Page 8: Configuration Of The Basic Modules
• 2 - Clamp for supporting the main power supply cable. • 3 - Terminal for connecting between the mains power supply and the power source. T-type fuse 2A (Position 3, page 31). • 4 - Earthing point. ERACLE 16 - Installation and Operation Manual... -
Page 9: Control Module
- Jumper for enable/disable Earth Fault Indication; - Resettable (PTC) fuses; - Connector for connecting the main power source; - Connector for connecting 4-zone / 4-sounder expander; - Connector for connecting the control panel keypad. ERACLE 16 - Installation and Operation Manual... -
Page 10: Main Power Source
Attention: It is possible that the battery might not be charged at the panel initial start-up. In this case the BATT LOW/LOST at the control module and the GENERAL FAULT at the front panel will light on until the battery will be charged up to the required level. ERACLE 16 - Installation and Operation Manual... -
Page 11: 4-Zone Expander
Before connecting or disconnecting the expander you SHOULD check whether the main and the stand-by power supplies are OFF! The metal box of ERACLE 16 can accommodate up to 4-zone expanders. To each zone can be connected up to 32 conventional detectors with consumption <200µA at normal operation mode and unlimited number of manual call points. -
Page 12: 4-Sounder Expander
5 6 7 8 First а) First Second Control First First Second Control 4 Sounder 4 Zone 4 Zone panel 4 Zone 4 Sounder 4 Zones panel Expander Expander Expander Expander Expander Expander Figure 16. ERACLE 16 - Installation and Operation Manual... -
Page 13: Connecting
4. CONNECTING 4.1 Relay Module 43ECR032 43ECR032 is a supplementary module which is located outside the ERACLE 16 Alarm Panel box. The 43ECR032 contains 8 changeover contact relays. When using all 16 zones, the ERACLE 16 needs two relay modules. - Page 14 Terminals and jumper 43ECR32 configuration of 43ECR032. Figure 18. Master Connecting between Panel one Relay Module ERACLE 16 and Master Panel. Master Figure19. Panel Connecting between ERACLE 16 two Relay Modules and Master Panel. ERACLE 16 - Installation and Operation Manual...
-
Page 15: Repeater Panel
4.2 Repeater Panel A second ERACLE 16 can be connected to the ERACLE 16 Fire Alarm panel as Slave. The function of the Slave is to double the light and sound indication and the button control of the first panel at a distance up to 1000 m. For the purpose, to both of the panels have to be assigned specific priorities: The first fire alarm panel shall be the system Master and the second - Slave. -
Page 16: Class Change Mode
Up to 32 conventional fire detectors and an unlimited number of manual call points can be connected to each circuit. Figure 23 shows how to connect detectors within a zone. Figure 23. Connecting of detectors (D1÷N) and manual call points (CP1÷N) to the zone circuit. ERACLE 16 - Installation and Operation Manual... - Page 17 Figure 24 shows how to connect the sounders. One R=10K resistor is connected to the end of each circuit as shown in the diagram. LEGEND black brown Figure 24. Connecting of sounders to SND1÷SND4 outputs of the control module and the output of the 4-sounder expander. ERACLE 16 - Installation and Operation Manual...
-
Page 18: System Programming
In case of call point activation, the programmed sounder time delay will be ignored and the sounders will be activated immediately. In order to program ERACLE 16 for Sounder Delay over an interval between 1 and 10 minutes: •... -
Page 19: Double Action Mode
The purpose of introducing a DOUBLE Action mode is to avoid false alarms. Where ERACLE 16 has been programmed to function in this mode, in the case of a fire signal, the panel does not alarm at once but waits for the alarm event to be repeated within a specific time interval - Figure 25. -
Page 20: Master Panel Mode
Figure 26. Example for Instant Action Mode Programming. 5.4 Master Panel Mode When connecting two ERACLE 16 panels in a common system, the first must be pro- grammed as Master and the second as Slave. In order to program the Master Panel mode: •... -
Page 21: Operation Instructions
Level 1) only the SILENCE BUZZER button is active and in ON position (Access Level 2) all buttons are active. - Operation modes LED indication. - LED indication on zone status. - Control buttons. - Instructions for working with the fire panel. ERACLE 16 - Installation and Operation Manual... -
Page 22: Buttons
Lights up in yellow at disabled zone. Blinks in yellow: - 1 blink per second at trouble in the zone; - 2 blinks per second at “One Man” Test and disabling of zones. ERACLE 16 - Installation and Operation Manual... -
Page 23: Sound Signal
The signal can be stopped by pressing the SILENCE BUZZER button, but the LED indication remains. 6.6 Service Modes Zone Enable / Disable Each zone of ERACLE 16 can be enabled or disabled. To disable a zone: • Press ENABLE/DISABLE button: DISABLE/ ENABLE LED blinks. - Page 24 (item 6.1). At this point the sounders are enabled. You can exit the sounder enabling mode also by pressing the TEST/SCROLL button, as in that case the procedure for initial start-up will not run. ERACLE 16 - Installation and Operation Manual...
- Page 25 ZONE 1 is in test mode. Test a detector from this zone whether it react to smoke, heat, etc. ERACLE 16 will activate the sounders for about 2 seconds to confirm the provoked fire alarm. • Press TEST/SCROLL button to TEST LED will continue blinking.
-
Page 26: Indication
NOTE: The fault indication does not show immediately. There is a delay in reporting depending on the type of the fault. After all faults are corrected the panel automatically returns to NORMAL MODE. ERACLE 16 - Installation and Operation Manual... -
Page 27: Indication Of The Operation Modes
DISABLE • The respective zone LEDs light up in Disabled yellow to indicate disabled zones. zones and/or • The yellow SOUNDER FAULT/DISA- sounders. BLE LED lights up to indicate disabled sounders. ERACLE 16 - Installation and Operation Manual... -
Page 28: General Connection Circuit Of Eracle 16
ERACLE 16 - Installation and Operation Manual... -
Page 29: Fire Alarm Record
QUANTITY PER ZONE LOCATION № TOTAL: Ion - Ionisation sensor Ph - Photoelectric sensor RoR - Rate of Rise sensor F/T - Fixed Temperature sensor CP - Call Point System installed by: ..................Telephone/Fax: ..................ERACLE 16 - Installation and Operation Manual... -
Page 30: Service Record
ERACLE 16 - Installation and Operation Manual... -
Page 31: Spare Parts Kits
Self tapping screw М4,2х35 cross slot DIN7981 Jumper Cable tie 2,5/160mm Lightpipe for indication EOL - module Plastic cap 4-Zone Expander (43ECZ020) ERACLE 16 Spare Parts Kit Screw М3х6 DIN7985 Lightpipe for indication EOL - module Jumper 4-Sounder Expander (43ECS020) ERACLE 16 Spare Parts Kit Screw М3х6 DIN7985... - Page 32 Comelit Group S.p.A. Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy tel. +39 0346 750 011; fax +39 0346 71436 www.comelitgroup.com - info@comelit.it...
