Short manual testo 510
Basic settings
Instrument off >press and hold
confirm with
(
Unit of pressure/velocity: hPa, mbar, Pa, mmH2O, mmHg, psi, inH2O, inHG, m/s, fpm
>
Density of the medium (Density) > Auto off function: OFF, ON
Switching the instrument on
Press
.
Switching the display light on (for 10s)
Instrument on > press
Select display mode
Instrument on > select with
Current reading > Hold: Readings are held > Max: Maximum values > Min: Minimum
values > Hold Avg: Timed mean value calculation, see below
Timed mean value calculation for flow
Press
several times, until
- - - -
until
appears > Releasing
calculation, the current readings
are displayed > End measurement: press
displayed.
Switching the instrument off:
Instrument on >press and hold
1
Protection cap: Park position
2
Differential pressure sensor nipple
connection
3
Display
4
Control keys
5
Battery compartment, holding
magnets (on rear)
2s > select with
):
:
and
Hold
starts mean value
2s.
Short manual testo 510 11
appear > Hold
Avg
, the mean value is
( ),
down

Advertisement

Table of Contents
loading

Related Manuals for TESTO 510

Summary of Contents for TESTO 510

  • Page 1 Short manual testo 510 11 Short manual testo 510 Protection cap: Park position Differential pressure sensor nipple connection Display Control keys Battery compartment, holding magnets (on rear) Basic settings Instrument off >press and hold 2s > select with ( ),...

  • Page 2: About This Document

    > Take faulty rechargeable batteries as well as spent batteries to the collection points provided for them. > Send the product back to Testo at the end of its useful life. We will ensure that it is disposed of in an environmentally...

  • Page 3: Specifications

    Specifications 13 Specifications Functions and use The testo 510 is a differential pressure measuring instrument. It is normally used to measure small differences in pressure (e.g. to check filter permeability), gas flow pressure measurement, fine draught measurement as well as flow velocity measurement with a Pitot tube.

  • Page 4: Product Description

    Product description Product description At a glance Protection cap: Park position Differential pressure sensor nipple connection Display Control keys Battery compartment, holding magnets (on rear) First steps - Inserting batteries: 1 To open the battery compartment, push the battery cover down.

  • Page 5: Using The Product

    Using the product 15 Using the product For velocity to be measured, the unit of density and density value must be set correctly, see chapter ‚First steps‘, section ‚Basic settings (configuration mode)‘. - Switching the instrument on: > Press - Measuring mode is opened. - Switching the display light on: The instrument is switched on.

  • Page 6: Maintaining The Product

    Using the product - Timed mean value calculation for flow: Function only available when unit m/s or fpm is set. 1 Press several times, until appear in the Hold display. The last result of mean value calculation is displayed. - If mean value calculation was carried out since the last time the instrument was switched on, the last result is displayed.

  • Page 7: Tips And Assistance

    Keep to the permitted measuring range. · Residual capacity <10 min: Change batteries. If we could not answer your question, please contact your dealer or Testo Customer Service. For contact details, please visit www.testo.com/service-contact Accessories and spare parts Accessories and spare parts can be found in the product...
  • Page 8 Notes...
