testo · Smart Probes
Instruction manual
GlobalTestSupply
www.
.com
d Quality Products Online at:
sales@GlobalTestSupply.c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Probes 905i and is the answer not in the manual?

Questions and answers

Summary of Contents for TESTO Smart Probes 905i

  • Page 1 · Smart Probes Instruction manual GlobalTestSupply www. .com d Quality Products Online at: sales@GlobalTestSupply.c...
  • Page 2: Table Of Contents

    Safety and the environment ..............5 2.1. About this document ................ 5 2.2. Ensure safety................... 6 2.2.1. Safety and the testo 510i ..................6 2.2.2. Safety and the testo 549i ..................6 2.2.3. Safety and the testo 805i ..................6 2.3.
  • Page 3 Accessories and spare parts ............16 Technical data ..................16 9.1. Bluetooth module ................16 9.2. General technical data ..............17 9.2.1. testo 905i ......................17 9.2.2. testo 410i ......................18 9.2.3. testo 405i ......................19 9.2.4. testo 549i ......................19 9.2.5.
  • Page 4: Safety And The Environment

    2 Safety and the environment Safety and the environment 2.1. About this document > Please read this documentation through carefully and familiarize yourself with the product before putting it to use. Pay particular attention to the safety instructions and warning advice in order to prevent injuries and damage to the products.
  • Page 5: Ensure Safety

    > Dangers may also arise from the systems being measured or the measuring environment: Note the safety regulations valid in your area when performing the measurements. 2.2.1. Safety and the testo 510i • Magnetic field • May be harmful to those with pacemakers.
  • Page 6: Protecting The Environment

    > At the end of its useful life, send the product to the separate collection for electric and electronic devices (observe local regulations) or return the product to Testo for disposal. Specifications Testo Smart Probes are different hand-held measuring instruments for various applications that communicate with your mobile terminal devices by means of an app.
  • Page 7: Led Status

    3 Key 4 Battery compartment (at the back) 5 Direction of flow testo 405i / testo 410i (not shown) (An arrow on the top of the housing displays the direction of flow in which the measuring instrument has been calibrated and which achieves the best measurement results.
  • Page 8: Switching Off

    ® You need a tablet or smartphone with the testo Smart Probes App already installed on it to be able to establish a Bluetooth connection. You can get the App for iOS instruments in the App Store or for Android instruments in the Play Store.
  • Page 9: Using The App

    6 Using the App Using the App 6.1. Overview of operating controls Choice of applications. Display of connected Smart Probes. 3 Switch between the views (list, graphic diagram, table) Measurement settings. (The menu changes depending on the Smart Probe connected and the application selected) Restarts the measuring value recording in graph and table format.
  • Page 10: Display Tutorial

    Tutorial is displayed. In Tutorial, swipe to display the next page. 2. Tap X to close the Tutorial. 6.2.3. Show help An internet connection is required to display the testo website. 1. Tap -> Help The page www.testo.com/smartprobesmanuals.html is displayed.
  • Page 11: Setting Favourites

    6 Using the App 6.3.2. Setting favourites 1. Press A selection of applications is displayed. 2. Press next to the application that you would like to designate as a favourite. The asterisk is displayed in orange , and the selected application is listed under Show Favorites.
  • Page 12: Settings View

    6 Using the App • Table view In the Table view, all readings are displayed in sequence according to date and time. The different readings from the individual Smart Probes can be selected by pressing ◄ ►. 6.6. Settings view Edit View.
  • Page 13: Pdf Export

    > Keep connections clean and free of grease and other deposits, clean with a damp cloth as required. Ensuring measuring accuracy > Testo Customer Service would be glad to further assist you if you so wish. > Keep within the permissible measuring range! >...
  • Page 14: Smart Probes App

    7.2. Smart Probes App The testo Smart Probes App is kept updated via the Play Store for Android devices and the App Store for iOS devices. Please update the App as soon as a new update is available. We therefore recommend that you do not disable automatic notifications when new updates are available.
  • Page 15: Accessories And Spare Parts

    Designation Item number testo Smart Case (Refrigeration) for storing and transporting 0516 0240 2 × testo 115i and 2 × testo 549i, dimensions 250 × 180 × 70 mm testo Smart Case (Heating) for storing and transporting 0516 0270 testo 115i, testo 410i, testo 510i, testo 549i and testo 805i, dimensions 250 ×...
  • Page 16: General Technical Data

    Changes The FCC demands that the user be informed that any changes or modifications to the instrument that have not been explicitly approved by Testo AG may void the user's right to use this instrument. 9.2. General technical data All accuracy specifications apply at a nominal temperature of 22 °C.
  • Page 17: Testo 410I

    Probe shaft diameter 4 mm Directives, standards EU guideline: 2014/30/EU and tests Warranty Duration: 2 years Warranty terms: see website www.testo.com/warranty 9.2.2. testo 410i Feature Values Measuring range 0.4 to 30 m/s / 80 to 5,900 fpm -20 to 60 °C / -4 to 140 °F Accuracy ±...
  • Page 18: Testo 405I

    Probe tip diameter 9 mm Directives, standards EU guideline: 2014/30/EU and tests Warranty Duration: 2 years Warranty terms: see website www.testo.com/warranty 9.2.4. testo 549i Feature Values Measuring range 0 to 60 bar (rel) / 0 to 870 psi (rel) Overpressure 65 bar Accuracy ±...
  • Page 19: Testo 805I

    125 mm × 32 mm × 31 mm Directives, standards EU guideline: 2014/30/EU and tests Warranty Duration: 2 years Warranty terms: see website www.testo.com/warranty 9.2.5. testo 805i Feature Values Measuring range -30 °C to 250 °C / -22 to 482 °F Accuracy ±...
  • Page 20: Testo 605I

    Adjustable from 0.1 to 1.0 Directives, standards EU guideline: 2014/30/EU and tests Warranty Duration: 2 years Warranty terms: see website www.testo.com/warranty 9.2.6. testo 605i Feature Values Measuring range -20 to 60 °C, -4 to 140 °F, 0 to 100% RH Accuracy ±...
  • Page 21: Testo 510I

    Probe shaft length 100 mm Directives, standards EU guideline: 2014/30/EU and tests Warranty Duration: 2 years Warranty terms: see website www.testo.com/warranty 9.2.7. testo 510i Feature Values Measuring range 0 to 150 hPa / 60 in wc Accuracy ± 1 digit ±...
  • Page 22: Testo 115I

    9 Technical data 9.2.8. testo 115i Feature Values Measuring range -40 to 150 °C / -58 to 302 °F Accuracy ± 1 digit ± 1.3 °C (-20 to 85 °C) ± 2.34 °F (-4 to 185 °F) Resolution 0.1 °C / 0.1 °F...
