Adjust Limits
1. Adjust the Upper Limit
a. Press and hold (about 5 sec) "Up" and "Stop"
buttons simultaneously until motor jogs x1 and
beeps x1.
b. Use "Up" button to raise the shade to the desired
highest position, and use "Up" or "Down" button to
do the final adjustment if necessary.
c. Press and hold (about 5 sec) "Up" and "Stop"
buttons simultaneously until motor jogs x2 and
beeps x3.
2. Adjust the Lower Limit
a. Press and hold (about 5 sec) "Down" and "Stop"
buttons simultaneously until motor jogs x1 and
beeps x1.
b. Use "Down" button to lower the shade to the
desired lowest position, and use "Up" or "Down"
button to do the final adjustment if necessary.
c. Press and hold (about 5 sec) "Down" and "Stop"
buttons simultaneously until motor jogs x2 and
beeps x3.
Favorite Position
1. Set Favorite Position
a. Use "Up" or "Down" button to move the shade to
desired Favorite position.
b. Press and hold (about 2 sec) one "P2" button on
the back of remote control until motor jogs x1 and
beeps x1.
c. Press and hold (about 2 sec) "Stop" button until
motor jogs x1 and beeps x1.
d. Once more, press and hold (about 2 sec) "Stop"
button until motor jogs x2 and beeps x3.
2. Send Shade to Favorite Position
Press and hold (about 2 sec) "Stop" button, motor
will move to Favorite position.
8
B L I S S R E M O T E C O N T R O L
Action on
Remote Control
Motor Response
Action on
Remote Control
Motor Response
Action on
Remote Control
Motor Response
Action on
Remote Control
Motor Response
Action on
Remote Control
Motor Response
Action on
Remote Control
Motor Response
Action on
Remote Control
Shade Response
|
R E F E R E N C E G U I D E
a.
+
Up
Stop
Jog x1
Beep x1
c.
+
Up
Stop
Jog x2
Beep x3
a.
+
Down
Stop
Jog x1
Beep x1
c.
+
Down
Stop
Jog x2
Beep x3
a.
or
Up
Down
or
c.
Stop
Jog x1
Beep x1
Stop
or
b.
Up
b.
Down
b.
P2
Jog x1
Beep x1
d.
Stop
Jog x2
Beep x3
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the Bliss Automation and is the answer not in the manual?
Questions and answers
BLINDS NOT CHARGING
ALTA Bliss Automation blinds may not be charging due to the following reasons:
1. Low Battery Alert – If the battery has run out, it needs to be recharged.
2. Charging Issues – Ensure the battery is connected to the correct USB power source (USB 5V 1A or USB 5V 2A).
3. Blinking Indicators – A blinking red light indicates a low battery, while a blinking green light shows charging is in progress. A solid green light means charging is complete.
4. Environmental Factors – The motor should not be exposed to moisture or extreme temperatures (-10℃ to +50℃).
5. Hardware Issues – If power cables are damaged or incorrectly connected, charging may not work.
Checking these factors can help diagnose and resolve charging issues.
This answer is automatically generated
Reset to factory, did pairing step. Unit is charged. When I press up or down it jogs but does not keep moving. I have been working on this for hours and hours.
If the ALTA Bliss Automation unit jogs but does not keep moving after a factory reset, follow these troubleshooting steps:
1. Check Battery and Power:
- Ensure the battery is not dead or inserted incorrectly (check polarity).
- If using a solar panel, recharge with the provided charger and check panel positioning.
- Verify that the motor is properly connected to power.
2. Check for Radio Interference:
- Keep the remote control and motor antenna away from metal objects.
- Move the remote closer to the receiver.
3. Check Remote Pairing:
- After a factory reset, the motor must be re-paired with the remote.
- Press the P1 button on the motor for about 2 seconds until the motor jogs once and beeps once.
- Within 10 seconds, press and hold the “Stop” button on the remote until the motor jogs twice and beeps three times.
4. Sleep Mode or Multiple Motors:
- Ensure other motors are in sleep mode to avoid interference.
- Make sure only one motor is paired to the remote channel being used.
5. Check Wiring:
- Confirm wiring is connected correctly if applicable.
If the motor jogs but does not continue operation, it is likely not fully paired with the remote or affected by one of the above issues. Re-pairing and checking power and signal conditions should resolve the issue.
This answer is automatically generated
Shade will not move either direction - new remote battery and unit charged fully
The ALTA Bliss Automation shade may not move in either direction despite a new remote battery and a fully charged unit because the motor direction cannot be changed if the upper and lower limits are already set. In this case, direction change can only be done using the P1 button. If the motor is set to move in a direction that is blocked by the preset limits, it will not respond to remote commands.
This answer is automatically generated
We moved into place with 2 shades that are synced with remote. They worked fine- today only 1 responds.
