5.5.1. Wheel assembly

To substitute the wheel assembly (rh or lh) remove the fastener (F) in Figure 47
and remove the wheel.
Insert the new wheel on the axis of the frame using the appropriate location hole,
previously aligned with the present hole on the axis of the frame and fully insert
the locking clip (F).
Make sure that the fastener is securely attached to the hub of the wheels.
F
Figure 47
Code Description
R105-001 Wheel assembly
