2.3. Mounting the wheelchair

Anti-tip bar and front support bar
Insert anti-tip bar (D) and front support bar (C) into the main chassis (E) as shown
in Figure 29. Secure the two bars with fasteners.
Make sure tubes are correctly locked.
D
Figure 29
Tubes (D) and (C) are of the same width but (D) is
longer.
If tubes (D) and (C) are inverted, the wheelchair will
result unbalanced with possible risk for the user.
www.neatech.it
43
C
WARNING
