TACTouch
Operation & Assembly Manual, TAC5/TAC6 Controller
20210315

Advertisement

Table of Contents
loading

Related Manuals for Swegon TACTouch TAC5

Summary of Contents for Swegon TACTouch TAC5

  • Page 1 TACTouch Operation & Assembly Manual, TAC5/TAC6 Controller 20210315...

  • Page 2: Table Of Contents

    Content Safety .................... 3 Information about documentation ..........3 Storage of documentation ............3 Applied symbols ................3 WEEE 2012/19/UE Directive ............3 General information ..............4 Operation of the panel ..............4 Software update ................5 Technical data ................5 Exploitation conditions ...............

  • Page 3: Safety

    • do not dispose of the product with other unsorted waste, • do not burn the product. By adhering obligations of waste electrical and electronic equipment controlled disposal mentioned above, you avoid harmful effects on the environment and human health. 20210215 Swegon reserves the right to alter specifications.

  • Page 4: General Information

    - quick return back to the main screen. Main menu. Main menu - menu information concerning the selected After pressing menu button panel shows the rotary menu. menu position. - enter to the main menu. Swegon reserves the right to alter specifications.

  • Page 5: Software Update

    Temperature measuring 0…50°C range Relative humidity 5…85%, without conden- sation. Display Graphic, color 480x272 pix. with touch screen. Dimensions 144x97x20 mm Weight 0.2 kg Standards PN-EN 60730-2-9 PN-EN 60730-1 Assembly method On wall Swegon reserves the right to alter specifications.

  • Page 6: Exploitation Conditions

    Assembly. Disconnect the mounting frame (1) from the back of control panel housing (2). The frame is attached to the control panel housing with latches. Use a flat screwdriver to detach the frame. Swegon reserves the right to alter specifications.

  • Page 7: Connecting The Control Panel To The Controller

    155Ω/km), max. length of 50 m. Signal outputs in the control panel connector: The control panel has built-in magnets, which allows it to be attached without screws to a flat metal mounting surface. Swegon reserves the right to alter specifications.

  • Page 8: Cleaning And Maintenance Procedures

    In addition, EL2adapter_v2 adapter can be used to extension the control panel connection to the controller module. The adapter provides a wire connection with an RJ-type plug with a 4-wire cable and is available from the control panel manufacturer. Swegon reserves the right to alter specifications.

  • Page 9: Connecting Tactouch Control Panel To The Tac5 Controller

    TACTouch Connecting TACTouch control panel to the TAC6/TAC5 controller 20210215 Swegon reserves the right to alter specifications.
  • Page 10 TACTouch TACtouch centralized (TAC5/TAC6). Advanced setup: configure SAT MODBUS with correct address Swegon reserves the right to alter specifications. 20210215...
  • Page 11 TACTouch The manufacturer reserves a right for making changes in construction and software without previous notice. 20210215 Swegon reserves the right to alter specifications.
