LUNA RC a
Instructions for Use

Symbol explanation

Symbols on the machine.
This product complies with applicable EU
directives.
Symbols in this user manual
Warning/Caution!

Application area

LUNA RC is a controller that has been designed to regulate
room temperature as well as VAV control applications.
The product may not be used for anything other than its
intended use.

General

Read through the entire instructions for use before
you install/use the product and save the instructions
for future reference. It's not permissible to make changes
or modifications to this product other than those specified
in this document.

Protective equipment

Always use appropriate personal protective equipment
for the work in question, in the form of gloves,
respirators and protective glasses during handling,
installation, cleaning and service/maintenance.

Electrical safety

Permitted voltage, see "Electrical data". It is not
permissible to insert foreign objects into the product's
contactor connections or the electronics's ventilation openings;
risk for short circuiting.
24 V isolation transformer to be connected should comply
with the provisions of IEC 61558-1.
Cable sizing must be carried out for cabling between the
product and the power supply source.
Disconnect the power supply when working on products
that are not required to run in production.
Always follow the local/national rules for who shall be
permitted to carry out this type of electrical installation.
The document was originally written in Swedish

Handling

• The product must be handled with care.

• Installation

• Moist, cold and aggressive environments must be
avoided.
• Avoid installing the product near a heat source.
• Assemble the product according to applicable industry
regulations.
• Install the product for easy access during service/
maintenance.
• If the product is mounted above a fixed ceiling, the
inspection hatch must be located so that the product is
accessible for inspection.
• Check to make sure that the product doesn't have any
visible defects.
• Check that the product is properly secured after it has
been installed.
• Check that all cables are properly secured in place after
installation.
20220808
