Bird-X Super BirdXPeller Pro Quick Start Manual

VOLUME CONTROL
The unit has a volume control dial on the front panel
of the unit. Turning the dial toward low will result in
reduced sound output and rotating the dial toward
high will result in an increase in sound output.
CAUTION: Take care when turning the dial since the unit may
be in an inactive state when the dial is rotated. It could then
reactivate at a very high level of sound which could be painful
to your ears.
POWER SWITCH
The power switch enables the unit to operate.
Slide the switch to the ON position to start the
unit. If you turn the unit OFF, be sure to leave it off
for about 30 seconds before turning it back on to
allow the electronics to properly reset.
TROUBLESHOOTING
PROBLEM SOLUTION
• Check volume settings
Unit is on,
• Check time of operation settings.
but no sound is heard
• Check that at least one bird is
selected to play.
Unit is on, but plays the
Reset the unit by turning it off
same bird over and over,
for 30 seconds and then back on
regardless of settings
• Double check Mode
switch settings
Unit is not operating • Make sure photocell
is not obstructed.
properly in the
DAY or NIGHT mode • Make sure the photocell is
not affected by bright lights
in either the front or the
back of the unit.
• Check battery condition
Unit does not function
• Turn power switch on unit
properly when connected
to the OFF position.
to a 12 volt battery Reconnect the battery,
wait 30 seconds, then
switch the unit back on
LIMITED WARRANTY
THIS SUPER BIRDXPELLER PRO UNIT IS
GUARANTEED AGAINST DEFECTS
MATERIAL AND WORKMANSHIP FOR SIX
MONTHS FROM DATE OF PURCHASE. BIRD-X
WILL REPLACE OR REPAIR,
DEFECT OCCURS UNDER NORMAL USE.
UNITS ALSO CARRY A 30-DAY PERFORMANCE
GUARANTEE. IF USER IS NOT SATISFIED WITH
RESULTS, UNIT MAY BE RETURNED WITHIN 30
DAYS FOR CREDIT LESS A 15% HANDLING
AND RESTOCKING CHARGE.
ACCEPTED ONLY WITH AUTHORIZATION
FROM OUR CHICAGO OFFICE.
300 North Elizabeth Street • Chicago, IL 60607
ph. (312) 226-2473 • fax (312) 226-2480
Toll Free US & Canada 800-662-5021
www.bird-x.com
EPA Establishment Number 62617-OR-001
Pest Control Products Act #23587
SUPER BIRDXPELLER PRO P/N #10371
PRIOR TO INSTALLATION
Your complete Super BirdXPeller Pro kit includes a
control unit, power adapter, battery cable with clips
and four speakers. Open the control unit by lifting
the two latches on the side of the enclosure.
IN
PROVIDED
Prior to operation, route the speakers and power
cables from their respective jacks on the control
panel down through the cable strain relief in the
lower part of the enclosure, as shown in Figure 1.
RETURNS
IMPORTANT:
the power switch is in the OFF
position and the volume control is
set to the minimum (LOW) volume
level (counterclockwise)
shown in Fig. 2 while plugging the
speaker and power cords into the
control unit.
INSTALLATION
1) Use the mounting hardware (included) to mount
the control unit box to a wall, post or other
vertical surface.
2) Plug the power adapter into an electrical outlet or
attach the battery clip assembly to a 12V battery.
The other end of the cable should already be
plugged into the power jack located below
POWER on the front panel of the control unit box.
Digital Bird Repeller
Cable Strain Relief
Be certain that
as
Fig. 1
Fig. 2
